- Allen Bradley
- 2711P-B10C15A1
- PanelView Plus 1000 Operator Interface
- USA
- 399 x 55 x 248 mm
- 2.9 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 24
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Allen-Bradley 2711P-B10C15A1 is a PanelView Plus 1000 Operator Interface Terminal (HMI) designed for industrial automation and process control applications. It provides a graphical touch-screen interface for operators to monitor, control, and interact with PLC-controlled systems.
This HMI model belongs to the PanelView Plus 1000 series, offering enhanced visualization, flexible communication options, and reliable industrial performance.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Model | 2711P-B10C15A1 |
| Product Type | PanelView Plus 1000 Operator Interface (HMI) |
| Display Size | 10.4-inch color touchscreen |
| Resolution | 800 × 600 pixels (SVGA) |
| Input Type | Touchscreen with virtual keypad and function buttons |
| Communication | Ethernet, DF1, DH+, and DeviceNet options |
| Power Supply | 24 V DC nominal |
| Application Memory | Up to 16 MB (model-dependent) |
| Mounting Type | Panel mount |
| Dimensions | 399 × 55 × 248 mm |
| Weight | 2.9 kg |
Function and Working Principle
The 2711P-B10C15A1 functions as a human-machine interface (HMI), bridging operators and industrial control systems.
Its main functions include:
- Displaying real-time process and machine data
- Allowing operator input via touchscreen and virtual buttons
- Sending commands to PLCs and receiving status updates
- Displaying alarms, warnings, and diagnostics
- Supporting multiple communication protocols for flexibility
The HMI scans operator inputs, communicates with PLCs, and updates the display in real time, providing efficient control and visualization of industrial processes.
Key Features
- 10.4-inch color touchscreen with SVGA resolution
- Multiple communication options: Ethernet, DF1, DH+, DeviceNet
- Supports advanced graphics and dynamic displays
- Alarm, trend, and recipe management capabilities
- Rugged industrial design suitable for harsh environments
- Easy panel mounting with compact depth
- High reliability and long operational lifespan
Industrial Applications
- Manufacturing automation and production lines
- Packaging and conveyor systems
- Process control in chemical, water, or food industries
- Material handling and machine operation
- Monitoring and controlling assembly line equipment
- Industrial machinery diagnostics and alarms
Role in Industrial Systems
The 2711P-B10C15A1 serves as the primary operator interface, responsible for:
- Displaying machine status and operational data
- Allowing manual control of machinery and processes
- Visualizing alarms, events, and system diagnostics
- Facilitating communication between PLCs and operators
- Enhancing operational efficiency and safety
It is essential for providing intuitive interaction, real-time monitoring, and operational control in industrial automation environments.
Installation Notes
- Panel-mounted on control cabinet or machine console
- Requires 24 V DC power supply
- Proper grounding and cable management recommended
- Communication wiring should match HMI configuration and PLC protocols
- Installation should be performed by qualified personnel
Compatible Equipment
- Allen-Bradley ControlLogix and CompactLogix PLCs
- DF1, DH+, Ethernet/IP, and DeviceNet networked devices
- Industrial sensors and actuators
- SCADA and supervisory control systems
- Legacy Allen-Bradley PLCs with compatible communication
Advantages
- Large touchscreen for clear visualization
- Multi-protocol communication for flexible integration
- Rugged and durable industrial construction
- Advanced visualization capabilities (trends, alarms, graphics)
- Reliable operator interface for complex industrial systems
- Easy to configure and maintain
Limitations
- Heavier and larger than PanelView Micro or Standard models
- Requires DC power supply (24 V)
- Legacy protocols may need adapters for modern Ethernet-only networks
- Obsolete compared to PanelView Plus 7 series in some applications
Conclusion
The Allen-Bradley 2711P-B10C15A1 PanelView Plus 1000 Operator Interface is a robust and flexible HMI for industrial automation systems.
It delivers high-quality visualization, multi-protocol communication, and intuitive operator control, making it ideal for manufacturing, process control, and complex machine automation environments.
