Allen Bradley 1734SC-IF4U Detailed Technical Overview
1. Product Overview
The Allen Bradley 1734SC-IF4U is a 4-channel universal analog input module designed for distributed industrial automation systems. It is capable of accepting multiple types of analog signals, including voltage and current, making it a highly flexible solution for process monitoring and control.
This module supports individually configurable input channels, allowing each channel to be set for different signal types such as 0–10V, ±10V, or 4–20 mA. This flexibility makes it suitable for systems where different sensors and transmitters are used within the same installation.
The compact structure and modular integration allow the module to be installed close to field devices, reducing signal wiring length and improving measurement accuracy.
2. Brand and Series
- Brand: Allen Bradley
- Series: 1734 Series
- Platform: POINT I/O
- Module Type: Universal Analog Input Module
This module belongs to a distributed I/O platform designed for flexible system expansion and efficient signal acquisition in industrial environments.
3. Technical Specifications
Parameter Table
| Parameter | Specification |
|---|---|
| Model | 1734SC-IF4U |
| Input Type | Analog (Universal) |
| Channels | 4 |
| Signal Types | Voltage / Current |
| Voltage Range | 0–10V, ±10V |
| Current Range | 0–20 mA, 4–20 mA |
| Resolution | 16-bit |
| Input Impedance | High (Voltage), Low (Current loop) |
| Accuracy | ±0.1% full scale (typical) |
| Conversion Time | Approx. 5–10 ms per channel |
| Isolation | Channel-to-backplane isolation |
| Bus Current | Approx. 75 mA @ 5V DC |
| Power Dissipation | Approx. 2–3 W |
| Mounting | DIN Rail |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Dimensions | Approx. 75 × 12 × 56 mm |
| Weight | ≈ 0.11 kg ( 0.11 ) |
4. Product Features
The 1734SC-IF4U is designed to provide precise and flexible analog signal acquisition.
- Four independently configurable analog input channels
- Supports both voltage and current input signals
- High-resolution 16-bit data conversion
- Compact design for high-density installations
- Channel isolation for improved signal integrity
- Modular architecture for easy expansion
- DIN rail mounting for simple installation
These features ensure accurate measurement and flexible configuration in complex systems.
5. Product Applications
The module is widely used in industrial automation systems requiring analog signal monitoring.
Typical applications include:
- Process control systems
- Temperature, pressure, and flow monitoring
- Sensor and transmitter interfacing
- Industrial data acquisition systems
- Chemical and manufacturing processes
- Energy management and monitoring systems
It is especially suitable for applications where multiple signal types need to be processed within a single module.
6. Product Advantages
High Flexibility
Supports multiple signal types on each channel, reducing the need for different module types.
Accurate Measurement
16-bit resolution ensures precise data acquisition for process control.
Reduced Wiring Complexity
Distributed installation reduces cable length and signal noise.
Compact Design
Slim form factor enables efficient use of panel space.
Easy Integration
Seamlessly integrates into modular distributed I/O systems.
7. Recommended Models (Same Series or Related)
POINT I/O Analog and Related Modules
| Model | Type | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 1734-IF4 | Analog Input | 4 | Voltage/Current | 75 × 12 × 56 | 0.10 ( 0.10 ) |
| 1734-IE2C | Analog Input | 2 | Current | 75 × 12 × 56 | 0.09 ( 0.09 ) |
| 1734-OE2C | Analog Output | 2 | Current | 75 × 12 × 56 | 0.11 ( 0.11 ) |
| 1734-OE2V | Analog Output | 2 | Voltage | 75 × 12 × 56 | 0.11 ( 0.11 ) |
| 1734-IT2I | Temperature Input | 2 | Thermocouple/RTD | 75 × 12 × 56 | 0.12 ( 0.12 ) |
These modules allow flexible configuration of analog input and output functions within the same system.
8. Recommended Popular Models (Same Brand)
Widely Used Industrial Modules
| Model | Type | Channels | Function | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 1756-EN2T | Communication | — | Ethernet Interface | 145 × 140 × 35 | 0.45 ( 0.45 ) |
| 1756-IF8 | Analog Input | 8 | Voltage/Current | 145 × 140 × 35 | 0.45 ( 0.45 ) |
| 1756-OB16E | Digital Output | 16 | 24V DC Output | 145 × 140 × 35 | 0.42 ( 0.42 ) |
| 1769-IF4 | Analog Input | 4 | Voltage/Current | 118 × 87 × 35 | 0.30 ( 0.30 ) |
| 1769-OF2 | Analog Output | 2 | Voltage/Current | 118 × 87 × 35 | 0.28 ( 0.28 ) |
