- Allen Bradley
- 2094-SE02F-M00-S0
- Kinetix 6200 Safety Shutdown Control Module
- USA
- 290 x 70 x 285 mm
- 0.68 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 5
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The 2094-SE02F-M00-S0 is a Safety Shutdown / Safe Torque-Off control module used in the Allen-Bradley Kinetix 6200 / 6500 servo drive system.
It is designed to manage functional safety operations, including safe shutdown of servo power, ensuring that motors cannot generate torque when a safety condition is triggered.
This module is commonly used in safety-rated motion control systems integrated with Logix controllers.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen-Bradley |
| Series | Kinetix 6200 / 6500 |
| Model | 2094-SE02F-M00-S0 |
| Product Type | Safety Shutdown / Control Module |
| Function | Safe Torque-Off (STO) / Safety control |
| Communication | SERCOS interface |
| Safety Rating | SIL3 / PLe capable system architecture |
| System Voltage | 324–528V AC (drive system dependent) |
| Installation | Kinetix 2094 power rail system |
| Dimensions | 290 × 70 × 285 mm |
| Weight | 0.68 kg |
Function and Working Principle
The module is responsible for safety-level control of servo drive shutdown.
Its operation includes:
- Monitoring safety inputs from safety circuits or controllers
- Enabling or disabling drive torque generation
- Executing Safe Torque-Off (STO) when required
- Preventing unintended motor restart after safety trips
- Communicating safety status via SERCOS-based motion system
When a safety event occurs, it ensures the drive output is disabled in a controlled and certified manner.
Key Features
- Integrated Safe Torque-Off functionality
- Designed for SIL3 / Performance Level e safety architectures
- Works within Kinetix 6200/6500 multi-axis servo systems
- Supports SERCOS motion communication
- Eliminates need for external safety contactors in many configurations
- Provides real-time safety state monitoring
Industrial Applications
- Robotics systems
- Packaging machinery
- CNC and machining centers
- Automated production lines
- Material handling systems
- Safety-critical motion control systems
Role in Industrial Systems
This module is used to:
- Provide certified safety shutdown of servo drives
- Prevent hazardous motor motion during faults or E-stop conditions
- Interface machine safety systems with motion control architecture
- Ensure compliance with industrial safety standards in motion systems
Installation Notes
- Installed on Kinetix 2094 power rail system
- Must be paired with compatible Kinetix drive modules
- Requires correct safety wiring and configuration
- STO functionality must be validated during commissioning
- System must follow safety-rated design architecture
Compatible Equipment
- Kinetix 6200 / 6500 servo drives
- Logix 5000 controllers
- SERCOS motion networks
- 2094 power rail systems
- Industrial safety I/O systems
Advantages
- High-integrity safety shutdown capability
- Reduces need for external safety relays in some designs
- Integrated motion + safety architecture
- Suitable for high-performance servo systems
- Certified safety-level operation
Limitations
- Legacy Kinetix platform (no longer current-generation)
- Requires specific SERCOS-based architecture
- Not compatible with modern EtherNet/IP-only motion systems
- Complex configuration and commissioning requirements
Conclusion
The 2094-SE02F-M00-S0 Safety Shutdown Control Module is a dedicated safety component in the Kinetix 6200 servo system, responsible for implementing Safe Torque-Off and ensuring controlled, certified shutdown of motion systems in industrial automation environments.
