- Allen Bradley
- 1794-IE8XT
- ControlNet Flex I/O Adapter Module
- USA
- 94 × 94 × 69 mm
- 0.12kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 4
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
1794-IE8XT FLEX I/O XT Analog Input Module – Detailed Technical Overview
1. Product Introduction
The 1794-IE8XT is an industrial-grade FLEX I/O XT series analog input module designed for harsh and extended environmental conditions. It is used for acquiring analog signals from field instruments such as transmitters, sensors, and industrial measurement devices, and converting them into digital signals for PLC processing.
Compared with standard FLEX I/O modules, the “XT” version is engineered for extended temperature operation and higher environmental resistance, making it suitable for outdoor installations, extreme temperature zones, and demanding industrial applications.
It belongs to the FLEX I/O distributed I/O family and is typically installed on a compatible XT terminal base, providing reliable data acquisition in remote or harsh environments.
2. Product Features
- 8-channel analog input module
- Designed for extreme temperature environments (XT series)
- Supports current and voltage input signals
- High-resolution analog conversion
- FLEX I/O distributed architecture compatibility
- Ruggedized industrial design
- DIN rail mounting system
- LED diagnostic indicators
- Stable operation under vibration and shock conditions
- Suitable for outdoor or harsh industrial locations
3. Technical Parameters
| Parameter | Specification |
|---|---|
| Model | 1794-IE8XT |
| Product Type | XT series analog input module |
| Series | FLEX I/O XT / 1794 Series |
| Input Channels | 8 single-ended analog inputs |
| Input Signal Types | 0–20 mA, 4–20 mA, 0–10 V, ±10 V |
| Resolution | 12-bit / 16-bit data format (system dependent) |
| Conversion Type | Successive approximation ADC |
| Input Accuracy | ±0.1% to ±0.2% full scale |
| Input Impedance | High impedance voltage / low impedance current |
| Power Supply | 24V DC nominal |
| Operating Temperature | -20°C to 70°C (extended XT range) |
| Storage Temperature | -40°C to 85°C |
| FlexBus Current | ~40–80 mA |
| Power Dissipation | ~3–4 W |
| Isolation | Field-to-system isolation (50V typical) |
| Channel Isolation | Non-isolated channels |
| Update Time | ~5–10 ms scan cycle |
| Indicator Lights | Power + channel status LEDs |
| Mounting Type | DIN rail |
| Terminal Base | XT-compatible FLEX I/O base |
| Vibration Resistance | 5g (10–500 Hz) |
| Shock Resistance | 30g |
| IP Rating | IP20 |
| Dimensions | 94 × 94 × 69 mm |
| Weight | 0.12 kg |
4. Product Function Description
The 1794-IE8XT is designed to collect analog process signals in environments where standard I/O modules may fail due to temperature extremes or harsh conditions.
Each channel converts incoming analog signals into digital values for PLC systems. These signals typically represent physical variables such as pressure, flow, temperature, or level.
The XT version is reinforced for stable operation in outdoor enclosures, remote skids, and industrial zones with high vibration or temperature fluctuations.
It is commonly used in distributed control systems where reliability under harsh conditions is critical.
5. Product Applications
The 1794-IE8XT is suitable for industrial environments requiring rugged analog signal acquisition.
Typical Applications
- Oil and gas production sites
- Offshore platforms
- Mining operations
- Outdoor process control systems
- Water and wastewater remote stations
- Chemical plants with extreme environments
- Power generation auxiliary systems
- Pipeline monitoring systems
- Heavy industrial machinery
- Remote automation systems
Typical Field Devices
- Pressure transmitters
- Flow transmitters
- Temperature sensors
- Level sensors
- Industrial analog probes
- Environmental monitoring instruments
6. Product Advantages
6.1 Extended Temperature Design
Operates reliably in extreme hot and cold environments compared to standard modules.
6.2 Rugged Industrial Construction
Designed for vibration, shock, and harsh field conditions.
6.3 Flexible Signal Compatibility
Supports both current and voltage analog inputs.
6.4 Stable Distributed Architecture
Integrates into FLEX I/O systems for remote and modular automation.
6.5 Reliable Data Acquisition
Provides stable analog signal conversion in harsh environments.
6.6 Reduced Downtime
High durability reduces maintenance frequency in remote installations.
6.7 Compact Design
Maintains standard FLEX I/O footprint despite ruggedization.
7. Brand Overview
This product belongs to a globally recognized industrial automation technology provider specializing in:
- PLC control systems
- Distributed I/O platforms
- Industrial networking solutions
- Process automation systems
- Safety and motion technologies
Its systems are widely used across energy, oil & gas, manufacturing, mining, and infrastructure industries due to reliability and long lifecycle support.
8. Product Series Information
Series Name
FLEX I/O XT Series (1794 XT Ruggedized Line)
Series Type
Rugged distributed analog I/O system
Key Characteristics
- Extended temperature operation
- High vibration and shock resistance
- Industrial-grade environmental protection
- Modular distributed architecture
- DIN rail mounting
- Remote installation capability
The 1794-IE8XT is part of the XT rugged analog input lineup designed for extreme environments.
9. Recommended Related Models (Same Series or Similar)
| Model | Product Type | Function | Dimensions | Weight (kg) | Key Parameters |
|---|---|---|---|---|---|
| 1794-IE8XT | XT analog input module | 8-channel AI | 94 × 94 × 69 mm | 0.12 kg | Rugged extended temp |
| 1794-IE8 | Standard AI module | 8-channel AI | 94 × 94 × 69 mm | 0.11 kg | Standard environment |
| 1794-IE12 | High-density AI | 12-channel AI | 94 × 94 × 69 mm | 0.12 kg | More inputs |
| 1794-IF4I | Isolated AI module | 4-channel AI | 94 × 94 × 69 mm | 0.11 kg | High isolation |
| 1794-OE4 | Analog output module | 4-channel AO | 94 × 94 × 69 mm | 0.10 kg | Control output |
10. Recommended Popular Models from Same Brand
| Model | Product Type | Function | Dimensions | Weight (kg) | Key Parameters |
|---|---|---|---|---|---|
| 1756-L81E | PLC controller | ControlLogix CPU | 145 × 175 × 52 mm | 0.92 kg | High performance |
| 1769-L33ER | Compact PLC | CompactLogix system | 118 × 87 × 87 mm | 0.60 kg | Ethernet integrated |
| 1734-AENTR | Ethernet adapter | POINT I/O system | 75 × 75 × 55 mm | 0.18 kg | Distributed I/O |
| 2711P-T10C4D8 | HMI panel | Operator interface | 271 × 212 × 60 mm | 1.80 kg | Touchscreen HMI |
| 20-COMM-E | Drive comm module | Ethernet communication | 140 × 95 × 30 mm | 0.22 kg | Drive networking |
11. Installation Notes
- Use XT-rated compatible terminal base
- Ensure proper sealing for harsh environments
- Maintain correct grounding practices
- Avoid routing near high-voltage lines
- Ensure stable 24V DC supply
- Secure DIN rail installation firmly
12. Maintenance Recommendations
- Periodically inspect wiring integrity
- Monitor signal stability under extreme conditions
- Check module diagnostics LEDs
- Clean enclosure environment regularly
- Replace if signal drift or faults occur
13. Summary
The 1794-IE8XT is a ruggedized FLEX I/O analog input module designed for harsh and extreme industrial environments. Its extended temperature capability, durable construction, and stable signal acquisition make it suitable for remote automation systems where standard modules cannot reliably operate.
