Product Overview
The Allen Bradley 1785-L20B is a PLC-5/20 Processor, designed as the central processing unit for PLC-5 automation systems requiring higher performance and faster processing than the PLC-5/11 series. It is ideal for complex control applications, offering enhanced memory, faster scan times, and reliable industrial operation.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 1785-L20B |
| Product Type | PLC Processor |
| Function | Central processing unit for PLC-5 systems |
| Compatibility | PLC-5 I/O modules and racks |
| Dimensions | 165 × 51 × 89 mm |
| Weight | 1.45 kg |
| Operating Environment | Industrial automation and process control systems |
Function and Working Principle
The 1785-L20B functions by:
- Executing user-defined PLC programs with high-speed processing
- Reading inputs from PLC-5 I/O modules
- Generating output commands to control machines and processes
- Handling communication with HMIs, networked PLCs, and other industrial devices
As the core of the PLC-5 system, it ensures deterministic, high-performance control for demanding industrial automation tasks.
Role in Industrial Automation
The processor is key for:
- Controlling complex manufacturing and process operations
- Coordinating logic, sequencing, and data handling
- Managing communication between controllers, operator interfaces, and networked devices
- Supporting high-reliability systems that require rapid scan times
Industrial Applications
Typical applications include:
- High-speed manufacturing automation systems
- Process control in chemical, oil & gas, and power plants
- Material handling and automated packaging lines
- Networked PLC environments requiring fast response and data processing
- Industrial systems with large numbers of I/O modules
Installation and System Integration
Installation steps:
- Insert the 1785-L20B processor into a PLC-5 rack
- Connect compatible I/O modules and power supply
- Configure using RSLogix 5 or compatible programming software
- Verify input/output functionality, program execution, and network communication
The processor’s industrial-grade design ensures reliable performance in demanding automation environments.
Compatible System Components
- PLC-5 I/O racks and modules
- Allen Bradley communication modules (e.g., 1785-ENET, 1785-BCM)
- Operator interfaces and HMIs
- RSLogix 5 programming software
- Networked PLC-5 or ControlLogix systems
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| Allen Bradley 1785-L20B | PLC Processor | PLC-5/20 high-performance CPU | Complex industrial automation |
| Allen Bradley 1785-L11B/E | PLC Processor | PLC-5/11 enhanced version | Mid-range industrial control |
| Allen Bradley 1785-L40B | PLC Processor | Advanced PLC-5/20 CPU | Large-scale and high-speed industrial systems |
Key Advantages
- High-speed, reliable control for complex PLC-5 applications
- Supports large I/O configurations and fast scan times
- Enables network communication and integration with industrial HMIs
- Compact, rugged design for harsh industrial environments
- Enhances automation efficiency, reliability, and performance
Technical FAQs
What is the main purpose of the 1785-L20B?
It serves as the central processor for PLC-5 systems, providing high-speed logic, sequencing, and I/O control.
Which I/O modules is it compatible with?
Compatible with all PLC-5 I/O racks and modules.
Does it support communication with other devices?
Yes, via Allen Bradley communication modules such as Ethernet or DH+ networks.
Where is it typically applied?
In complex industrial automation, high-speed manufacturing, and process control environments.
Conclusion
The Allen Bradley 1785-L20B PLC-5/20 Processor is a high-performance and reliable CPU for industrial automation systems. With its fast processing, support for large I/O configurations, and network integration, it is ideal for complex PLC-5 applications in manufacturing, process industries, and critical automation networks.
