GE IC694ALG222 Analog Input Module
Product Introduction
The GE IC694ALG222 is a high-density analog input module designed for the Series 90-30 and RX3i PLC platforms. It provides four isolated input channels with 12-bit resolution (up to 14-bit enhanced), configurable for voltage (±10 V, ±5 V, 0–10 V) or current (0–20 mA, 4–20 mA) signals. The module mounts on a standard 34 mm DIN-rail profile and communicates over the high-speed backplane, delivering deterministic data to the PLC for real-time process monitoring and control.
Key Applications
Monitoring pressure, temperature, and level transducers in oil & gas and petrochemical refineries.
Collecting flowmeter signals and batch process control data in chemical manufacturing.
Measuring analog outputs from precision scales and feeders in food & beverage lines.
Reading vibration and condition-monitoring sensors in power generation turbines.
Integrating environmental sensors (humidity, CO₂, pH) in water/wastewater treatment facilities.
Brand Overview
GE Automation & Controls, a division of General Electric, has over 40 years of experience delivering rugged PLC, RTU, and I/O solutions for critical industrial applications. Known for its Series 90-30, RX3i, and PACSystems platforms, GE supports global process and discrete industries with long-lifecycle hardware and comprehensive engineering services.
Product Advantages
-
Channel Isolation: Each of the four inputs is galvanically isolated to 1500 V AC, eliminating ground-loop errors.
-
Signal Flexibility: Auto-ranging and software-selectable input types reduce surplus inventory and simplify commissioning.
-
Enhanced Resolution: Supports 14-bit enhanced mode for improved measurement accuracy in fine-control loops.
-
High Throughput: Samples all channels in <10 ms, ensuring up-to-date data for fast process changes.
-
Robust Design: Operates reliably from –25 °C to +70 °C with conformal-coated PCBs for harsh environments.
Detailed Technical Parameters
| Specification | Details |
|---|---|
| Model Number | IC694ALG222 |
| Channels | 4 isolated analog inputs |
| Resolution | 12-bit native; 14-bit enhanced mode |
| Input Ranges | ±10 V, ±5 V, 0–10 V; 0–20 mA, 4–20 mA |
| Isolation Voltage | 1500 V AC channel-to-bus and channel-to-channel |
| Sampling Time | <10 ms for all channels |
| Accuracy | ±0.1 % full scale |
| Temperature Drift | ±25 ppm/°C |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % RH (non-condensing) |
| Dimensions (W × H × D) | 34 × 145 × 140 mm |
| Weight | 0.29 kg |
| Mounting | DIN-rail or Series 90-30 backplane slot |
Related Models (Same Series / Function)
| Model | Description |
|---|---|
| IC694ALG221 | 8-channel 12-bit analog input module, Series 90-30 |
| IC694ALG223 | Dual-range ±10 V/4–20 mA, 4-channel analog input for RX3i |
| IC694ALG230 | 16-bit isolated analog input module with 8 channels |
| IC694ADC901 | High-density 16-bit analog input with built-in signal conditioning |
| IC694MLC230 | Mixed analog I/O combo module with 4 inputs and 4 outputs |
Popular GE Automation & Controls Models
| Model | Key Features |
|---|---|
| IC695CPU542 | RX3i PAC CPU with 64 MB user memory and high-speed backplane |
| IC695MDL645 | 32-point 24 V DC sink digital input module |
| IC695ALG600 | 4-channel ±10 V/0–20 mA analog output, 16-bit resolution |
| IC695CMM001 | Ethernet communication module for Series 90-30 |
| IC695PWR002 | 24 V DC redundant power supply unit for RX3i and Series 90-30 |
Frequently Asked Questions (FAQ)
Q: What analog ranges does the IC694ALG222 support?
A: Each channel can be set to ±10 V, ±5 V, 0–10 V, 0–20 mA, or 4–20 mA via software configuration.
Q: How precise are the measurements?
A: Native 12-bit resolution yields ±0.1 % FS accuracy; enhanced mode offers up to 14-bit for finer granularity.
Q: Is channel-to-channel isolation provided?
A: Yes, each input is isolated to 1500 V AC from the backplane and from other channels.
Q: How quickly does it sample all channels?
A: All four channels are updated in under 10 ms, ensuring prompt data for fast control loops.
Q: What environmental conditions can it handle?
A: It operates in –25 °C to +70 °C and up to 95 % RH (non-condensing), with conformal coating for corrosion resistance.
Q: Which PLC platforms is it compatible with?
A: It fits Series 90-30 and RX3i backplanes, and can be used in PACSystems where slot-compatible.
Q: How do I mount the module?
A: It installs on a standard 34 mm DIN-rail or in a dedicated backplane slot on Series 90-30 racks.
Q: Can I mix this with other analog modules?
A: Yes, you can combine it with other ALG2xx and ALG6xx series modules in the same rack.
Q: What certifications does it hold?
A: It carries CE, UL, and cUL approvals for industrial control equipment.
Q: How do I achieve enhanced 14-bit resolution?
A: Enable enhanced mode in your PLC’s I/O configuration tool to utilize available extra bits.
