Product Overview
The Allen Bradley 80026-524-01-R Single-Phase AC/DC Power Supply is a high-performance 1500 W industrial switching power supply engineered for PowerFlex 7000 medium-voltage AC drive systems and other industrial automation applications requiring dependable auxiliary DC power. Designed to convert 100–240 VAC single-phase input power into a regulated DC output, the module provides stable power for drive control electronics, protection circuits, communication modules, and auxiliary control devices.
The 80026-524-01-R utilizes advanced switch-mode power conversion technology to achieve high efficiency, excellent voltage regulation, and reliable continuous-duty performance. By maintaining stable DC output under varying electrical loads, the power supply helps ensure uninterrupted operation of automation equipment while reducing the risk of control system failures caused by voltage fluctuations.
Its rugged industrial construction allows reliable operation in environments exposed to electrical noise, vibration, and continuous production cycles. Comprehensive protection features safeguard both the power supply and connected equipment, improving overall system availability and reducing maintenance requirements.
With dimensions of 250 × 150 × 100 mm and an approximate weight of 4.54 kg, the module is suitable for installation inside industrial control cabinets and PowerFlex 7000 drive enclosures.
Typical applications include medium-voltage drive systems, industrial motor control centers, mining equipment, power generation facilities, water treatment plants, petrochemical installations, heavy manufacturing, steel mills, paper production, and other large-scale industrial automation systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 80026-524-01-R |
| Product Type | Single-Phase AC/DC Switching Power Supply |
| Primary Function | Auxiliary DC Power Supply |
| Rated Power | 1500 W |
| Input Voltage | 100–240 VAC, Single Phase, 50/60 Hz |
| Output Voltage | 56 VDC (Regulated) |
| Power Conversion | Switch Mode Power Supply (SMPS) |
| Compatible System | PowerFlex 7000 AC Drive |
| Mounting Method | Panel / Cabinet Mount |
| Cooling Method | Forced Air Cooling |
| Protection Features | Overload, Overvoltage, Short Circuit, Overtemperature Protection |
| Dimensions | 250 × 150 × 100 mm |
| Weight | Approximately 4.54 kg |
Function and Working Principle
The 80026-524-01-R converts incoming single-phase AC power into regulated DC power used by industrial drive control systems and auxiliary electrical circuits.
Typical Power Flow
Single-Phase AC Input
↓
Input Rectifier
↓
Power Factor and Filtering Circuit
↓
High-Frequency Switching Converter
↓
Voltage Regulation
↓
80026-524-01-R Power Supply
↓
PowerFlex 7000 Control Electronics
↓
Industrial Automation Equipment
During operation, the switching controller continuously monitors both the input supply and output load to maintain stable voltage under changing operating conditions.
Primary operating functions include:
- High-efficiency AC/DC power conversion
- Stable regulated DC output
- Auxiliary control power supply
- Voltage regulation
- Continuous industrial operation
- Short-circuit protection
- Overload protection
- Thermal protection
- Electrical isolation
- Improved drive system reliability
These functions provide dependable electrical power for automation equipment while helping reduce unexpected production downtime.
Role in Industrial Control Systems
Within industrial automation systems, the 80026-524-01-R supplies regulated auxiliary DC power for drive control electronics and automation equipment.
Typical automation architecture:
Utility Power
↓
80026-524-01-R AC/DC Power Supply
↓
PowerFlex 7000 Drive
↓
PLC / Drive Controller
↓
Medium-Voltage Motor
↓
Industrial Process
The module ensures that control electronics remain supplied with stable DC power for accurate drive operation and system diagnostics.
Industrial Applications
Medium-Voltage Motor Drive Systems
Typical applications include:
- PowerFlex 7000 AC drives
- Large induction motors
- Synchronous motor systems
- Variable speed applications
- Heavy industrial processes
Mining Industry
Suitable for:
- Crushers
- Conveyors
- Grinding mills
- Hoisting equipment
- Ventilation systems
Oil and Gas Facilities
Frequently installed in:
- Compressor stations
- Pipeline pumping systems
- Offshore platforms
- Refinery process equipment
- Petrochemical plants
Power Generation
Ideal for:
- Boiler feed pumps
- Cooling water pumps
- Induced draft fans
- Generator auxiliary systems
- Plant automation
Water and Wastewater Treatment
Common applications include:
- High-capacity pumping stations
- Aeration blowers
- Filtration systems
- Water distribution
- Industrial treatment facilities
Heavy Manufacturing
Widely used in:
- Steel mills
- Cement plants
- Paper mills
- Chemical processing
- Metal processing facilities
Installation and System Integration
Before installation, engineers should verify:
- Input voltage compatibility
- Cabinet ventilation
- Protective grounding
- Wiring integrity
- Output voltage requirements
- PowerFlex 7000 compatibility
- Environmental conditions
- Cooling airflow
- Electrical protection devices
- Commissioning procedures
Recommended Installation Procedure
- Disconnect all incoming power.
- Mount the power supply securely.
- Connect the single-phase AC input.
- Connect the regulated DC output.
- Verify grounding connections.
- Inspect wiring polarity.
- Restore input power.
- Measure output voltage.
- Verify PowerFlex control operation.
- Test protection functions.
- Monitor operating temperature.
- Complete commissioning documentation.
Proper installation helps maximize equipment reliability and operating life.
Compatible System Components
| Component | Function |
|---|---|
| PowerFlex 7000 AC Drive | Medium-voltage motor control |
| 80026-524-01-R | Auxiliary AC/DC power supply |
| ControlLogix PLC | Central automation controller |
| Industrial HMI | Operator interface |
| EtherNet/IP Communication Module | Industrial networking |
| Medium-Voltage Motor | Mechanical drive |
| Protection Relay | System protection |
| Industrial Control Cabinet | Equipment enclosure |
| Power Distribution Panel | Incoming electrical supply |
| Cooling Fan Assembly | Thermal management |
Recommended Alternative Models
| Model | Product Type | Typical Application |
|---|---|---|
| 80026-524-01-R | 1500 W AC/DC Power Supply | PowerFlex 7000 auxiliary power |
| 80026-524-01 | Single-Phase Power Supply | Industrial automation systems |
| 80026-518-01-R | DC Switching Power Supply | Control circuit power |
| 1606-XLS960E | Industrial Power Supply | General automation |
| 1606-XLS480E | DIN Rail Power Supply | Industrial control panels |
Key Advantages
- High-efficiency 1500 W power conversion
- Stable regulated DC output
- Wide single-phase AC input range
- Reliable continuous-duty performance
- Excellent voltage regulation
- Comprehensive electrical protection
- Rugged industrial construction
- Easy cabinet installation
- Optimized for PowerFlex 7000 systems
- Low maintenance requirements
- Dimensions 250 × 150 × 100 mm
- Approximate weight 4.54 kg
Technical FAQs
What is the Allen Bradley 80026-524-01-R?
The 80026-524-01-R is a 1500 W Single-Phase AC/DC Switching Power Supply designed to provide regulated auxiliary DC power for PowerFlex 7000 drive systems and industrial automation equipment.
What is its primary function?
Its primary function is to convert 100–240 VAC single-phase input into a stable 56 VDC regulated output for drive control electronics and auxiliary circuits.
What are the physical dimensions?
The module measures 250 × 150 × 100 mm.
What is the approximate weight?
The unit weighs approximately 4.54 kg.
Which systems are compatible?
It is primarily designed for Allen Bradley PowerFlex 7000 medium-voltage AC drive systems and compatible industrial automation equipment.
Which industries commonly use this power supply?
It is widely used in mining, oil and gas, power generation, water treatment, steel production, cement manufacturing, chemical processing, paper mills, and other heavy industrial applications.
Does the power supply include protection features?
Yes. It incorporates overload, short-circuit, overvoltage, and overtemperature protection to improve system reliability.
Is it suitable for continuous industrial operation?
Yes. The 80026-524-01-R is engineered for reliable 24/7 operation in demanding industrial environments.
Where is the power supply typically installed?
It is typically installed inside PowerFlex 7000 drive cabinets, industrial electrical enclosures, and motor control systems.
Why is an industrial AC/DC power supply important?
A dedicated industrial AC/DC power supply ensures stable auxiliary power for drive electronics, communication systems, and protection circuits, helping improve equipment reliability, reduce downtime, and support continuous industrial production.
Conclusion
The Allen Bradley 80026-524-01-R Single-Phase AC/DC Power Supply is a dependable 1500 W industrial power conversion module designed for PowerFlex 7000 medium-voltage drive systems. Its high-efficiency switching technology, stable regulated DC output, and comprehensive protection functions provide reliable auxiliary power for critical drive electronics and automation equipment.
With dimensions of 250 × 150 × 100 mm and an approximate weight of 4.54 kg, the 80026-524-01-R integrates easily into industrial drive cabinets and electrical control systems. When combined with compatible PowerFlex 7000 drives, PLCs, HMIs, communication modules, and industrial control equipment, it delivers stable power distribution, improved operational reliability, reduced maintenance requirements, and long-term performance in demanding industrial environments.
