Industrial AC Drive – Model 20G11NC3P5JA0NNNNN
1. Product Overview
The model 20G11NC3P5JA0NNNNN is a compact industrial AC drive designed for low-power motor control applications requiring high precision, stable torque output, and reliable operation. It is typically used in small automation systems where energy efficiency and smooth motor behavior are important.
This drive is optimized for applications involving light mechanical loads such as fans, pumps, and small conveyor systems. It ensures stable motor acceleration and deceleration while reducing mechanical wear and improving system efficiency.
The structure is designed for easy installation inside control cabinets and supports standard industrial integration requirements.
2. Brand & Series Information
Brand: Industrial automation drive manufacturer (U.S.-based power electronics platform)
Series: Compact general-purpose AC drive family (750-class vector control platform)
Product Type: Variable frequency drive (VFD)
Control Method: V/Hz control and sensorless vector control
Voltage Class: 380–480V three-phase supply
3. Technical Parameters
Electrical Performance
| Parameter | Specification |
|---|---|
| Model | 20G11NC3P5JA0NNNNN |
| Rated Output Power | 1.5 kW – 2.2 kW |
| Rated Output Current | 3.5 A |
| Input Voltage | 3-phase 380–480 VAC |
| Output Frequency | 0–590 Hz |
| Control Modes | V/Hz / sensorless vector control |
| Overload Capacity | Up to 150% short-term overload |
| Efficiency | High-efficiency motor drive conversion |
| Braking Support | External braking resistor support |
| Cooling Method | Natural + forced air cooling |
| Protection Functions | Overcurrent, overvoltage, undervoltage, thermal protection |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Height | Approx. 300 mm |
| Width | Approx. 180 mm |
| Depth | Approx. 160 mm |
| Weight | ≈ 3.5 kg |
4. Product Features
This model is designed for compact installations and stable low-power motor control performance.
Key features include:
- Compact structure suitable for tight control cabinet space
- Stable low-speed torque performance for small motors
- Simple parameter setup and fast commissioning
- Energy-efficient operation under light load conditions
- Built-in motor protection and fault detection functions
- Smooth start/stop control to reduce mechanical stress
- Compatible with standard industrial automation systems
- Reliable continuous operation in light-duty environments
5. Application Areas
The drive is widely used in small-scale industrial and automation systems:
- Small conveyor and sorting systems
- HVAC fan and ventilation control systems
- Water circulation pumps and booster pumps
- Light packaging machinery
- Textile auxiliary equipment
- Food processing small machines
- Automated doors and simple mechanical systems
- General factory auxiliary automation
6. Product Advantages
The model provides a strong balance of simplicity, efficiency, and reliability:
- Very compact size suitable for space-limited installations
- Low energy consumption for small motor applications
- Stable performance under variable light loads
- Easy configuration reduces setup time
- Reliable protection system improves equipment safety
- Low maintenance requirement
- Smooth motor operation reduces mechanical wear
- Cost-effective solution for basic industrial control needs
7. Same Series / Related Models (5 Recommendations)
| Model | Key Parameters | Dimensions (mm) | Weight |
|---|---|---|---|
| 20G11GC3P0JA0NNNNN | 1.5 kW, compact low-power drive | 280 × 170 × 150 | ≈ 3.0 kg |
| 20G11GC5P0JA0NNNNN | 2.2 kW, small conveyor applications | 300 × 180 × 160 | ≈ 3.8 kg |
| 20G11NC5P5JA0NNNNN | 2.2–3.0 kW, light industrial control | 320 × 190 × 170 | ≈ 4.2 kg |
| 20G11NC7P5JA0NNNNN | 3.7 kW, medium-light duty systems | 340 × 195 × 175 | ≈ 6.0 kg |
| 20G11NC11P0JA0NNNNN | 5.5 kW, higher light industrial load | 370 × 210 × 185 | ≈ 8.0 kg |
8. Same Brand Popular Models (5 Recommendations)
| Model | Product Type | Key Parameters | Dimensions (mm) | Weight |
|---|---|---|---|---|
| 20F1ANC180JA0NNNNN | Heavy-duty drive | 180A, ~90 kW industrial use | 720 × 280 × 250 | ≈ 40 kg |
| 20F1ANC220JA0NNNNN | Medium-heavy drive | 220A vector control system | 760 × 300 × 260 | ≈ 52 kg |
| 20F1ANC260JA0NNNNN | High-power drive | 260A heavy industrial load | 780 × 300 × 260 | ≈ 55 kg |
| 20F1ANC302JA0NNNNN | High-capacity drive | 302A, large industrial systems | 820 × 320 × 280 | ≈ 68 kg |
| 20G11NC104JA0NNNNN | Mid-power drive | 104A, ~55 kW automation control | 550 × 260 × 230 | ≈ 20 kg |
9. Summary
The 20G11NC3P5JA0NNNNN is a compact industrial AC drive designed for low-power motor applications requiring stable operation, energy efficiency, and simple integration.
Its small size, reliable protection features, and stable motor control make it suitable for a wide range of light industrial automation systems where efficiency and ease of use are more important than high power output.
