Allen-Bradley 1746-NIO4V Detailed Technical Overview
1. Product Overview
The Allen-Bradley 1746-NIO4V is a combination analog I/O module designed for use within the SLC 500 modular PLC system. It integrates both analog input and analog output capabilities into a single module, with a focus on voltage signal processing.
This module provides a total of four channels, typically configured as two analog inputs and two analog outputs. It is specifically designed to handle voltage-based signals, making it suitable for applications where sensors and actuators operate with voltage ranges rather than current loops.
The 1746-NIO4V serves as a compact interface between field devices and the PLC processor, enabling both monitoring and control within a single hardware unit.
2. Brand Information
- Brand: Allen-Bradley
- Industry: Industrial automation and control systems
- Product Type: Analog combination I/O module
The brand is widely recognized in industrial sectors for its durable hardware and stable performance in long-term automation applications.
3. Product Series
- Series: SLC 500
- Category: Analog I/O module
- Module Type: Combination (Voltage Input + Voltage Output)
The SLC 500 platform is a modular control system. The 1746-NIO4V is designed to reduce system complexity by combining analog input and output functions in a single slot, particularly for voltage-based applications.
4. Technical Parameters
Core Specifications Table
| Parameter | Value |
|---|---|
| Model | 1746-NIO4V |
| Module Type | Analog Combination I/O (Voltage) |
| Series | SLC 500 |
| Input Channels | 2 |
| Output Channels | 2 |
| Input Signal Type | Voltage |
| Input Range | ±10 V DC |
| Output Signal Type | Voltage |
| Output Range | ±10 V DC |
| Resolution | 16-bit |
| Conversion Method | Sigma-Delta |
| Input Impedance | ≥1 MΩ |
| Output Load | ≥1 kΩ |
| Backplane Current (5V) | 55 mA |
| Backplane Current (24V) | 145 mA |
| Isolation | 500 V AC |
| Step Response | ~50–100 ms (input), <5 ms (output) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| Dimensions (mm) | 145 × 35 × 140 |
| Weight (kg) | 0.35 kg |
5. Product Functions and Applications
Functional Description
- Converts analog voltage signals from field devices into digital data
- Generates voltage output signals for actuators and control elements
- Enables both signal monitoring and control within one module
- Provides stable signal acquisition with noise filtering
- Supports closed-loop control systems using voltage signals
Typical Applications
- Voltage-based process control systems
- Industrial automation lines with voltage sensors and actuators
- Laboratory and testing equipment
- Motion control systems requiring voltage feedback
- Equipment retrofitting where compact I/O solutions are required
6. Product Advantages
1. Integrated Voltage I/O
Combines voltage input and output in a single module, reducing system hardware requirements.
2. High Precision
16-bit resolution ensures accurate measurement and control of analog signals.
3. Compact Design
Single-slot structure saves space in control cabinets.
4. Stable Signal Performance
Designed for industrial environments with strong noise resistance.
5. Simplified System Architecture
Reduces wiring and configuration complexity by combining functions.
7. Recommended Models (Same Series or Related)
SLC 500 Series Related Modules
| Model | Type | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 1746-NI4 | Analog Input | 4 | Voltage / Current | 145 × 35 × 140 | 0.32 |
| 1746-NI8 | Analog Input | 8 | Voltage / Current | 145 × 35 × 140 | 0.34 |
| 1746-NI16I | Analog Input | 16 | Current | 145 × 35 × 140 | 0.36 |
| 1746-NO4V | Analog Output | 4 | Voltage | 145 × 35 × 140 | 0.33 |
| 1746-NIO4I | Analog I/O | 4 | Current | 145 × 35 × 140 | 0.35 |
