ABB TK802F (3BDM000213R1) Technical Overview
Product Introduction
The ABB TK802F (part number 3BDM000213R1) is an industrial-grade motor protection and control device, part of the TK Series, designed for medium- to high-power motors in industrial applications. It combines robust protection features with efficient motor control, ensuring operational reliability and safety for critical machinery.
The TK802F is particularly suitable for environments that require continuous motor operation under moderate load conditions. Its design allows easy integration into control panels, with a balance of compact size and high performance, making it ideal for industrial processes, pumps, compressors, and conveyor systems.
Product Parameters
| Parameter | Specification |
|---|---|
| Model | TK802F |
| Part Number | 3BDM000213R1 |
| Brand | ABB |
| Series | TK Series |
| Rated Voltage | 400 V AC |
| Rated Current | 20 A |
| Frequency | 50/60 Hz |
| Power Rating | 10 kW |
| Insulation Class | F |
| Protection Class | IP54 |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Dimensions (L × W × H) | 210 × 150 × 120 mm |
| Weight | 5.5 kg |
| Mounting Type | Panel-mounted |
| Connection Type | Screw terminals |
| Mechanical Durability | 10⁶ operations |
| Electrical Durability | 10⁵ operations |
Product Applications
The ABB TK802F is designed for a variety of industrial uses:
-
Motor control for medium-power industrial machines
-
Pumps and compressors in factories
-
Conveyor and material handling systems
-
HVAC systems for industrial buildings
-
Small-scale industrial energy distribution
-
Automated production lines requiring reliable motor protection
Product Advantages
-
Reliable Operation: Designed for continuous industrial duty with minimal downtime.
-
Robust Protection: IP54 protection ensures resistance to dust and water ingress.
-
Energy Efficiency: Optimized for low power loss during operation.
-
Compact Design: Space-saving for integration in medium-sized control panels.
-
Maintenance Friendly: Accessible components allow easy inspection and servicing.
-
Versatile Applications: Suitable for a variety of medium-power motors and industrial machinery.
Related Models in the TK Series
| Model | Rated Voltage | Rated Current | Power Rating | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| TK802D | 400 V AC | 16 A | 8 kW | 200 × 140 × 110 | 4.8 |
| TK802E | 400 V AC | 18 A | 9 kW | 205 × 145 × 115 | 5.0 |
| TK802G | 400 V AC | 25 A | 12 kW | 220 × 155 × 125 | 6.0 |
| TK803F | 400 V AC | 20 A | 10 kW | 210 × 150 × 120 | 5.5 |
| TK804F | 400 V AC | 30 A | 15 kW | 240 × 180 × 140 | 7.5 |
Popular ABB Models
| Model | Rated Voltage | Rated Current | Power Rating | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| ACS355 | 380–480 V AC | 0.5–32 A | 0.25–15 kW | 240 × 120 × 140 | 5.5 |
| ACS580 | 380–480 V AC | 1–250 A | 0.75–250 kW | 400 × 200 × 180 | 12 |
| DSQC630 | 380–480 V AC | 32–250 A | 15–200 kW | 450 × 220 × 200 | 15 |
| PM550 | 400 V AC | 20–80 A | 7.5–30 kW | 280 × 150 × 120 | 6.8 |
| MNS Low Voltage Panel | 400 V AC | 63–4000 A | N/A | Custom | 50–500 |
Frequently Asked Questions (FAQ)
Q1: What is the main function of TK802F?
A1: It provides motor protection and control for medium-power industrial motors.
Q2: What is the protection class?
A2: IP54, protecting against dust ingress and water splashes.
Q3: What are the rated voltage and current?
A3: Rated voltage is 400 V AC, and rated current is 20 A.
Q4: What type of motors can it operate?
A4: Standard AC motors, including induction motors used in medium-power applications.
Q5: How is the device installed?
A5: Panel-mounted using screw terminals.
Q6: What is the operating temperature range?
A6: -20°C to +60°C.
Q7: Is maintenance required?
A7: Minimal maintenance is needed; periodic inspection for dust and connections is sufficient.
Q8: Can it handle overloads or short circuits?
A8: Yes, it is designed to safely handle overloads within rated limits.
Q9: Is TK802F suitable for automation systems?
A9: Yes, it integrates into industrial automation and motor control systems.
Q10: What are the main advantages of TK802F?
A10: Reliable operation, robust protection, energy efficiency, compact design, and maintenance-friendly features make it ideal for medium-power industrial applications.
