Product Overview
The SDCS‑PIN‑51 (3BSE004940R1) is a measurement interface card designed for ABB drive control systems. It collects analog inputs from sensors (such as 4–20 mA or 0–10 V signals) and converts them into accurate data for the drive logic. It is key for precise motor control and stable process operation.
The module is built for industrial conditions, with robust components, electrical noise protection, and extended temperature tolerance. It improves measurement reliability and reduces load on the main control board.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | SDCS‑PIN‑51 (3BSE004940R1) |
| Product Type | Measurement Interface Card |
| Function | Field signal measurement and analog-to-digital conversion |
| Supported Signals | 4–20 mA, 0–10 V |
| Supply Voltage | 24 V DC (typical) |
| Mounting | Rack-mounted card |
| Dimensions (L × W × H) | 100 × 70 × 20 mm |
| Weight | 0.4 kg |
| Operating Temp | –20 °C to +50 °C |
| Storage Temp | –40 °C to +70 °C |
| Communication | RS‑485 / MODBUS (optional) |
| Compatibility | DCS500/DCS600 series drives |
Product Description
The SDCS‑PIN‑51 card provides accurate measurement and interface for analog signals in large drive systems. It enables precise feedback for motor current, voltage, and other sensors, ensuring reliable control. The modular design allows easy maintenance and minimal downtime. It isolates measurement tasks from power and control logic, improving system reliability and performance.
Product Applications
-
Steel mills, rolling mills, and heavy industries.
-
Pumps, compressors, and process control drives.
-
Retrofit and modernization of DCS500/DCS600 systems.
-
Automation systems requiring precise analog monitoring.
-
Marine and heavy machinery applications.
Product Advantages
-
High accuracy for analog signals.
-
Offloads measurement from main control board.
-
Plug-in modular design.
-
Rugged, industrial-grade construction.
-
Supports 4–20 mA and 0–10 V signals.
-
Compatible with DCS500/DCS600 drives.
-
Simplifies maintenance and fault isolation.
-
Compact form factor.
-
Long service life.
-
Enables tighter closed-loop process control.
Brand and Series
-
Brand: ABB
-
Series: DCS Drive Control Series (Measurement Interface Cards)
Related or Same-Series Models
| Model | Product Type | Main Function | Supply Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| SDCS‑PIN‑52 | Measurement Interface Card | Successor/variant | 24 V DC | 100×70×20 | 0.4 |
| SDCS‑PIN‑46 | Pulse Interface Module | Encoder input | 24 V DC | 115×65×22 | 0.33 |
| SDCS‑PIN‑41A | Pulse Interface Module | Dual encoder interface | 24 V DC | 115×65×22 | 0.32 |
| SDCS‑PIN‑4 | Pulse Interface Module | Single encoder input | 24 V DC | 115×65×22 | 0.3 |
| SDCS‑IOB‑23 | I/O Expansion Module | Analog/digital I/O | 24 V DC | 150×100×25 | 0.38 |
Popular ABB Models
| Model | Product Type | Application | Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| ACS580-01-046A-4 | AC Drive | General speed control | 400 V AC | 370×203×200 | 8.2 |
| DCS800-S02-0050-05 | DC Drive | Heavy-duty DC motor | 500 V DC | 425×270×190 | 12.5 |
| ACS880-01-145A-3 | Industrial Drive | Precision control | 400 V AC | 540×270×245 | 15 |
| ACS355-03E-07A3-4 | Compact Drive | Light industry | 400 V AC | 125×70×130 | 1.2 |
| ACS150-03E-02A4-4 | Micro Drive | Small machine control | 400 V AC | 98×70×120 | 1 |
FAQ
Q1: What does SDCS‑PIN‑51 do?
A1: It measures analog signals and converts them for the drive control system.
Q2: Which drives are compatible?
A2: DCS500 and DCS600 series drives.
Q3: Which signals does it support?
A3: 4–20 mA current and 0–10 V voltage signals.
Q4: Weight and dimensions?
A4: 0.4 kg, 100×70×20 mm.
Q5: Can it be replaced easily?
A5: Yes, plug-in module allows fast replacement.
Q6: Operating conditions?
A6: –20 °C to +50 °C, storage –40 °C to +70 °C.
Q7: Communication interface?
A7: Some versions support RS‑485 or MODBUS.
Q8: Benefit of a dedicated measurement card?
A8: Isolates measurement, simplifies maintenance, improves reliability.
Q9: Is it still available?
A9: Yes, widely used for retrofit and maintenance.
Q10: Installation checks?
A10: Ensure compatibility, correct slot, voltage, cooling, and input signal range.
