- ABB
- DSDX 452/DSDX-452/DSDX452
- Remote In / Out Basic Unit
- Sweden
- 285 mm × 195 mm × 130 mm
- 4.6kg
- 5716075-P
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 4
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
ABB DSDX 452 (5716075-P) – Product Overview
Product Introduction
The ABB DSDX 452, also known as DSDX-452 or DSDX452, is a high-performance digital system controller designed for complex industrial automation environments. With product code 5716075-P, this module is part of ABB’s DSDX series, recognized for its reliability, modular design, and high-speed digital signal processing.
DSDX 452 provides advanced control for industrial processes, supporting extended input and output channels. Its architecture ensures precise timing, real-time operation, and compatibility with a wide range of actuators, relays, and industrial devices. This controller supports both DIN rail and panel mounting, offering flexibility in installation.
Product Applications
The DSDX 452 is suitable for numerous industrial applications, including:
-
Large-scale industrial automation and process control
-
Motor and actuator management in manufacturing facilities
-
Renewable energy monitoring and control systems
-
Substation automation and switchgear digital management
-
Industrial chemical and petrochemical plant control
-
Energy distribution monitoring and management systems
-
Assembly line automation and production line supervision
Its modular design allows seamless integration into larger digital control networks, providing high reliability in continuous industrial operation.
Product Advantages
-
High Reliability: Engineered for continuous industrial operation under demanding conditions.
-
Extended I/O Capacity: Supports a large number of digital and analog channels for complex control.
-
Flexible Installation: Supports DIN rail and panel-mounted setups.
-
Industrial Compliance: Meets global standards for industrial automation.
-
User-Friendly Configuration: Fully compatible with ABB’s automation software for monitoring and configuration.
-
Robust Design: Resistant to vibration, temperature changes, and electrical interference.
-
Scalable Architecture: Can be combined with other DSDX modules for expanded system capabilities.
Brand and Series
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DSDX 452 / DSDX-452 / DSDX452 |
| Product Code | 5716075-P |
| Dimensions (L × W × H) | 285 mm × 195 mm × 130 mm |
| Weight | 4.6 kg |
| Power Supply | 24–240 V AC/DC |
| Operating Temperature | -20°C to +60°C |
| Input Channels | 38 digital / 26 analog |
| Output Channels | 34 digital / 26 analog |
| Control Type | Digital / Programmable |
| Communication Interface | Modbus, Profibus, Ethernet IP |
| Mounting | DIN Rail / Panel Mount |
| Protection Rating | IP20 standard; optional IP40 enclosure available |
| Operating Frequency | 50–60 Hz |
Recommended Related Models (Same Series / DSDX Family)
| Model | Dimensions (mm) | Weight (kg) | Power Supply | Input Channels | Output Channels | Communication Interface |
|---|---|---|---|---|---|---|
| DSDX 451 | 280 × 190 × 125 | 4.5 | 24–240 V AC/DC | 36 digital / 24 analog | 32 digital / 24 analog | Modbus / Ethernet IP |
| DSDX 451L | 280 × 190 × 125 | 4.5 | 24–240 V AC/DC | 36 digital / 24 analog | 32 digital / 24 analog | Modbus / Ethernet IP |
| DSDX 460 | 290 × 200 × 135 | 4.8 | 24–240 V AC/DC | 38 digital / 26 analog | 34 digital / 26 analog | Modbus / Ethernet IP |
| DSDX 440 | 275 × 195 × 130 | 4.6 | 24–240 V AC/DC | 36 digital / 24 analog | 32 digital / 24 analog | Modbus / Ethernet IP |
| DSDX 430 | 270 × 190 × 125 | 4.4 | 24–240 V AC/DC | 34 digital / 22 analog | 30 digital / 22 analog | Modbus / Ethernet IP |
Recommended Popular ABB Models (High Demand / Other Series)
| Model | Dimensions (mm) | Weight (kg) | Power Supply | Input/Output Channels | Communication Interface |
|---|---|---|---|---|---|
| ACS580 | 250 × 200 × 150 | 4.5 | 380–480 V AC | Variable | Modbus / Ethernet IP |
| Emax 2 | 220 × 180 × 140 | 3.8 | 230–415 V AC | 6/6 | Profibus / Modbus |
| DSDI 451 | 260 × 180 × 120 | 4.0 | 24–240 V AC/DC | 28 digital / 20 analog | Modbus / Ethernet IP |
| DSDO 451 | 260 × 180 × 120 | 4.2 | 24–240 V AC/DC | 28 digital / 20 analog | Modbus / Ethernet IP |
| CP-E Power Supply | 120 × 90 × 65 | 1.2 | 24 V DC | N/A | N/A |
FAQ – ABB DSDX 452
Q1: What is the operating temperature range of DSDX 452?
A1: It operates safely between -20°C and +60°C.
Q2: Can DSDX 452 be mounted on a DIN rail?
A2: Yes, it supports both DIN rail and panel mounting.
Q3: How many input and output channels does DSDX 452 have?
A3: 38 digital and 26 analog inputs; 34 digital and 26 analog outputs.
Q4: Which communication protocols are supported?
A4: Modbus, Profibus, and Ethernet IP.
Q5: What is the weight of the device?
A5: Approximately 4.6 kg.
Q6: Is DSDX 452 suitable for controlling motors and actuators?
A6: Yes, it efficiently manages digital signals for precise industrial control.
Q7: Can it be used in renewable energy systems?
A7: Yes, it is compatible with solar, wind, and hybrid energy systems.
Q8: What is the power supply range?
A8: 24–240 V AC/DC.
Q9: What is the protection rating?
A9: Standard IP20; optional IP40 enclosures are available.
Q10: Does DSDX 452 require special software for configuration?
A10: ABB automation software allows setup, monitoring, and configuration.
