ABB DSDP 160 (57160001-KG) – Product Overview
Product Introduction
The ABB DSDP 160, also referred to as DSDP160, is a high-capacity digital system processor designed for advanced industrial automation and precise digital control. Identified by the product code 57160001-KG, this module is part of ABB’s DSDP series, engineered for robust performance in complex industrial environments.
DSDP 160 functions as a central processing unit for digital input and output operations, handling large volumes of data with high-speed accuracy. It is ideal for integration into industrial control systems, supporting panel and DIN rail mounting, and providing reliable operation under continuous industrial workloads. The module ensures precise control of actuators, motors, relays, and other connected equipment, making it a versatile choice for mission-critical applications.
Product Applications
The DSDP 160 module is suitable for a wide range of industrial and automation applications:
-
Industrial process automation and monitoring systems
-
Control of motors, actuators, and relays in machinery
-
Renewable energy applications including wind and solar plants
-
Substation automation and switchgear control
-
Energy management and distribution systems
-
Industrial machinery requiring high-speed, precise digital processing
Its advanced processing capabilities and robust design make it suitable for high-demand and critical industrial applications.
Product Advantages
-
High Reliability: Designed for continuous operation in demanding environments.
-
High-Performance Digital Processing: Fast and accurate management of multiple input/output channels.
-
Flexible Installation: Supports panel or DIN rail mounting.
-
Industrial Compliance: Meets global safety and operational standards for industrial automation.
-
User-Friendly Configuration: ABB software allows easy setup, monitoring, and maintenance.
-
Durable Design: Resistant to vibration, temperature changes, and electrical interference.
-
Multi-Channel Support: Capable of processing large numbers of input and output channels efficiently.
Brand and Series
-
Brand: ABB
-
Series: DSDP Series (Digital System Digital Processor)
-
Product Code: 57160001-KG
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DSDP 160 / DSDP160 |
| Product Code | 57160001-KG |
| Dimensions (L × W × H) | 230 mm × 155 mm × 105 mm |
| Weight | 3.0 kg |
| Power Supply | 24–240 V AC/DC |
| Operating Temperature | -20°C to +60°C |
| Input Channels | 20 digital / 12 analog |
| Output Channels | 18 digital / 12 analog |
| Control Type | Digital / Programmable |
| Communication Interface | Modbus, Profibus, Ethernet IP |
| Mounting | DIN Rail / Panel Mount |
| Protection Rating | IP20 standard; optional IP40 enclosure available |
| Operating Frequency | 50–60 Hz |
Recommended Related Models (Same Series / DSDP Family)
| Model | Dimensions (mm) | Weight (kg) | Power Supply | Input Channels | Output Channels | Communication Interface |
|---|---|---|---|---|---|---|
| DSDP 150 | 220 × 150 × 100 | 2.7 | 24–240 V AC/DC | 18 digital / 10 analog | 16 digital / 10 analog | Modbus / Ethernet IP |
| DSDP 140B | 210 × 145 × 95 | 2.4 | 24–240 V AC/DC | 16 digital / 8 analog | 14 digital / 8 analog | Modbus / Ethernet IP |
| DSDP 140A | 210 × 145 × 95 | 2.4 | 24–240 V AC/DC | 16 digital / 10 analog | 12 digital / 8 analog | Modbus / Ethernet IP |
| DSDP 135B | 205 × 145 × 95 | 2.3 | 24–240 V AC/DC | 16 digital / 10 analog | 12 digital / 8 analog | Modbus / Ethernet IP |
| DSDP 130B | 200 × 140 × 90 | 2.2 | 24–240 V AC/DC | 16 digital / 8 analog | 12 digital / 8 analog | Modbus / Ethernet IP |
Recommended Popular ABB Models (High Demand / Other Series)
| Model | Dimensions (mm) | Weight (kg) | Power Supply | Input/Output Channels | Communication Interface |
|---|---|---|---|---|---|
| ACS580 | 250 × 200 × 150 | 4.5 | 380–480 V AC | Variable | Modbus / Ethernet IP |
| Emax 2 | 220 × 180 × 140 | 3.8 | 230–415 V AC | 6/6 | Profibus / Modbus |
| DSDI 130 | 200 × 140 × 90 | 2.2 | 24–240 V AC/DC | 12 relay / 8 analog | Modbus / Ethernet IP |
| DSDO 131 | 210 × 145 × 95 | 2.3 | 24–240 V AC/DC | 14 relay / 8 analog | Modbus / Ethernet IP |
| CP-E Power Supply | 120 × 90 × 65 | 1.2 | 24 V DC | N/A | N/A |
FAQ – ABB DSDP 160
Q1: What is the operating temperature range of DSDP 160?
A1: The device operates safely between -20°C and +60°C.
Q2: Can DSDP 160 be mounted on a DIN rail?
A2: Yes, it supports both DIN rail and panel mounting.
Q3: How many input and output channels does DSDP 160 have?
A3: 20 digital and 12 analog inputs; 18 digital and 12 analog outputs.
Q4: Which communication protocols are supported?
A4: Modbus, Profibus, and Ethernet IP.
Q5: What is the weight of the device?
A5: Approximately 3.0 kg.
Q6: Is DSDP 160 suitable for controlling motors and actuators?
A6: Yes, it efficiently processes digital signals for precise control.
Q7: Can it be used in renewable energy systems?
A7: Yes, it is compatible with solar, wind, and hybrid energy systems.
Q8: What is the power supply range?
A8: 24–240 V AC/DC.
Q9: What is the protection rating?
A9: Standard IP20; optional IP40 enclosures are available.
Q10: Does DSDP 160 require special software for configuration?
A10: ABB automation software allows easy setup, monitoring, and configuration.
