Product Technical Profile – ABB BAMU-11 (3AUA0000109935 / 3AUA0000109935-D)
1) Brand and Series Overview
Brand: ABB
Series: BAMU Series – Base Analog Measurement Units
The BAMU Series consists of modular analog measurement and signal conditioning units developed for industrial automation and drive systems. These modules are engineered to provide reliable analog input/output processing, signal isolation, and monitoring functions within control cabinets and automation panels.
The BAMU-11 model is positioned as a high-stability analog measurement module within the series, supporting precise signal acquisition and transmission for industrial control environments. The “-D” version typically indicates a minor hardware revision or design update while maintaining functional compatibility.
2) Product Overview
The ABB BAMU-11 (3AUA0000109935 / 3AUA0000109935-D) is an industrial analog measurement and interface module designed for accurate acquisition, isolation, and transmission of analog signals. It acts as a bridge between field-level instrumentation (such as pressure transmitters, flow meters, and temperature sensors) and higher-level automation systems including PLCs and distributed control systems.
This module ensures signal accuracy, electrical isolation, and operational stability in environments exposed to electrical noise, voltage fluctuations, and varying temperature conditions. Its compact DIN rail-compatible design enables efficient integration into existing control cabinets without significant structural modifications.
BAMU-11 is commonly used in industrial automation systems requiring dependable analog signal monitoring and control loop support.
3) Technical Parameters
| Parameter | Specification |
|---|---|
| Model | BAMU-11 (3AUA0000109935 / 3AUA0000109935-D) |
| Rated Supply Voltage | 24 V DC |
| Operating Voltage Range | 18–30 V DC |
| Input Signal Types | 4–20 mA / 0–10 V |
| Output Signal Types | 4–20 mA / 0–10 V |
| Number of Channels | 2 Analog Channels |
| Signal Accuracy | ±0.3% Full Scale |
| Isolation Voltage | 1500 V AC |
| Response Time | ≤ 5 ms |
| Power Consumption | ≤ 3 W |
| Protection Class | IP20 |
| Mounting | DIN Rail (35 mm) |
| Operating Temperature | −20 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Cooling Method | Natural convection |
| Terminal Type | Screw clamp |
| Dimensions (H × W × D) | 110 × 45 × 120 mm |
| Weight (kg) | 0.32 kg |
| Housing Material | Flame-retardant industrial polymer |
4) Product Description
The BAMU-11 module is designed to provide stable analog measurement and signal processing capabilities in industrial control systems. It supports dual-channel analog input and output, making it suitable for systems that require simultaneous monitoring of multiple process variables.
Each channel is electrically isolated to prevent signal interference and protect connected control equipment. The module’s high accuracy (±0.3% FS) ensures reliable data transmission in closed-loop control systems.
Its housing is optimized for DIN rail installation in industrial cabinets, offering easy integration with minimal wiring complexity. Clear terminal markings and structured layout simplify installation and maintenance procedures.
The updated “-D” version maintains full compatibility with standard BAMU-11 installations while incorporating minor design improvements for enhanced durability.
5) Key Advantages
High Measurement Accuracy
Ensures reliable signal transmission in sensitive industrial control loops.
Dual-Channel Capability
Supports simultaneous processing of two independent analog signals.
Galvanic Isolation
Protects control systems from ground loops and voltage spikes.
Compact Cabinet Integration
Slim housing optimizes panel space usage.
Low Power Consumption
Reduces internal cabinet heat and improves overall system efficiency.
Industrial-Grade Durability
Designed for stable operation across wide temperature ranges.
Maintenance-Friendly Layout
Clear labeling and accessible terminals support fast troubleshooting.
6) Typical Applications
• Process automation in manufacturing plants
• Industrial motor and drive systems monitoring
• Water treatment and wastewater management control
• HVAC system analog monitoring
• Power generation auxiliary systems
• Oil and gas instrumentation panels
• Distributed control system (DCS) interfaces
• Energy monitoring systems
7) Five Related Models (BAMU Series or Similar Modules)
| Model | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| BAMU-01C | 1 | 4–20 mA / 0–10 V | 100 × 45 × 115 | 0.26 |
| BAMU-02C | 1 | Voltage to Current | 100 × 45 × 115 | 0.28 |
| BAMU-03C | 2 | 4–20 mA | 110 × 45 × 120 | 0.33 |
| BAMU-12 | 2 | 0–10 V | 110 × 45 × 120 | 0.34 |
| BAMU-15 | 3 | Multi-range Analog | 120 × 50 × 125 | 0.40 |
8) Five Popular Models (Same Brand)
| Model | Product Type | Main Rating | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS580-01-12A6-4 | Variable Frequency Drive | 5.5 kW | 358 × 152 × 203 | 6.5 |
| ACS880-01-017A-4 | Drive Inverter | 17 kW | 220 × 120 × 180 | 3.6 |
| Emax 2 E1.6 | Air Circuit Breaker | 1600 A | 280 × 140 × 160 | 6.0 |
| Tmax XT3 | Molded Case Circuit Breaker | 400 A | 140 × 80 × 100 | 1.8 |
| AF16-30-10 | Contactor | 16 A | 90 × 55 × 78 | 0.42 |
9) Frequently Asked Questions (FAQ)
Q1: What is the primary function of BAMU-11?
A1: It is used for analog signal measurement, conditioning, and transmission within industrial automation systems.
Q2: How many channels does BAMU-11 support?
A2: It supports two independent analog channels.
Q3: What supply voltage is required?
A3: The module operates on a nominal 24 V DC supply.
Q4: What signal types are supported?
A4: It supports 4–20 mA and 0–10 V analog formats.
Q5: Does it provide electrical isolation?
A5: Yes, it includes galvanic isolation between input and output circuits.
Q6: What environments is it suitable for?
A6: It is designed for indoor industrial control cabinets with moderate temperature variations.
Q7: What distinguishes the -D version?
A7: The -D version reflects a design update while maintaining compatibility with the original model.
Q8: Can it integrate with PLC systems?
A8: Yes, it interfaces directly with PLC and DCS analog input/output modules.
Q9: What is the installation method?
A9: It is mounted on a standard 35 mm DIN rail.
Q10: What routine maintenance is required?
A10: Periodic inspection of terminal tightness and cabinet ventilation is typically sufficient.
