ABB AI610 3BHT300000R1 Analog Input Module Detailed Overview

Product Introduction

The ABB AI610 3BHT300000R1 is a high-performance analog input module designed for use in industrial automation systems. As part of the ABB AC 800M series, this module offers a reliable and flexible solution for the acquisition of analog signals in various process control applications. With the ability to convert input signals from devices like sensors, transmitters, and other field instruments, the AI610 module plays a crucial role in accurately capturing and transmitting analog data to control systems, enabling efficient process monitoring and control.

The AI610 3BHT300000R1 module is built to handle 0-20 mA and 4-20 mA current loop inputs, as well as 0-10 V and -10 to +10 V voltage inputs. This versatility makes it suitable for a wide range of industrial applications, from manufacturing and process control to energy and utility systems. With its 252 x 273 x 40 mm compact size and 1.21 kg weight, the module offers a robust design while ensuring easy integration into existing systems.

Product Specifications

Product Applications

The ABB AI610 3BHT300000R1 analog input module is designed for a wide range of applications across various industries, including:

• Industrial Automation: The module is commonly used in automation systems to acquire analog data from field devices, such as temperature sensors, pressure transmitters, and flow meters. It helps process controllers make accurate decisions based on real-time analog signals.

• Process Control Systems: In chemical plants, oil refineries, and power generation facilities, this module facilitates precise monitoring of process variables like temperature, pressure, and flow, which are essential for maintaining optimal process conditions.

• Building Automation: It is also used in building management systems to acquire data from sensors monitoring variables like HVAC systems, air quality, and lighting levels.

• Energy and Utilities: The AI610 module is integral in energy and utility sectors, particularly in monitoring power generation, distribution systems, and water treatment plants, ensuring that critical systems remain within operational parameters.

• Manufacturing: The module plays a crucial role in collecting data from industrial machines, helping to monitor their health and performance, contributing to predictive maintenance and efficiency improvements.

• Test and Measurement: The AI610 is often used in laboratories or test environments to collect analog signals from various instruments for precise analysis and calibration.

Product Advantages

1. High Accuracy and Precision: The AI610 module offers an accuracy of ±0.1% of full scale, making it suitable for precise applications requiring reliable signal processing.

2. Wide Input Range Compatibility: This module supports a variety of input types, including 0-20 mA, 4-20 mA, and 0-10 V signals, ensuring flexibility in connecting different field devices.

3. Compact Design: With dimensions of 252 x 273 x 40 mm and a weight of 1.21 kg, it provides a compact solution that fits easily into standard control cabinets.

4. High Channel Count: The module features 8 channels for analog signal inputs, making it ideal for applications that require multiple signals to be processed simultaneously.

5. Robust Temperature Range: With an operating temperature range from -20°C to +60°C, the module is designed for use in various industrial environments, even those with harsh conditions.

6. Seamless Integration: Compatible with popular industrial communication protocols like MODBUS and HART, making it easy to integrate into existing control and automation systems.

7. Fast Response Time: With a response time of < 10 ms, the module provides quick and reliable updates, ensuring that real-time data is processed without delays.

8. DIN Rail Mounting: The module is designed for easy installation on DIN rails, simplifying the setup and integration process in industrial control panels.

Brand Information

• Brand: ABB

• Product Type: Analog Input Module

• Industry Focus: Industrial Automation, Process Control, Energy, Manufacturing, Test & Measurement

Recommended Models: ABB AI Series and Related
