ABB AI610 Product Overview, Specifications, Applications, and FAQs

1. Product Overview

The ABB AI610 (Part Number: 3BHT300000R1) is a high-performance analog input module designed for industrial automation systems. It is part of ABB’s AC800M series, a robust and flexible range of I/O modules for industrial control. The AI610 module is built to collect, convert, and process analog signals from a variety of field devices, including sensors and transducers. It features 16 analog input channels, allowing it to handle multiple measurement points simultaneously.

With its high resolution and fast sampling rate, the AI610 is ideal for applications requiring precise monitoring of temperature, pressure, flow, and level measurements, among others. It supports a wide range of input signal types, including voltage and current, ensuring broad compatibility with various industrial sensors.

The AI610 provides a reliable and accurate solution for real-time data collection, ensuring optimal performance in automated control systems across numerous industries.

2. Product Specifications

3. Product Description

The ABB AI610 is a versatile and highly reliable analog input module that offers high-precision data acquisition for industrial automation systems. With 16 input channels and the capability to measure both voltage (0-10 V) and current (4-20 mA), it can handle a wide range of industrial sensors. The module has a 16-bit resolution, ensuring accurate signal conversion and precise monitoring for real-time control.

One of the standout features of the AI610 is its sampling rate of up to 250 Hz per channel, allowing for fast data acquisition and timely updates in automation systems. This feature is particularly beneficial for applications requiring quick responses to changing conditions, such as process control or real-time monitoring.

The AI610 also supports Modbus TCP and Ethernet/IP communication protocols, which makes it easy to integrate with other control systems, such as SCADA and PLC systems, as well as communicate with field devices and sensors in a distributed networked environment. The DIN rail mounting ensures easy installation and space-efficient setup.

Key Features:

• Multiple Input Types: Supports both voltage and current input signals, making it suitable for a variety of sensor applications.

• High Precision: With a 16-bit resolution and ±0.1% FS accuracy, the AI610 ensures high-quality measurements.

• Fast Data Acquisition: A sampling rate of 250 Hz per channel provides real-time data collection for responsive control.

• Wide Operating Range: The AI610 can operate in temperatures ranging from -25°C to +70°C, making it adaptable to challenging environments.

• Seamless Integration: Supports Modbus TCP and Ethernet/IP, which simplifies integration into existing automation systems.

• Durable Design: DIN rail mounting and IP20 protection ensure durability and easy installation.

4. Product Applications

The ABB AI610 is suitable for a wide range of industrial applications where precise and reliable analog data acquisition is essential. Some common use cases include:

• Process Control: Used for monitoring and controlling industrial processes in manufacturing, chemical, and power generation plants by acquiring data from sensors measuring parameters like temperature, pressure, and flow.

• Machine Control: The AI610 monitors signals from sensors in automated machines, providing data for machine control systems that ensure efficient and safe operation.

• Building Automation: In HVAC systems, lighting control, and energy management, the AI610 is used to collect data from environmental sensors for energy-efficient building operation.

• Energy Management: The module can collect data from energy meters, voltage, and current transducers, providing critical information for managing electrical systems in industrial plants.

• Test and Measurement Systems: In laboratories and test setups, the AI610 ensures accurate data acquisition for calibration and testing purposes.

5. Product Advantages

The ABB AI610 offers several key advantages:

• High Accuracy: The 16-bit resolution and ±0.1% FS accuracy ensure precise signal conversion, which is crucial for applications that rely on accurate data for control decisions.

• Wide Input Signal Compatibility: Supports both voltage (0–10 V) and current (4–20 mA) inputs, making the AI610 highly adaptable to a wide range of industrial sensors.

• Real-Time Data Acquisition: With a sampling rate of 250 Hz per channel, the AI610 provides rapid updates to control systems, ensuring that industrial operations run smoothly and respond promptly to changes.

• Easy Integration: The support for Modbus TCP and Ethernet/IP communication protocols makes the AI610 easily integrable into modern automation networks, including SCADA and PLC systems.

• Versatile Mounting: DIN rail mounting provides a straightforward installation method that saves space and makes it suitable for industrial control panels.

6. Brand and Product Series

The AI610 is part of ABB’s AC800M I/O system, known for its flexibility and scalability in industrial control applications. This series is designed for industries requiring high-performance control and data acquisition, with a focus on reliability, accuracy, and easy integration.
