ABB 5STP1752H000 – Product Overview
1. Product Introduction
The ABB 5STP1752H000 is a high-performance Insulated Gate Bipolar Transistor (IGBT) power module designed for medium to high-power industrial applications. It delivers efficient and reliable power switching, optimized for use in motor drives, inverters, and power converters. This model is part of ABB’s 5STP series, known for its robustness and advanced semiconductor technology.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 5STP1752H000 |
| Type | IGBT Power Module |
| Voltage Rating (V) | 1700 V (Collector-Emitter Voltage) |
| Current Rating (A) | 1200 A (Collector Current) |
| Continuous Collector Current | 1200 A |
| Surge Current (A) | 24,000 A (Peak Surge) |
| Gate-Emitter Voltage | ±20 V |
| Switching Frequency | Up to 10 kHz |
| Package Type | Press-pack Module |
| Mounting | Pressure contact mounting |
| Dimensions (mm) | 180 x 140 x 80 |
| Weight (kg) | 1.8 |
| Operating Temperature | –40°C to +125°C |
| Thermal Resistance (Junction to Case) | 0.10 °C/W |
3. Applications
-
Industrial Motor Drives: Designed for use in medium and large motor drives for industries such as manufacturing and processing.
-
Renewable Energy Systems: Suitable for wind turbines and solar inverters due to high efficiency and reliability.
-
Traction Systems: Used in electric trains and trams for effective power control.
-
Power Converters: Ideal for industrial power converters requiring robust switching capabilities.
-
Uninterruptible Power Supplies (UPS): Provides reliable switching for power backup systems.
4. Key Advantages
-
High Power Density: Delivers high current capacity in a compact form factor.
-
Low Switching Losses: Advanced IGBT technology reduces power loss and improves efficiency.
-
Robust Construction: Press-pack design ensures durability under harsh operating conditions.
-
Wide Operating Temperature Range: Reliable performance from –40°C to +125°C.
-
Fast Switching Capability: Supports high-frequency switching up to 10 kHz.
-
Easy Integration: Standardized package and mounting simplify installation and replacement.
5. Brand and Series
-
Brand: ABB
-
Series: 5STP Series – Press-pack IGBT Modules
6. Related or Compatible Models
| Model | Description |
|---|---|
| 5STP1500H120 | IGBT module with 1500 V, 1200 A rating |
| 5STP2100H120 | Higher current IGBT module, 2100 A, 1700 V |
| 5STP1750H120 | Similar voltage rating, slightly lower current |
| 5STP1400H120 | Lower voltage module for medium power applications |
| 5STP2000H120 | High current press-pack module, 2000 A |
7. Popular ABB Models
| Model | Type | Key Parameters |
|---|---|---|
| 5STP2100H120 | Press-pack IGBT Module | 1700 V, 2100 A |
| 5SDF0460F0001 | Diode Module | 1600 V, 4600 A |
| 5SDF1045H0002 | IGBT Module | 3300 V, 1045 A |
| 5SHX0845F0001 | IGCT Module | 4500 V, 840 A |
| 5SDF1750H120 | High Power IGBT | 1700 V, 1750 A |
8. FAQ – Frequently Asked Questions
Q1: What type of semiconductor device is the 5STP1752H000?
A1: It is an Insulated Gate Bipolar Transistor (IGBT) power module designed for high power applications.
Q2: What are the voltage and current ratings of this module?
A2: It has a voltage rating of 1700 V and a continuous current rating of 1200 A.
Q3: What are the physical dimensions and weight?
A3: Dimensions are 180 mm x 140 mm x 80 mm, and it weighs approximately 1.8 kg.
Q4: What applications is this IGBT module best suited for?
A4: It is ideal for motor drives, renewable energy systems, traction, power converters, and UPS systems.
Q5: What is the maximum operating temperature for this module?
A5: The maximum operating temperature is +125°C, with a lower limit of –40°C.
Q6: What mounting method does the 5STP1752H000 use?
A6: It uses a press-pack pressure contact mounting method for reliable electrical and thermal contact.
Q7: Does this module support high switching frequencies?
A7: Yes, it supports switching frequencies up to 10 kHz, suitable for fast dynamic applications.
Q8: How does the press-pack design benefit the module?
A8: Press-pack design offers improved mechanical stability, ease of maintenance, and superior thermal management.
Q9: What cooling methods are recommended?
A9: External cooling via heat sinks and forced air or liquid cooling is recommended to maintain optimal temperatures.
Q10: Is this module compatible with other ABB IGBT modules?
A10: Yes, it is compatible within the 5STP series and can often be integrated with related ABB power electronics systems.
