Product Overview
The Allen-Bradley 77158-008-51 Mounting Clip Kit is a mechanical installation accessory used primarily for securing Allen-Bradley PanelView Plus HMI terminals in industrial control panels. It provides a stable and vibration-resistant mounting solution, ensuring proper mechanical fixation of the HMI to the enclosure cutout.
This kit is typically supplied as a set of clips used during panel installation or replacement of operator interfaces in automation systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Model | 77158-008-51 |
| Product Type | Mounting Clip Kit |
| Application | Panel mounting for HMI terminals |
| Compatible Systems | PanelView Plus series (various sizes) |
| Function | Mechanical fastening of HMI to panel cutout |
| Material | Industrial-grade metal alloy (clip construction) |
| Installation Type | Screw-tightened panel mounting |
| Kit Contents | Multiple mounting clips (typically set of 4) |
| Dimensions | 65 × 15 × 30 mm |
| Weight | 0.09 kg |
Function and Working Principle
The 77158-008-51 kit is a pure mechanical retention system designed to:
- Secure PanelView terminals into panel cutouts
- Apply uniform clamping force across the HMI bezel
- Maintain gasket compression for environmental sealing
- Prevent vibration-induced loosening in industrial environments
- Ensure long-term stability of operator interface installations
The clips are tightened using screws, which pull the terminal tightly against the enclosure surface.
Role in Industrial Control Systems
Although it is not an electronic module, the mounting clip kit plays an important role in system reliability:
- Ensures stable operation of operator interfaces
- Maintains environmental sealing (dust, moisture protection)
- Prevents mechanical stress on display terminals
- Supports safe and compliant panel installations
- Reduces downtime during HMI servicing or replacement
Industrial Applications
The Allen-Bradley 77158-008-51 is commonly used in:
- Factory automation control panels
- Power distribution and monitoring systems
- Oil and gas control rooms
- Chemical and process industry HMIs
- Water treatment and pumping stations
- Manufacturing and machine control systems
Installation and System Integration
For proper installation:
- Position HMI terminal in panel cutout
- Insert mounting clips into designated slots
- Tighten screws evenly in sequence
- Ensure gasket compression is uniform
- Avoid over-tightening to prevent bezel damage
- Perform final sealing inspection after installation
Compatible System Components
The 77158-008-51 kit is typically used with:
- Allen-Bradley PanelView Plus HMIs
- Panel cutout enclosures
- Industrial sealing gaskets
- HMI communication modules (Ethernet, serial systems)
- Control panel mounting hardware
Recommended Alternative Models
| Model | Product Type | Key Feature | Application |
|---|---|---|---|
| 77158-008-51 | Mounting Clip Kit | Standard HMI mounting solution | PanelView Plus systems |
| 2711P-RMTC | Replacement mounting kit | HMI retention system | PanelView installations |
| 2711P bezel kits | HMI housing components | Mechanical support parts | Operator interface systems |
| Universal HMI mounting kits | Generic panel clips | Cross-brand compatibility | Industrial HMI panels |
Key Advantages
- Secure and stable HMI mounting
- Ensures proper sealing against dust and moisture
- Vibration-resistant design for industrial environments
- Simple installation and replacement
- Improves reliability of operator interfaces
- Compatible with multiple PanelView configurations
- Durable metal construction for long service life
Technical FAQs
What is the main function of the 77158-008-51 kit?
It mechanically secures PanelView HMI terminals into a panel cutout.
Does it contain electronic components?
No. It is a purely mechanical mounting accessory.
How many clips are included?
Typically supplied as a set of four mounting clips.
Where is it used?
In industrial automation panels using Allen-Bradley PanelView Plus HMIs.
Conclusion
The Allen-Bradley 77158-008-51 Mounting Clip Kit is a critical installation accessory that ensures secure, stable, and sealed mounting of HMI terminals in industrial control systems. While simple in design, it plays an essential role in maintaining the mechanical integrity and reliability of operator interface installations.
