Product Overview
The Allen Bradley 2711P-T15C4D9 is a PanelView Plus 6 1500 series HMI (Human–Machine Interface) designed for industrial automation applications.
It features a 15-inch color touchscreen display and provides operators with visual monitoring, control, and data entry capabilities. This model is part of the PanelView Plus 6 generation, widely used in existing industrial plants where robustness and reliability are critical.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Rockwell Automation (Allen Bradley) |
| Model | 2711P-T15C4D9 |
| Product Type | PanelView Plus 6 1500 HMI |
| Display Size | 15-inch color TFT |
| Resolution | 1024 × 768 (XGA) |
| Dimensions | 416 × 65 × 330 mm |
| Weight | 4.2 kg |
| Touch Type | Analog resistive touchscreen |
| Communication Ports | Ethernet, RS-232, USB |
| Power Supply | 18–30V DC |
| Operating System | Windows CE embedded |
| Enclosure Rating | Industrial IP/NEMA-rated front panel |
Function and Working Principle
The 2711P-T15C4D9 serves as a graphical interface between operators and PLCs:
- Connects to ControlLogix or CompactLogix PLCs via Ethernet or serial ports.
- Displays real-time process data, alarms, trends, and machine status.
- Allows operators to input control commands, adjust setpoints, and interact with automation systems.
- Applications are deployed using FactoryTalk View Machine Edition (ME) software.
It does not directly execute control logic; it relies on the PLCs for process execution.
Key Features
- Large 15-inch touchscreen for enhanced visibility
- Rugged construction for industrial environments
- Supports EtherNet/IP and serial communication
- USB ports for application transfer and maintenance
- Reliable Windows CE-based embedded system
- Designed for continuous operation on the factory floor
Industrial Applications
- Assembly line monitoring and control
- Packaging machinery HMI
- Oil and gas process systems
- Power generation control panels
- Water and wastewater treatment
- Conveyor and material handling systems
- Factory automation and industrial process visualization
Installation Overview
- Panel-mounted in control cabinets
- Powered by 18–30V DC industrial supply
- Connects to PLCs via EtherNet/IP or serial communication
- Runs FactoryTalk View ME applications for process visualization
- Suitable for integration with legacy Rockwell Automation PLC networks
Compatible Systems
- Allen Bradley ControlLogix PLCs
- Allen Bradley CompactLogix PLCs
- FactoryTalk View Machine Edition (ME) software
- EtherNet/IP industrial networks
- Legacy PanelView Plus 6 installations
Alternative Models
| Model | Description |
|---|---|
| 2711P-T15C4D8 | PanelView Plus 6 1500, similar configuration |
| 2711P-T15C21D8S | PanelView Plus 7 15-inch replacement |
| 2711P-T15C22D9P | PanelView Plus 7 Performance 15-inch |
| 2711P-T12C4D8 | 12-inch PanelView Plus 6 variant |
| 2711P-T10C22D9P | 10-inch PanelView Plus 7 variant |
Key Advantages
- Large 15-inch display for improved operator interface
- Rugged industrial design suitable for harsh environments
- Compatible with legacy Rockwell Automation PLC systems
- Ethernet and serial communication for flexible integration
- USB support for updates and program management
- Reliable, long-term operation in industrial settings
Conclusion
The Allen Bradley 2711P-T15C4D9 PanelView Plus 6 1500 is a robust industrial HMI terminal ideal for operators requiring intuitive visualization, control, and monitoring in legacy automation systems.
It offers durability, compatibility, and a large touchscreen interface, making it suitable for long-term use in demanding industrial environments.
