- Allen Bradley
- 2711P-K6C20A
- PanelView Plus 600 Operator Interface
- USA
- 266 x 98 x 167 mm
- 0.93 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 8
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Allen Bradley 2711P-K6C20A PanelView Plus 600 is a mid-size industrial operator interface designed for efficient human-machine interaction in automation systems. It provides operators with a high-resolution color touchscreen and intuitive navigation, enabling real-time monitoring and control of industrial processes.
This interface is ideal for applications that require enhanced visualization and responsive control within Allen Bradley PLC-based systems, supporting both compact and mid-scale industrial control environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 2711P-K6C20A |
| Product Type | PanelView Plus 600 Operator Interface |
| Dimensions | 266 × 98 × 167 mm |
| Weight | 0.93 kg |
| Display Type | Color TFT touchscreen |
| Display Size | 6-inch |
| Resolution | 640 × 480 pixels |
| Input Method | Touchscreen |
| Communication Ports | Ethernet, USB, Serial |
| Power Supply | 24 V DC |
| Power Consumption | ~35 W |
| Memory | 128 MB Flash / 64 MB RAM |
| Mounting Type | Panel / flush mount |
| Operating Temperature | 0°C to 50°C |
| Protection Rating | NEMA 4X / IP65 front |
| Application | Industrial HMI / operator control systems |
| Data Visualization | Real-time graphical process display |
| Reliability | Designed for continuous industrial operation |
Function and Working Principle
The 2711P-K6C20A functions as a graphical HMI, translating PLC process data into operator-readable displays while transmitting operator commands back to the controller.
Core Functions:
- Real-time process visualization and monitoring
- Touchscreen-based operator input for machine control
- Alarm and event display
- Historical trend viewing and process logging
- Navigation through operational sequences and menus
Working Principle:
The interface communicates with Allen Bradley PLCs via Ethernet or serial communication. Data from the PLC is displayed on the touchscreen, while operator inputs are sent back to the controller for immediate execution, ensuring responsive and reliable control.
Role in Industrial Control Systems
The PanelView Plus 600 plays a critical role as the operator interface layer in industrial automation, providing:
- Local control of industrial machinery
- Centralized monitoring of process variables and alarms
- Operator interaction with PLC logic
- Enhanced operational safety and decision-making
This model enables operators to manage both simple and complex processes efficiently.
Industrial Applications
The 2711P-K6C20A is widely used in:
- Manufacturing automation systems
- Process control in chemical, food, and beverage industries
- Water treatment and utility management
- Packaging and assembly lines
- Remote monitoring and control stations
- Mid-size industrial machine panels
Its 6-inch display provides a balance between visibility and compact panel integration.
Installation and System Integration
For optimal operation:
- Panel or flush-mounted in industrial control cabinets
- Connected to PLCs via Ethernet or serial ports
- Powered by 24V DC industrial power supply
- Configured using FactoryTalk View ME software
- Proper grounding and wiring ensure stable operation
Correct installation ensures reliable data display and responsive operator control.
Compatible System Components
The 2711P-K6C20A works with:
- Allen Bradley CompactLogix and ControlLogix PLC systems
- FactoryTalk View ME HMI software
- PanelView Plus power supply units
- Distributed I/O modules
- Industrial Ethernet switches and communication modules
- PLC expansion and interface modules
Together, these components form a scalable and reliable industrial automation network.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 2711P-K4M20D | PanelView Plus 400 | Compact HMI | Small-scale systems |
| 2711P-K6C5D8 | PanelView Plus 600 | Full touchscreen | Standard mid-scale applications |
| 2711P-K10C4A3 | PanelView Plus 1250 | Large 10-inch display | Enhanced visualization |
| PanelView Plus 7 | Modern HMI platform | Advanced features and connectivity | System upgrades |
| 2711P-T6C5D1 | Touchscreen HMI | Cost-effective 6-inch display | Basic operator control |
Key Advantages
- 6-inch high-resolution touchscreen for clear visualization
- Seamless integration with Allen Bradley PLCs and control networks
- Real-time monitoring and responsive control
- Rugged design for industrial environments (NEMA 4X / IP65)
- Reliable continuous operation for long-term use
- Enhances operator efficiency and process safety
Technical FAQs
Q1: What is the primary function of the 2711P-K6C20A?
It provides operators with a graphical interface to monitor and control industrial processes.
Q2: What type of display does it use?
A 6-inch color TFT touchscreen.
Q3: Which controllers is it compatible with?
Allen Bradley CompactLogix and ControlLogix PLCs.
Q4: Is it suitable for industrial environments?
Yes, it is rated NEMA 4X / IP65 for front panel protection.
Q5: What software is used for configuration?
FactoryTalk View Machine Edition (ME) is typically used.
Conclusion
The Allen Bradley 2711P-K6C20A PanelView Plus 600 offers a reliable, mid-size operator interface solution for industrial automation systems. Its responsive touchscreen, durable construction, and versatile connectivity enable operators to efficiently monitor and control industrial processes. Ideal for mid-scale applications, this module ensures high performance, safety, and long-term operational reliability.
