Product Overview
The Allen Bradley 25A-D017N114 PowerFlex 523 AC Drive is a compact AC drive from the PowerFlex 523 series, used to manage motor operation in industrial machines and automated equipment. It is suitable for applications where the motor needs controlled operation as part of a production sequence, rather than simply being switched between on and off states.
In a machine installation, the drive forms the link between the electrical supply and the AC motor. Control commands can come from a PLC, operator station, or other machine-control equipment. This arrangement allows motor operation to be coordinated with conveyors, material movement, packaging processes, pumping equipment, and other mechanical functions.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 25A-D017N114 |
| Product Series | PowerFlex 523 |
| Product Type | AC Drive |
| Main Function | AC Motor Speed Control |
| Application | Industrial Automation |
| Dimensions | 109 × 220 × 184 mm |
| Weight | 2.3 kg |
Product Features
- Allen Bradley PowerFlex 523 series AC drive
- Compact format for industrial machine applications
- Suitable for variable-speed AC motor control
- Supports controlled motor operation within automated processes
- Can be incorporated into PLC-based motor-control systems
- Suitable for conveyors, packaging equipment, pumps, fans, and material-handling machinery
- Useful where motor speed needs to follow changing machine conditions
- Dimensions: 109 × 220 × 184 mm
- Weight: 2.3 kg
Working Principle
The 25A-D017N114 regulates the operating condition of an AC motor according to the command received from the machine-control system. Instead of connecting the motor directly to a fixed operating condition, the drive manages the electrical output supplied to the motor.
Consider a packaging machine in which the motor must slow down during product positioning and then return to a higher operating speed during material transfer. The control system can issue the corresponding command, and the PowerFlex 523 adjusts the motor operation as required.
The drive therefore occupies a central position in the motor-control chain:
Machine Controller → 25A-D017N114 → AC Motor → Mechanical Mechanism
This arrangement allows motor speed and machine movement to be coordinated without making the motor itself responsible for the overall production sequence.
Industrial Applications
| Application | Typical Use |
|---|---|
| Packaging Lines | Synchronizing motor operation with packaging stages |
| Conveyor Equipment | Adjusting material-transfer speed |
| Pumping Machinery | Matching motor operation to process demand |
| Fan Systems | Controlling airflow through motor-speed adjustment |
| Material Handling | Managing movement speed |
| Assembly Equipment | Coordinating motor-driven mechanisms |
| Production Machinery | Incorporating motor operation into automatic sequences |
| General Machine Automation | Providing controlled AC motor operation |
Compatible System Components
| Component | Function |
|---|---|
| PLC / Controller | Provides machine sequence and operating commands |
| AC Motor | Drives the mechanical load |
| Operator Interface | Allows operator control and status monitoring |
| Sensors | Detect machine or process conditions |
| Circuit Protection | Protects the incoming electrical circuit |
| Motor Protection | Helps protect the motor and associated wiring |
| Motor Cable | Carries the drive output to the motor |
| Control Wiring | Connects external commands and signals |
The final configuration depends on the motor, electrical supply, machine design, and required control method.
Installation and Maintenance
The 109 × 220 × 184 mm dimensions make cabinet planning important when installing the 25A-D017N114. Although the drive itself is compact, sufficient room should be considered for power connections, motor cables, ventilation, inspection, and servicing.
During installation, the complete catalog number should first be confirmed. Technicians should then check the electrical supply, motor connections, grounding, control wiring, and protective equipment.
For commissioning, the motor should initially be operated under controlled conditions. Correct rotation, command response, acceleration, and deceleration should be observed. If the drive reports a fault, the associated wiring, motor, control signals, and operating conditions should be checked before replacing the module.
Recommended Related Models
| Model | Product Series | Primary Function |
|---|---|---|
| Allen Bradley 25A-D017N114 | PowerFlex 523 | AC motor speed control |
| Allen Bradley 25A-D017N104 | PowerFlex 523 | Variable-speed AC motor control |
| Allen Bradley 25A-D013N104 | PowerFlex 523 | Compact AC motor control |
| Allen Bradley 25A-D013N114 | PowerFlex 523 | Variable-speed motor applications |
| Allen Bradley 25A-D010N114 | PowerFlex 523 | AC motor-speed control |
| Allen Bradley 25A-D024N104 | PowerFlex 523 | Higher-size PowerFlex 523 configuration |
The related models should be evaluated by complete catalog number and electrical requirements. A similar PowerFlex series designation or physical appearance does not by itself confirm that a model can replace another.
Key Advantages
The 25A-D017N114 is particularly useful when a machine needs motor operation to respond to different stages of production. Its role is not limited to starting a motor; it allows motor operation to become part of the wider automation strategy.
Its compact 109 × 220 × 184 mm form factor can also be advantageous for machine builders working with restricted cabinet space. With a stated weight of 2.3 kg, it can be incorporated into relatively compact motor-control assemblies while still requiring appropriate clearance for wiring and ventilation.
Technical FAQs
What role does the 25A-D017N114 perform in a machine?
It serves as the AC motor-control device, regulating motor operation according to commands from the machine’s control system.
Why would a packaging machine use this type of AC drive?
Packaging machinery often requires different motor speeds during feeding, positioning, processing, and transfer. An AC drive allows those operating conditions to be coordinated with the machine sequence.
Does the compact size eliminate the need for cabinet clearance?
No. The drive measures 109 × 220 × 184 mm, but additional space is still needed for electrical connections, cable routing, ventilation, inspection, and maintenance.
What should be compared between a 25A-D017N114 and another PowerFlex 523 model?
The complete catalog number, electrical requirements, motor application, control configuration, and existing installation should be compared. The fact that both units belong to the PowerFlex 523 family does not guarantee direct interchangeability.
