Industrial AC Drive Product Overview
Model: 22B-A8P0N104
1. Product Introduction
The 22B-A8P0N104 is a compact low-voltage AC variable frequency drive designed for precise speed regulation of three-phase induction motors. It is used in general-purpose industrial automation systems where stable motor performance, smooth acceleration, and energy efficiency are required.
This model belongs to a compact drive platform focused on simple configuration, fast commissioning, and reliable operation in light to medium industrial environments.
It is commonly applied in applications where consistent torque control and basic speed adjustment are needed rather than advanced vector control functions.
2. Brand Information
Brand Category: Global industrial automation and control systems manufacturer
This product is part of a well-established industrial drive ecosystem widely used in manufacturing, material handling, and process automation industries.
It is recognized for reliability, standardized design, and long-term industrial stability.
3. Product Series
Series: PowerFlex 40 Series
The PowerFlex 40 series is a compact AC drive platform designed for general-purpose motor control applications. It emphasizes simplicity, durability, and cost efficiency.
The series is widely used in systems that require stable motor speed control with minimal configuration complexity.
4. Technical Parameters
Main Specification Table
| Parameter | Specification |
|---|---|
| Model | 22B-A8P0N104 |
| Drive Type | AC Variable Frequency Drive (VFD) |
| Series | PowerFlex 40 |
| Input Voltage | 200–240V AC, single-phase |
| Output Voltage | 3-phase output (0–input voltage level) |
| Rated Power | Approx. 1.5 kW (2.0 HP) |
| Rated Current | Approx. 8.0 A |
| Control Method | V/f control (Voltage/Frequency) |
| Frequency Range | 0–400 Hz |
| Overload Capacity | Standard industrial overload protection |
| Cooling Method | Forced air cooling |
| Protection Level | IP20 (panel mounting type) |
| Communication | Basic serial communication support |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Installation Type | Panel / cabinet mounting |
| EMC Design | Industrial environment compliance |
| Dimensions (H × W × D) | 152 × 80 × 135 mm |
| Weight | 0.85 kg |
5. Product Applications
The 22B-A8P0N104 is widely used in industrial automation systems with moderate load requirements, including:
- Conveyor systems with higher torque demand
- Industrial pump control systems
- HVAC ventilation and air handling units
- Packaging and filling machinery
- Textile machinery and auxiliary equipment
- Light manufacturing production lines
- Material transport and logistics systems
- Automated equipment retrofit projects
It is suitable for applications requiring stable speed control under varying load conditions.
6. Product Advantages
The main advantages of the 22B-A8P0N104 include:
- Compact design suitable for space-constrained electrical cabinets
- Simple configuration structure for fast installation and commissioning
- Stable motor control with smooth acceleration and deceleration performance
- Efficient energy usage under variable load operation
- Built-in protection functions including overload, undervoltage, and overvoltage protection
- Low maintenance requirements due to solid-state electronic structure
- Strong compatibility with standard industrial induction motors
- Suitable for both OEM machine integration and system upgrade projects
7. Same Series or Closely Related Models (PowerFlex 40 Series)
| Model | Rated Power | Input Voltage | Rated Current | Frame Size | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 22B-A4P5N104 | 0.75 kW | 200–240V 1-phase | 4.5 A | A | 152 × 80 × 135 | 0.75 |
| 22B-A5P0N104 | 0.75 kW | 200–240V 1-phase | 5.0 A | A | 152 × 80 × 135 | 0.75 |
| 22B-A8P0N104 | 1.5 kW | 200–240V 1-phase | 8.0 A | A | 152 × 80 × 135 | 0.85 |
| 22B-B5P0N104 | 0.75 kW | 200–240V 3-phase | 5.0 A | B | 160 × 90 × 140 | 1.0 |
| 22B-B8P0N104 | 1.5 kW | 200–240V 3-phase | 8.0 A | B | 160 × 90 × 140 | 1.1 |
These models share the same control logic and parameter structure, differing mainly in current rating, input phase type, and physical frame size.
8. Popular Models from Same Manufacturer (Across Drive Families)
| Model | Series | Rated Power | Input Voltage | Key Feature | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 22A-A8P0N104 | PowerFlex 4 | 1.5 kW | 200–240V 1-phase | Compact general-purpose drive | 150 × 70 × 130 | 0.7 |
| 22B-D8P0N104 | PowerFlex 40 | 1.5 kW | 200–240V | Standard industrial VFD | 160 × 90 × 140 | 0.9 |
| 25B-D024N114 | PowerFlex 525 | 2.0 HP class | 200–240V 3-phase | Advanced control + communication | 170 × 95 × 150 | 1.4 |
| 20G11NC140JA0NNNNN | PowerFlex 755 | Medium-high power | 400V class | High-performance motion control | 250 × 180 × 220 | 3.8 |
| 20F1A-N-D-4P0-A0NNNNN | PowerFlex 753 | Medium power | 400V class | Modular scalable drive platform | 240 × 170 × 210 | 3.3 |
9. Summary
The 22B-A8P0N104 is a compact and reliable AC drive designed for industrial motor control applications requiring higher current capacity within a simple control framework.
It provides stable operation, easy installation, and efficient energy performance in a wide range of automation systems.
As part of the PowerFlex 40 series, it maintains consistent configuration logic across different power levels, making it suitable for standardized equipment design and long-term industrial use.
