Industrial Variable Frequency Drive Report – 22A-A2P1N103
1. Product Overview
The 22A-A2P1N103 is a compact low-power variable frequency drive (VFD) designed for precise motor speed control in light industrial automation systems. It is used to regulate AC motor speed by adjusting output frequency and voltage, improving energy efficiency and mechanical control stability.
This model is optimized for small motor applications where space, simplicity, and stable operation are key requirements.
2. Brand and Product Series
- Brand: Industrial automation drive manufacturer (not specified)
- Product Series: Compact Micro AC Drive Series (22A platform)
- Product Category: Variable frequency drive (VFD)
This series is designed for low-power motor control applications, offering compact installation, simplified wiring, and efficient motor performance optimization.
3. Product Introduction
The 22A-A2P1N103 is a low-voltage AC drive designed for controlling small three-phase motors. It provides smooth acceleration, deceleration, and speed regulation, reducing mechanical stress and improving energy efficiency.
It is typically used in systems requiring:
- Compact motor control solutions
- Low-power energy-efficient operation
- Simple installation and commissioning
- Stable and reliable speed regulation
The drive is widely adopted in light industrial and commercial automation environments.
4. Technical Parameters
Core Specification Table
| Parameter | Specification |
|---|---|
| Model | 22A-A2P1N103 |
| Product Type | Variable Frequency Drive (VFD) |
| Series | 22A Compact Micro Drive Series |
| Input Phase | Single-phase |
| Output Phase | Three-phase |
| Input Voltage | 200–240V AC |
| Output Voltage | 0–input voltage |
| Rated Output Current | ~2.1 A |
| Power Rating | ~0.4–0.75 kW class |
| Control Method | V/f control + sensorless vector control |
| Frequency Range | 0–400 Hz |
| Overload Capacity | 150% short-time overload |
| Protection Functions | Overvoltage, undervoltage, overload, short circuit, thermal protection |
| Cooling Method | Natural / forced air cooling |
| Installation Type | Panel / DIN rail mounting |
| Communication | Basic industrial communication interface |
| Dimensions (H × W × D) | ~160 × 90 × 130 mm |
| Weight | ~0.9 – 1.3 kg |
5. Product Application Areas
The 22A-A2P1N103 is widely used in small motor control applications requiring stable speed regulation and compact installation.
Typical Applications
- Small conveyor systems
- Packaging machines
- Ventilation fans
- Water pumps
- Light industrial machinery
- Textile equipment
- Food processing machines
- Small automation systems
It is especially suitable for applications requiring reliable low-power motor control with minimal installation space.
6. Product Advantages
Compact Structure
Designed for tight installation environments.
Energy Efficient Operation
Reduces energy consumption through optimized motor speed control.
Stable Motor Control
Provides smooth torque and speed regulation.
Easy Integration
Simple wiring and fast commissioning process.
Reliable Protection System
Built-in protections enhance operational safety.
Low Maintenance Requirement
Designed for long-term stable industrial use.
7. Recommended Models – Same Series / Related Drives
22A Compact VFD Family
| Model | Power Level | Input Type | Output Current | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 22A-A1P5N103 | Low power | Single-phase | ~1.5 A | 150×80×120 | ~0.8 |
| 22A-A2P1N103 | Low-medium power | Single-phase | ~2.1 A | 160×90×130 | ~1.1 |
| 22A-A2P2N103 | Medium power | Single-phase | ~2.2 A | 160×95×130 | ~1.2 |
| 22A-A3P7N103 | Medium power | Single-phase | ~3.7 A | 170×100×140 | ~1.4 |
| 22A-B4P0N103 | Higher micro drive | Three-phase | ~4.0 A | 180×110×150 | ~1.6 |
8. Recommended Popular Models (Same Brand Portfolio)
Industrial Drive and Automation Portfolio
| Model | Application Focus | System Role | Voltage Range | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 22A-A2P1N103 | Light motor control systems | VFD drive | 200–240V | 160×90×130 | ~1.1 |
| 22F-D1P5N103 | Compact automation systems | VFD drive | 200–240V | 160×90×130 | ~1.0 |
| 22F-D2P2N103 | Medium light systems | VFD drive | 200–240V | 170×100×140 | ~1.3 |
| 2198-H025-ERS2 | Servo motion control systems | Servo drive module | 200–480V | 320×100×230 | ~7.0 |
| 2198-H040-ERS2 | Heavy industrial systems | Servo drive module | 200–480V | 360×140×250 | ~9.5 |
9. Engineering Summary
The 22A-A2P1N103 is a compact and efficient variable frequency drive designed for low-power motor control applications. It focuses on stable speed regulation, energy efficiency, and simple integration in small automation systems.
Key engineering characteristics include:
- Compact and lightweight design
- Stable low-power motor control capability
- Efficient frequency and voltage regulation
- Simple installation and commissioning
- Reliable protection functions for industrial use
This model is best suited for light industrial applications requiring cost efficiency, compact design, and stable motor performance.
