Industrial Servo Cable Technical Overview
Model: 2090-CFBM7DF-CEAF60
1. Product Introduction
The 2090-CFBM7DF-CEAF60 is an industrial-grade servo motor feedback and power cable assembly designed for high-performance motion control systems. It is commonly used to connect servo motors with servo drives in automated machinery, ensuring stable signal transmission and reliable power delivery.
This cable is engineered for use in dynamic motion environments where continuous flexing, vibration resistance, and electromagnetic interference protection are required. It is typically deployed in robotics, CNC machines, packaging systems, and high-speed automation lines.
The design focuses on reducing signal noise, improving durability, and maintaining stable motor control performance in demanding industrial applications.
2. Product Technical Parameters
Main Specification Table
| Parameter | Specification |
|---|---|
| Model | 2090-CFBM7DF-CEAF60 |
| Product Type | Servo motor feedback & power cable assembly |
| Cable Length | 60 meters (approx. based on “CEAF60” designation) |
| Connector Type | Industrial servo motor connector (factory molded) |
| Core Structure | Power + feedback + grounding integrated design |
| Shielding | Multi-layer electromagnetic interference shielding |
| Voltage Rating | Industrial servo drive compatible (up to 600V class) |
| Current Rating | Suitable for medium-to-high power servo systems |
| Jacket Material | Industrial-grade polyurethane (oil & abrasion resistant) |
| Flex Rating | Continuous flex / high-cycle motion rated |
| Operating Temperature | -40°C to +90°C |
| Flame Rating | Industrial flame-retardant standard compliant |
| Bend Radius | Flexible installation with controlled bending radius |
| Protection | EMI/RFI shielding for signal integrity |
| Dimensions (approx. outer diameter) | 12 mm – 18 mm cable diameter range |
| Weight | 8.5 kg (approx. for full 60m assembly) |
3. Product Description (Extended)
The 2090-CFBM7DF-CEAF60 servo cable is designed to ensure reliable communication between servo drives and motors in precision motion systems. It integrates both power conductors and feedback signal lines within a single shielded assembly, reducing wiring complexity and improving system stability.
The cable structure is optimized for dynamic applications, allowing repeated bending and movement without signal degradation. The shielding layer helps minimize electromagnetic interference generated by nearby industrial equipment.
This makes it suitable for high-speed automation systems where signal accuracy directly affects positioning performance.
4. Application Areas
This servo cable is widely used in industrial automation systems such as:
- CNC machining centers
- Industrial robotics systems
- Packaging machinery
- Material handling equipment
- Automated assembly lines
- Printing and labeling systems
- Semiconductor manufacturing equipment
- High-speed conveyor systems
- Precision positioning systems
It is especially suitable for motion-intensive environments requiring stable feedback accuracy.
5. Product Advantages
- High shielding performance reduces electromagnetic interference
- Integrated power and feedback design simplifies wiring
- High flexibility for dynamic motion applications
- Strong resistance to oil, abrasion, and industrial chemicals
- Stable signal transmission for precise servo control
- Suitable for continuous high-cycle motion
- Wide temperature operating range
- Reliable long-term durability in industrial environments
- Optimized for high-speed automation systems
6. Brand and Series Information
- Brand Category: Industrial automation motion control systems manufacturer
- Product Type: Servo motor power and feedback cable assembly
- Series Type: 2090 servo cable system series
- Technology Positioning: Motion control connectivity and signal transmission
- Application Level: Servo drive and motor connection systems
This series is designed for high-precision motion systems requiring stable communication and power delivery.
7. Same Series Recommended Models
The following models belong to the same or closely related servo cable family:
| Model | Cable Length | Key Features | Outer Diameter (mm) | Weight (kg) |
|---|---|---|---|---|
| 2090-CFBM7DF-CEAF30 | 30 m | Compact servo cable assembly | 12–18 mm | 4.2 |
| 2090-CFBM7DF-CEAF40 | 40 m | Medium-length motion cable | 12–18 mm | 5.6 |
| 2090-CFBM7DF-CEAF60 | 60 m | Standard industrial servo cable | 12–18 mm | 8.5 |
| 2090-CFBM7DF-CEAF80 | 80 m | Extended reach servo cable system | 12–18 mm | 11.0 |
| 2090-CFBM7DF-CEAF100 | 100 m | Long-distance industrial motion cable | 12–18 mm | 13.5 |
8. Same Brand Popular Models (Related Portfolio)
These models are widely used in industrial automation systems involving motion control, drives, and servo systems:
| Model | Product Type | Application | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| 2198-H040-ERS | Servo Drive | High-performance motion control | 190 × 130 × 95 | 1.6 |
| 2198-H025-ERS | Servo Drive | Mid-range servo applications | 180 × 120 × 90 | 1.4 |
| 2198-S086-ERS | Servo Drive | Multi-axis motion systems | 200 × 140 × 100 | 2.0 |
| 25A-D030N114 | Frequency Drive | Motor speed control systems | 240 × 180 × 140 | 3.2 |
| 2090-UXBB-DM12 | Servo cable | Compact motor feedback cable | 10–14 mm | 2.8 |
9. Summary
The 2090-CFBM7DF-CEAF60 is a high-performance servo motor cable designed for demanding motion control applications.
Its integrated power and feedback structure, strong shielding capability, and high flexibility make it suitable for precision automation systems requiring stable and accurate motion control.
It is widely used in robotics, CNC systems, and high-speed production equipment where reliability and signal integrity are critical.
