- Allen Bradley
- 1769-CRL1
- CompactLogix I/O Module
- USA
- 118 mm × 87 mm × 50 mm
- 0.31kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 6
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Technical Report: 1769-CRL1 Compact I/O Right-to-Left Bus Expansion Cable
1. Product Overview
The 1769-CRL1 is a Compact I/O bus expansion cable used in industrial automation systems to connect two separate I/O banks in a CompactLogix or compatible Compact I/O architecture. It provides a physical and electrical extension of the backplane communication bus, allowing multiple module groups to operate as a unified control system.
This product does not process signals or execute control logic. Its sole function is to maintain high-speed and reliable communication between distributed I/O racks inside a control cabinet.
It is commonly used when system layout constraints require separation of I/O modules into different physical sections.
2. Brand and Series Information
Brand: Industrial automation control platform ecosystem
Series: 1769 Compact I/O Series
Product Family: Bus Expansion Accessories
Module Type: Right-to-Left Compact I/O Expansion Cable
3. Product Function Description
The 1769-CRL1 provides a direct backplane connection between two Compact I/O banks.
Core functions include:
- Connecting left and right I/O banks in Compact I/O systems
- Extending backplane communication across separated module groups
- Supporting multi-bank system architecture (up to 3 banks total)
- Maintaining synchronized I/O data transmission
- Allowing independent power supply per I/O bank
- Enabling flexible cabinet layout design
A system can use up to two expansion cables, allowing segmentation into multiple functional I/O zones.
4. Technical Parameters
Electrical and Communication Characteristics
| Parameter | Value |
|---|---|
| Function Type | Backplane communication expansion cable |
| Signal Type | Parallel I/O bus extension |
| System Compatibility | Compact I/O 1769 platform |
| Maximum Expansion | Up to 3 I/O banks |
| Cable Usage Limit | Max 2 cables per system |
| Isolation Voltage | 30 V continuous |
| Backplane Current | 1.4 A at 24 V (system dependent) |
Mechanical Parameters
| Parameter | Value |
|---|---|
| Cable Length | 0.3 m (1 ft) |
| Physical Dimensions (installed system reference) | Approx. 118 mm × 87 mm × 50 mm |
| Connector Type | Multi-pin locked backplane connectors |
| Installation Method | Plug-in chassis connection |
| Weight | 0.28 kg – 0.31 kg |
| Cable Type | Shielded industrial bus cable assembly |
Environmental Conditions
| Parameter | Value |
|---|---|
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% – 95% non-condensing |
| Vibration Resistance | Industrial control cabinet rated |
| Shock Resistance | IEC industrial standard |
5. Product Advantages
1. Flexible System Segmentation
Allows a single Compact I/O system to be divided into multiple physically separated banks without losing communication integrity.
2. Simplified Cabinet Design
Reduces wiring complexity when I/O modules cannot be installed on a single DIN rail.
3. Stable High-Speed Backplane Communication
Ensures deterministic and synchronized data transfer between I/O banks.
4. Modular System Expansion
Supports scalable architecture for medium to large automation systems.
5. Independent Power Architecture
Each I/O bank can be powered separately, improving fault isolation and system stability.
6. Application Areas
The 1769-CRL1 is commonly used in:
- Modular industrial automation control panels
- Large manufacturing production lines
- Conveyor and logistics systems
- Multi-zone machine control systems
- Process automation systems requiring distributed I/O
- Retrofitting and expansion of PLC cabinets
- Factory automation systems with space constraints
It is especially valuable when physical cabinet layout forces separation of I/O modules into multiple sections.
7. Recommended Models (Same Series / Related Components)
| Model | Type | Key Parameters | Application |
|---|---|---|---|
| 1769-CRR1 | Right-to-Right Bus Cable | 0.3 m expansion cable | I/O bank linking |
| 1769-CRR3 | Right-to-Right Bus Cable | Extended version bus cable | Multi-bank expansion |
| 1769-CLL1 | Left-to-Left Bus Cable | Short expansion connection | Bank segmentation |
| 1769-CLL3 | Left-to-Left Bus Cable | 0.3 m expansion cable | Multi-bank architecture |
| 1769-CRL3 | Right-to-Left Bus Cable | Extended version cable | Flexible cabinet layout |
8. Other Popular Models (Same Platform – Widely Used)
| Model | Type | Key Parameters | Application |
|---|---|---|---|
| 1769-L33ER | PLC Controller | Integrated EtherNet/IP CPU | Machine automation |
| 1769-L36ERM | PLC Controller | High-performance motion control CPU | Advanced automation systems |
| 1769-AENTR | Ethernet Adapter Module | Dual-port EtherNet/IP communication | Distributed I/O networking |
| 1769-SDN | DeviceNet Scanner Module | Master fieldbus controller | Legacy network integration |
| 1769-IF8 | Analog Input Module | 8-channel analog signal input | Process monitoring |
9. Summary
The 1769-CRL1 is a structural communication accessory within Compact I/O systems, designed to extend the backplane bus between multiple I/O banks. It does not perform logic or signal processing but plays a critical role in system architecture flexibility and modular expansion.
Its main strengths are reliable communication extension, flexible system segmentation, and support for scalable multi-bank PLC configurations.
It is an essential component in medium to large automation systems where physical layout constraints require distributed I/O architecture.
