Product Overview
The Allen-Bradley 1762-OB16 MicroLogix 16-Point Solid-State DC Power Output Module is a compact digital output expansion module designed for industrial automation and PLC-based control systems.
This module provides sixteen solid-state DC output channels for controlling industrial field devices such as solenoids, relays, indicators, contactors, and other DC-powered equipment. Engineered for reliable switching performance and fast response speed, the 1762-OB16 is widely used in industrial automation systems requiring expanded digital output capacity.
As part of the MicroLogix expansion module family, the 1762-OB16 integrates seamlessly with MicroLogix controllers, offering efficient and scalable output control for industrial applications.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen-Bradley |
| Model | 1762-OB16 |
| Product Type | Solid-State DC Output Module |
| Series | MicroLogix Expansion I/O |
| Number of Outputs | 16 digital outputs |
| Output Type | Solid-state DC sourcing outputs |
| Output Voltage Range | 20.4 to 26.4V DC |
| Signal Type | Digital DC output |
| Isolation | Group isolated outputs |
| Mounting Type | DIN rail / panel mounted |
| Wiring Method | Screw terminal connection |
| Compatible Controllers | MicroLogix 1100 / 1200 / 1400 |
| Response Time | High-speed solid-state switching |
| Dimensions | 90 × 40.4 × 87 mm |
| Weight | 0.235 kg |
| Application | Industrial digital output expansion |
| Operating Environment | Industrial-grade automation systems |
Function and Working Principle
The 1762-OB16 functions as a digital DC output interface module for PLC automation systems.
Its operating process includes:
- Receiving control commands from the PLC processor
- Activating solid-state DC output channels
- Switching connected field devices ON or OFF
- Providing fast-response digital signal control
- Supporting stable and reliable industrial automation operation
Because the module uses solid-state output technology, it delivers faster switching performance and reduced mechanical wear compared to relay-based modules.
Role in Industrial Control Systems
Within industrial automation systems, the 1762-OB16 serves as a high-density digital output expansion module.
It is commonly used to control:
- Solenoid valves
- Industrial relays
- Alarm systems
- Indicator lamps
- DC contactors
- Automated machine actuators
The module expands the digital output capability of MicroLogix PLC systems while maintaining compact installation size.
Industrial Applications
The Allen-Bradley 1762-OB16 is widely used in:
- Manufacturing automation systems
- Packaging and assembly machinery
- Conveyor and transport systems
- Material handling equipment
- Food and beverage production lines
- Water treatment facilities
- Industrial process automation systems
It is especially suitable for applications requiring multiple high-speed DC output channels.
Installation and System Integration
Proper installation ensures reliable long-term performance:
- Mounted on DIN rail or industrial control panels
- Connected directly to MicroLogix expansion buses
- Wired using industrial screw terminal connections
- Installed inside industrial control cabinets
- Requires proper grounding and electrical protection
Correct installation improves operational stability and reduces electrical interference.
Compatible System Components
The 1762-OB16 typically works with:
- MicroLogix PLC controllers
- 1762 analog and digital I/O modules
- Human Machine Interfaces (HMI)
- Industrial sensors and switches
- Motor control systems
- Industrial communication modules
It functions as part of a scalable industrial automation platform.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 1762-OA8 | AC output module | Solid-state AC outputs | AC control systems |
| 1762-OW8 | Relay output module | Mechanical relay switching | General-purpose control |
| 1762-OB8 | DC output module | 8-point solid-state outputs | Compact systems |
| 1769-OB16 | CompactLogix output module | Higher integration capability | Advanced automation |
| Siemens SM1222 | Digital output module | Industrial PLC compatibility | Industrial automation |
Key Advantages
- High-density 16-point DC outputs
- Fast solid-state switching performance
- Compact industrial design
- Reliable long-term operation
- Seamless MicroLogix PLC integration
- Suitable for continuous industrial applications
Technical FAQs
What is the main function of the 1762-OB16?
It provides sixteen digital DC outputs for controlling industrial field devices.
What type of outputs does it support?
It supports solid-state DC sourcing outputs.
Which PLC systems are compatible with this module?
It is compatible with MicroLogix 1100, 1200, and 1400 controllers.
What are the advantages of solid-state outputs?
Solid-state outputs provide faster response speed and longer operational life compared to relay outputs.
Conclusion
The Allen-Bradley 1762-OB16 MicroLogix 16-Point Solid-State DC Power Output Module is a reliable industrial expansion module designed for efficient digital DC output control in PLC automation systems. With sixteen high-speed solid-state outputs, compact construction, and seamless MicroLogix integration, it provides dependable performance for industrial machine automation and process control applications.
For engineers and system integrators, the 1762-OB16 offers scalable output expansion, stable operation, and long-term reliability in demanding industrial environments.
