- Allen Bradley
- 1756-L7SPK
- ControlLogix ControlNet Communication Module
- USA
- 150 × 150 × 100 mm
- 0.37kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 7
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Technical Profile Report – 1756-L7SPK Safety Partner Module
1. Product Overview
The 1756-L7SPK is a GuardLogix Safety Partner controller module designed to operate as a redundant safety processor within the ControlLogix safety automation system. It is not a standalone controller; instead, it must be paired with a compatible L7S-series safety CPU to form a complete SIL 3 safety architecture.
This module belongs to the ControlLogix 5570 GuardLogix safety system, where it performs continuous safety data validation and redundancy checking to ensure fail-safe operation in industrial environments.
It is typically used in systems requiring:
- SIL 3 / PLe functional safety compliance
- Redundant safety processing architecture
- High-integrity machine safety systems
- Industrial automation with strict safety standards
2. Product Introduction
The 1756-L7SPK functions as a safety partner processor, working in parallel with the primary safety controller. It continuously compares safety logic execution results to detect discrepancies and ensure system integrity.
Key characteristics include:
- Safety partner module for GuardLogix L7S CPUs
- Required for redundant safety architecture
- Conformal coated version (K-type protection)
- Dual-slot modular design
- Backplane communication synchronization
- Real-time safety validation processing
It is installed in a ControlLogix chassis and works as part of a dual-controller safety system.
3. Technical Parameters
Core Specifications Table
| Parameter | Value |
|---|---|
| Controller Type | Safety Partner Module |
| Platform Series | ControlLogix 5570 GuardLogix |
| Functional Role | Redundant safety processor |
| Memory | Dependent on paired controller |
| Safety Architecture | 1oo2 redundant system |
| Safety Integrity Level | SIL 3 / PLe capable |
| Module Width | 2-slot design |
| Communication Method | Backplane synchronization |
| Compatible CPUs | 1756-L71S / L72S / L73S |
| Chassis Compatibility | 1756 ControlLogix chassis series |
| Programming Interface | System-level USB access |
| Power Consumption | 2.5 W |
| Backplane Current (5.1V DC) | 802 mA |
| Backplane Current (1.2V DC) | 5 mA |
| Isolation Voltage | 30 V continuous |
| Thermal Dissipation | 8.5 BTU/hr |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% – 95% non-condensing |
| Protection Type | Conformal coating (K version) |
| Scan Type | Safety redundant execution |
| Dimensions (H×L×W) | ≈ 150 × 150 × 100 mm |
| Weight | ≈ 0.37 kg |
4. Product Application Areas
The 1756-L7SPK is used in safety-critical automation systems where redundancy and fault detection are mandatory.
Industrial Applications
- Industrial robotics safety systems
- Automotive production line safety control
- Oil and gas emergency shutdown systems
- Chemical plant safety interlocks
- Heavy machinery protection systems
- Power generation safety systems
Safety Functions
- Emergency stop validation (E-Stop)
- Safety gate monitoring systems
- Light curtain safety systems
- Burner management safety systems
- Motion safety monitoring
5. Product Advantages
1. Redundant Safety Architecture
Ensures dual-channel safety processing for fault tolerance.
2. SIL 3 Compliance Support
Works within certified safety systems for high-risk applications.
3. Continuous Data Validation
Compares real-time safety execution with the primary CPU.
4. Conformal Coating Protection
Improves resistance against dust, humidity, and industrial corrosion.
5. High System Reliability
Designed for continuous 24/7 industrial operation.
6. Seamless System Integration
Installed directly into ControlLogix chassis architecture.
7. Fault Detection Capability
Detects mismatches between redundant safety channels instantly.
6. Brand Positioning
The product belongs to a globally recognized industrial automation ecosystem known for:
- Safety programmable controllers
- Industrial control systems
- Redundant automation architectures
- High-integrity safety solutions
It is widely used in industries where human safety and equipment protection are critical requirements.
7. Product Series
Series Name: GuardLogix Safety Partner Series (ControlLogix 5570 Safety Platform)
The 1756-L7SPK is part of the GuardLogix L7 safety architecture, operating only alongside compatible safety CPUs.
Series Features
- 1oo2 redundant safety processing design
- Chassis-based modular installation
- High-integrity real-time synchronization
- SIL 3 certified architecture
- Conformal coated protection (K variant)
8. Recommended Models – Same Series or Related
A. Same Series / Closely Related Models
| Model | Description | Key Parameters |
|---|---|---|
| 1756-L71S | Entry safety CPU | 2 MB memory, SIL 3 capable |
| 1756-L72S | Mid safety CPU | 4 MB memory, balanced systems |
| 1756-L73S | High safety CPU | 8 MB memory, large systems |
| 1756-L7SPK | Safety partner module | Redundant processor, conformal coated |
| 1756-L75S | High-end safety CPU | Expanded memory, complex systems |
B. Same Brand – Popular Models
| Model | Type | Key Parameters |
|---|---|---|
| 1756-L7SPK | Safety Partner Module | Redundant processor, SIL 3 system |
| 1756-L73S | Safety CPU | 8 MB memory, GuardLogix system |
| 1756-L72 | Standard CPU | 4 MB memory, non-safety control |
| 1756-L81E | Ethernet controller | Multi-core architecture, networking |
| 1756-L85E | Advanced controller | High-speed processing, large memory |
9. Summary
The 1756-L7SPK safety partner module is a critical component of GuardLogix safety systems, providing redundant processing and continuous validation of safety logic. It ensures that the system meets SIL 3 functional safety requirements by operating in parallel with a primary safety CPU.
Its value lies in redundancy, fault detection, and system-level safety assurance, making it essential in high-risk industrial automation environments where failure is not an option.
