ABB SB510 3BSE000860R1 – Detailed Technical Overview and Product Guide
1. Basic Product Information
Product Model: ABB SB510
Part Number: 3BSE000860R1
Brand: ABB
Series: SB Signal Conditioning & Transducer Family
Product Type: Analog Signal Conditioner / Transducer Module
Category: Industrial Signal Processing and Measurement Module
2. Product Introduction
The ABB SB510 3BSE000860R1 is an industrial analog signal conditioning and transducer module designed to convert and standardize measurement signals from field‑mounted sensors for use in automation, control, and monitoring systems. The analog input from temperature sensors, pressure transmitters, or flow meters is conditioned, isolated, and scaled into standardized outputs such as 4–20 mA or 0–10 V. This prepares raw signals for processing by controllers, recorders, or data acquisition units.
The SB510 is typically installed on DIN rails inside control panels, where it interfaces directly with field sensors and delivers accurate analog signals to higher‑level automation equipment. Its design emphasizes electrical isolation, stable output scaling, and noise‑reduction features, ensuring reliable signal quality in industrial environments.
With robust construction tailored to extended industrial use and precision under varying process conditions, the SB510 is a core module in signal conditioning applications. Its flexible input and output compatibility makes it suitable for numerous sensor types and control system architectures.
3. Technical Specifications
Electrical, Mechanical and Operational Parameters
| Parameter | Specification |
|---|---|
| Model | SB510 |
| Part Number | 3BSE000860R1 |
| Series | SB Analog Signal Transducers |
| Product Type | Analog Signal Conditioner / Transducer |
| Input Signal Types | Voltage, Current, Thermocouple, RTD |
| Output Signal Types | 4–20 mA, 0–10 V |
| Input Impedance | High Input Impedance (signal dependent) |
| Output Load Capability | Drive for typical industrial loads |
| Isolation | Full Galvanic Isolation between channels |
| Accuracy | ±0.1 % of full scale (typical) |
| Response Time | < 100 ms |
| Supply Voltage | 24 V DC |
| Power Consumption | < 5 W |
| Operating Temperature Range | –10 °C to +55 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Relative Humidity | 5 % to 95 % non‑condensing |
| Protection Rating | IP20 |
| Mounting Type | DIN‑Rail Mount |
| Connection Type | Screw Terminal |
| Dimensions (W × H × D) | 17.5 × 100 × 110 mm |
| Weight (kg) | 0.15 kg |
4. Product Applications
The SB510 is used in environments requiring accurate conditioning and transmission of analog process measurement signals for industrial automation and monitoring.
Typical application scenarios include:
• Conditioning temperature measurement signals from thermocouples and RTDs for control systems.
• Scaling analog signals from pressure, level, or flow transmitters for PLC or DCS input circuits.
• Transmitting clean analog outputs to distributed control systems, recorders, and operator stations.
• Providing isolation of analog loops to reduce ground loop effects and electrical noise.
• Preprocessing analog signals for data acquisition systems and PID loop feedback.
• Environmental monitoring system integration requiring stable analog signals.
• Machine automation and diagnostics using analog sensor feedback.
• Utility process automation requiring reliable analog signal conditioning.
In these applications, the SB510 ensures that raw sensor signals maintain integrity and accuracy from the field to the automation controller or monitoring system.
5. Product Advantages
High Accuracy Signal Conditioning
Delivers precise scaling and filtering of sensor inputs into industry‑standard analog outputs with minimal error.
Galvanic Isolation
Protects against ground loops and reduces electrical interference between channels, improving signal integrity.
Multi‑Input Flexibility
Accepts multiple types of sensor inputs including voltage, current, thermocouples, and RTDs, allowing flexibility in application.
Standard Industrial Output Compatibility
Produces widely compatible analog outputs such as 4–20 mA or 0–10 V for integration with controllers, recorders, and data systems.
Compact and Space‑Efficient
DIN‑rail form factor allows efficient use of control cabinet space.
Low Power Operation
Runs on a standard 24 V DC industrial supply with low power consumption.
Reliable Industrial Performance
Engineered for stable operation in industrial temperature and humidity ranges, suitable for continuous use.
Simple Installation
Screw terminal connections simplify field wiring and maintenance.
6. Recommended Models from the Same Series or Related Devices
Below are five related signal conditioning or transducer modules from the same family or with similar functionality.
| Model | Supported Inputs | Output Type | Supply Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| SB170 | Voltage / Current | 4–20 mA | 24 V DC | 17.5×100×110 | 0.15 kg |
| SB171 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 17.5×100×110 | 0.15 kg |
| SB172 | Thermocouple | 4–20 mA | 24 V DC | 17.5×100×110 | 0.15 kg |
| SB175 | RTD | 0–10 V | 24 V DC | 17.5×100×110 | 0.15 kg |
| SB510 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 17.5×100×110 | 0.15 kg |
7. Five Popular Industrial Automation Models from the Same Brand
Below are five widely used automation hardware modules that complement analog signal conditioning devices like the SB510.
| Model | Device Type | Supply Voltage | Dimensions (mm) | Weight (kg) | Application |
|---|---|---|---|---|---|
| AC800M | Modular Controller | 24 V DC | 140×180×120 | 1.2 kg | Core process automation CPU |
| PM856 | Processor Module | 24 V DC | 120×150×90 | 0.9 kg | Central logic controller |
| CI870 | Communication Interface | 24 V DC | 120×150×90 | 0.8 kg | Fieldbus network interface |
| AI820 | Analog Input Module | 24 V DC | 120×150×80 | 0.6 kg | Multi‑channel analog signal acquisition |
| DI820 | Digital Input Module | 24 V DC | 120×150×80 | 0.6 kg | Multi‑channel digital input capture |
8. Frequently Asked Questions (FAQ)
Q1: What is the main purpose of the SB510?
A: The SB510 conditions and scales raw analog signals from field sensors into standardized outputs for controllers and monitoring.
Q2: What types of inputs does the SB510 accept?
A: It accepts voltage, current, thermocouple, and RTD inputs.
Q3: What outputs does the SB510 provide?
A: It provides standardized analog outputs such as 4–20 mA or 0–10 V.
Q4: What power supply does it require?
A: The product operates on a 24 V DC supply.
Q5: How much does the SB510 weigh?
A: The approximate weight is 0.15 kg.
Q6: What are the physical dimensions of the module?
A: Approximately 17.5 × 100 × 110 mm.
Q7: Where is the SB510 typically installed?
A: It is typically mounted on DIN rails inside control cabinets.
Q8: Why is galvanic isolation important in signal conditioning?
A: Galvanic isolation reduces electrical noise and prevents ground loop interference, improving signal accuracy.
Q9: In which industries is the SB510 commonly used?
A: It is used in manufacturing, utilities, environmental monitoring, and process control systems.
Q10: Is the SB510 suitable for continuous industrial operation?
A: Yes, it is designed for stable, uninterrupted operation in industrial environments.
