Product: Honeywell FC‑TDOL‑0724
1. Technical Specifications
| Parameter | Details |
|---|---|
| Model | FC‑TDOL‑0724 |
| Product Type | Analog Input Module |
| Input Channels | 7 |
| Input Voltage Type | Analog signals (e.g. ±10 V or 0–10 V range) |
| Supply Voltage | 24 V DC |
| Input Impedance | Typically high (to suit sensor signal input) |
| Internal Current Draw | Approx. 2 A |
| Operating Temperature | −20 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Environmental Protection | IP20 |
| Certifications | CE, UL, CSA, TUV |
| Mounting | Field Terminal Assembly (FTA) |
| Dimensions (L × W × H) | 240 mm × 108 mm × 85 mm |
| Weight | 0.62 kg |
2. Product Introduction
The FC‑TDOL‑0724 is a high-performance analog input module engineered for industrial environments requiring reliable, real-time monitoring of process variables. Designed as part of a field terminal assembly (FTA), it enables the collection of analog signals from field instruments such as pressure transmitters, thermocouples, and flow sensors.
With seven analog input channels and 24 V DC power supply, it provides stable signal acquisition and smooth integration into control systems like PLCs or DCS platforms. The module ensures high signal integrity and is well-suited for mission-critical automation applications where data accuracy is paramount.
3. Applications
-
Real-time data acquisition from industrial sensors (temperature, flow, level, pressure, etc.)
-
Integration into distributed control systems (DCS) or programmable logic controllers (PLC)
-
Used in process automation industries such as oil & gas, chemicals, utilities, and manufacturing
-
Monitoring analog feedback in safety systems and diagnostic networks
-
Suitable for indoor panels or enclosures where space and signal clarity are critical
4. Product Advantages
-
Seven Analog Inputs: Accommodates multiple sensors in a single compact device
-
24 V DC Standard Power: Compatible with most industrial power supplies
-
Compact and Lightweight: Saves cabinet space and simplifies installation
-
High Reliability: Certified and compliant with key international standards
-
Rugged Design: Operates in wide temperature ranges and harsh electrical environments
-
Modular FTA Form Factor: Easy to integrate, wire, and maintain in control systems
-
Optimized for Signal Integrity: Designed for high-accuracy, low-noise signal processing
5. Brand
This product is manufactured under the Honeywell brand, known worldwide for its high-quality automation systems, industrial safety solutions, and field instrumentation. Honeywell’s control hardware is widely used in critical infrastructure and manufacturing sectors due to its durability, compliance, and innovation.
6. Series
The model FC‑TDOL‑0724 is part of the FC‑TDOL series — a family of field terminal modules supporting analog or digital input/output functionality. These modules are optimized for integration into control cabinets and process systems, and offer reliable performance for analog signal processing tasks.
7. Related Models (Same Series or Function)
| Model | Input/Output Type | Channels | Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| FC‑TDOL‑07120 | Relay Output with Loop Monitoring | 7 | 120 V AC/DC | 240 × 109 × 71 | 1.00 |
| FC‑TDOL‑0724P | Analog Input with Enhanced Protection | 7 | 24 V DC | 240 × 108 × 85 | 0.62 |
| FC‑TIDI‑1624 | Digital Input Module | 16 | 24 V DC | 260 × 110 × 90 | 1.20 |
| FC‑TSDO‑0824 | Safe Digital Output Module | 8 | 24 V DC | 250 × 108 × 85 | 0.95 |
| FC‑SDOL‑0424C | Digital Output with Line Monitoring | 4 | 24 V DC | 200 × 90 × 80 | 0.70 |
8. Popular Models by the Same Brand
| Model | Function | Channels | Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| FC‑TDO‑0824 | Secure Digital Output | 8 | 24 V DC | 240 × 110 × 85 | 0.90 |
| FC‑TIDI‑1624 | Digital Input Module | 16 | 24 V DC | 260 × 110 × 90 | 1.20 |
| FC‑SDOL‑0424C | Digital Output with Loop Monitoring | 4 | 24 V DC | 200 × 90 × 80 | 0.70 |
| FC‑TERM‑0001 | Terminal Block / End Module | – | – | 80 × 50 × 30 | 0.20 |
| FC‑CIPer‑Model30 | High-Speed Controller | – | Multi | 300 × 200 × 120 | 2.50 |
9. FAQs (QA Format)
Q1: What signal types can this module accept?
A1: It accepts standard analog voltage inputs, typically in the ±10 V or 0–10 V range, depending on the configuration.
Q2: Can this module be used in outdoor installations?
A2: It is rated IP20 and designed for cabinet use. For outdoor use, it must be installed within a weatherproof enclosure.
Q3: How many sensors can I connect?
A3: The module supports 7 analog input channels, allowing connection of 7 individual analog sensors.
Q4: What is the typical use case for this module?
A4: It is primarily used to collect sensor data in industrial process control systems such as DCS or PLC setups.
Q5: Does the module include signal isolation?
A5: Signal isolation depends on the internal design, but analog modules often include input isolation. It is recommended to confirm in your system manual.
Q6: Is this module hot-swappable?
A6: It depends on the backplane and controller. In most systems, hot-swapping analog modules is not recommended without precautions.
Q7: What certifications does it meet?
A7: The module meets CE, UL, CSA, and TUV certifications for industrial use.
Q8: What happens if the input voltage exceeds the limit?
A8: Excess input voltage can damage the input circuitry. Protection circuits are typically limited. External protection is advised.
Q9: How do I wire it in a control cabinet?
A9: It uses screw terminals or FTA blocks. Each channel is labeled and documented for easy wiring.
Q10: How much space should I allocate for mounting?
A10: The module’s footprint is approximately 240 mm by 108 mm with a height of 85 mm. Allow some clearance for wiring.
