GE IC695LRE001 – Serial Bus Transmitter Module
Product Introduction
The GE IC695LRE001 is a high-performance Serial Bus Transmitter Module designed for use with RX3i PACSystems. This module facilitates communication between the RX3i system and external devices via serial communication protocols, including RS-232 and RS-485 standards. It supports serial data transmission for a wide range of industrial automation applications.
This module features two independent serial ports, each capable of transmitting and receiving data at high speeds. It allows seamless integration with serial devices such as industrial controllers, PLCs, and other automation equipment. With the ability to operate in both master and slave modes, it offers flexibility in network configurations and control.
The IC695LRE001 is ideal for systems where serial communication is essential, ensuring reliable data exchange for real-time control and monitoring in industrial settings. It supports various protocols, including Modbus RTU and ASCII, ensuring compatibility with a broad range of devices.
Product Specifications
| Specification | Details |
|---|---|
| Model Number | IC695LRE001 |
| Type | Serial Bus Transmitter Module |
| Communication Standards | RS-232, RS-485 |
| Number of Ports | 2 (Independent Serial Ports) |
| Protocol Support | Modbus RTU, ASCII |
| Maximum Baud Rate | 115200 bps |
| Data Format | 8 Data Bits, 1 Stop Bit, Even/Odd/No Parity |
| Input Voltage Range | 5V DC |
| Power Requirements | 5V DC, 250mA |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% (Non-condensing) |
| Diagnostic LEDs | Port Status, Activity, and Error Indicators |
| Dimensions | 35.6 x 25.4 x 135 mm |
| Weight | 0.0223 kg |
| Mounting | RX3i Rack-mounted |
| Certifications | CE, UL, RoHS, FCC Class A |
Product Applications
The IC695LRE001 Serial Bus Transmitter Module is primarily used in industrial control systems where serial communication is essential for device interaction. The following are some key applications:
-
Manufacturing Automation: Enables communication between PLC systems and external equipment such as sensors, actuators, and motor controllers.
-
Energy and Power Distribution: Facilitates data exchange between power meters and SCADA systems, enabling real-time monitoring and control.
-
Water Treatment Plants: Supports communication between various devices such as pumps, valves, and flow meters in automated water treatment systems.
-
Oil and Gas: Used in remote monitoring and control of equipment such as pressure sensors and control valves in pipeline systems.
-
Transportation Systems: Integrates communication for signal controllers and traffic monitoring systems.
Product Advantages
-
Dual Serial Ports: Provides two independent serial communication channels, improving flexibility and efficiency in connecting to multiple devices.
-
Supports Multiple Protocols: Compatible with Modbus RTU and ASCII, ensuring seamless integration with a wide range of devices in the field.
-
High-Speed Communication: Capable of operating at 115200 bps, ensuring fast data transmission over serial connections.
-
Compact Design: With a compact size of 35.6 x 25.4 x 135 mm and weighing just 0.0223 kg, it is perfect for space-constrained applications.
-
Easy Troubleshooting: LED indicators for port status and error diagnostics help streamline maintenance and troubleshooting efforts.
-
Industrial-Grade Durability: Built to operate in harsh industrial environments with a wide temperature range of 0°C to 60°C.
Recommended Models from the RX3i Series
| Model Number | Specifications |
|---|---|
| IC695CPE310 | RX3i CPU Module, 1 GHz Processor, Dual Ethernet Ports |
| IC695ETM001 | Ethernet Interface Module, 10/100 Mbps, 2 RJ-45 Ports |
| IC695LRE100 | Serial Bus Receiver Module, RS-232/RS-485 |
| IC695MDL750 | 32-Point Digital Output Module, 24V DC, Sinking Logic |
| IC695ALG600 | 16-Channel Analog Input Module, 24V DC, 0-10V/4-20mA |
Recommended Popular Models from GE
| Model Number | Specifications |
|---|---|
| IC693PWR321 | Power Supply Module, 120/240V AC, 30W Output |
| IC693CPU374 | High-Performance CPU, Built-in Ethernet, 240 KB Memory |
| IC693MDL655 | 32-Point Digital Input Module, 24V DC, Positive Logic |
| IC693BEM331 | Genius Bus Controller Module, Supports Remote I/O |
| IC693MDL752 | 32-Point Digital Output Module, 24V DC, Negative Logic |
FAQs for the GE IC695LRE001
Q1: What is the main function of the IC695LRE001 module?
A1: The IC695LRE001 is a serial bus transmitter module that provides communication between RX3i PACSystems and external devices using RS-232 and RS-485 protocols.
Q2: How many serial ports does this module have?
A2: The module has two independent serial ports.
Q3: What is the maximum baud rate supported by this module?
A3: The module supports a maximum baud rate of 115200 bps.
Q4: Does this module support Modbus communication?
A4: Yes, it supports Modbus RTU protocol for industrial communication.
Q5: What is the power requirement for the IC695LRE001?
A5: The module requires 5V DC power and consumes 250mA.
Q6: Can the module be used for both transmitting and receiving data?
A6: Yes, the module supports both transmission and reception of data via serial communication.
Q7: What are the diagnostic features of this module?
A7: The module features LED indicators for port status, activity, and error diagnostics.
Q8: What is the temperature range for operation?
A8: The module operates in the temperature range of 0°C to 60°C.
Q9: What protocols does this module support?
A9: This module supports RS-232 and RS-485 communication and is compatible with Modbus RTU and ASCII protocols.
Q10: What is the weight and size of the module?
A10: The module weighs 0.0223 kg and has dimensions of 35.6 x 25.4 x 135 mm.
