Product Overview

The GE IC695CHS007 is a 7-Slot Backplate designed for the GE PACSystems RX3i automation platform. It provides the physical mounting structure and electrical backplane interface required to install and interconnect compatible RX3i CPUs, power supplies, communication modules, and I/O modules.

In an RX3i control system, the backplate is more than a mechanical support component. It establishes the module-to-module backplane connection through which power, control information, configuration data, and system communication are exchanged. A properly installed backplate therefore has a direct influence on overall PLC reliability.

The IC695CHS007 provides 7 module slots, allowing engineers to build a compact but expandable RX3i control system. Its specified dimensions are 265 × 141.5 × 148 mm, with a weight of approximately 1.03 kg.

The backplate is particularly useful in industrial cabinets where multiple RX3i components need to be arranged in a structured rack architecture while maintaining convenient access for installation, maintenance, and replacement.

---

Product Identification

Parameter	Specification
Manufacturer	GE
Product Family	PACSystems RX3i
Model	IC695CHS007
Product Type	7-Slot Backplate
Primary Function	Module Mounting and Backplane Interconnection
Number of Slots	7
Dimensions	265 × 141.5 × 148 mm
Weight	1.03 kg
Installation	Industrial Control Cabinet
Platform	RX3i
Application	PLC / I/O System Architecture
Mounting Type	Rack / Panel Installation

---

Technical Specifications

Technical Item	Specification
Product Series	PACSystems RX3i
Part Number	IC695CHS007
Component Type	7-Slot Backplate
Slot Capacity	7
Height	265 mm
Width	141.5 mm
Depth	148 mm
Weight	Approximately 1.03 kg
Installation Environment	Industrial Control Cabinet
Main Function	Module Mounting and Backplane Connection
System Architecture	RX3i Rack-Based Control
Maintenance	Replaceable Hardware Component

---

Main Functions

The IC695CHS007 performs several important functions within an RX3i control system.

1. Module Mounting

The backplate provides the physical structure for installing compatible RX3i modules.

2. Backplane Interconnection

It provides the electrical interface between installed modules and the control system architecture.

3. System Organization

Seven available slots allow the automation engineer to organize CPU, power, communication, and I/O components within a centralized rack.

4. System Expansion

The available slots provide flexibility for adding compatible system modules as control requirements increase.

5. Maintenance Access

The rack-style arrangement makes individual modules easier to identify, inspect, remove, and replace.

---

RX3i System Architecture

A typical RX3i system using the IC695CHS007 can be organized as:

RX3i Power Supply

↓

RX3i CPU / Controller

↓

Communication Modules

↓

Analog / Digital I/O Modules

↓

Field Devices

↓

Industrial Process

The exact module arrangement depends on the application and the system hardware configuration.

---

Working Principle

The backplate acts as the common infrastructure connecting installed RX3i modules.

During normal operation:

1. Individual modules are inserted into designated slots.
2. The modules mechanically engage with the backplate.
3. Electrical connections are established through the backplane interface.
4. The power and control architecture distributes required system resources.
5. The CPU communicates with installed modules through the backplane.
6. I/O modules exchange process information with the controller.
7. The PLC application uses this information to control the industrial process.

Because the backplate is shared by multiple modules, a poor connection or damaged backplane can potentially affect several components simultaneously.

---

Typical Industrial Applications

The GE IC695CHS007 can be used in a variety of RX3i automation applications, including:

• Factory automation
• Machine control
• Process automation
• Power generation
• Water treatment
• Oil and gas
• Chemical processing
• Pharmaceutical production
• Food and beverage manufacturing
• Mining
• Steel production
• Packaging systems
• Material handling

---

Installation Guide

1. Verify the Backplate Model

Confirm the product identification:

GE IC695CHS007

Verify that the application requires a 7-slot RX3i backplate.

---

2. Check the System Layout

Before physical installation, determine the intended positions of:

• Power supply
• CPU
• Communication modules
• I/O modules
• Spare slots
• Cable routing

Prepare the rack layout before mounting hardware.

---

3. Inspect the Backplate

Check the backplate for:

• Mechanical deformation
• Damaged mounting points
• Damaged connectors
• Contamination
• Corrosion
• Loose hardware

Do not install a visibly damaged backplate.

---

4. Prepare Cabinet Space

The specified dimensions are:

265 × 141.5 × 148 mm

Ensure adequate cabinet space around the backplate for:

• Module installation
• Cable routing
• Ventilation
• Maintenance access
• Module replacement

---

5. Mount the Backplate

Secure the backplate to the designated mounting surface using appropriate hardware.

Ensure that:

• The rack is level.
• Mounting hardware is secure.
• The backplate is not mechanically stressed.
• The cabinet structure can support the installed equipment.

---

6. Install the Power Supply

Install the compatible RX3i power supply in the designated position according to the approved system architecture.

Verify proper mechanical engagement.

---

7. Install the CPU and Modules

Install the compatible modules one at a time.

Typical components may include:

• CPU module
• Communication module
• Analog input module
• Analog output module
• Digital input module
• Digital output module

Ensure each module is fully seated and securely retained.

---

8. Verify Slot Arrangement

Confirm that every module is installed in its intended location.

Compare the physical installation with the PLC hardware configuration.

---

9. Connect Field and Communication Wiring

Route external cables carefully.

Avoid:

• Excessive bending
• Cable tension
• Sharp edges
• High-power cable interference
• Poor strain relief

---

10. Check Grounding

Verify the cabinet and system grounding arrangement before energizing the rack.

Proper grounding helps protect equipment and reduce electrical interference.

---

Commissioning Procedure

After installation, perform a structured commissioning sequence.

Step 1 — Mechanical Inspection

Check that the backplate and all modules are securely installed.

Step 2 — Connector Inspection

Verify that module connectors are correctly engaged.

Step 3 — Power Verification

Check the power supply and system voltage.

Step 4 — CPU Startup

Start the RX3i controller according to the approved procedure.

Step 5 — Module Recognition

Confirm that installed modules are recognized by the controller.

Step 6 — Diagnostic Review

Check for rack, module, or communication alarms.

Step 7 — I/O Test

Verify that connected inputs and outputs operate correctly.

Step 8 — Process Test

Run the system under controlled operating conditions.

---

Troubleshooting Guide

Fault 1 — Multiple Modules Are Not Recognized

If several modules simultaneously disappear from the controller configuration, inspect the backplate and power architecture first.

Possible causes include:

• Backplane connection problem
• Rack power issue
• Damaged backplate
• Incorrect module installation
• Configuration mismatch

---

Fault 2 — One Module Is Not Detected

Possible causes:

• Module not fully inserted
• Damaged module connector
• Incorrect slot configuration
• Contamination at the connection point

Remove and inspect the affected module before replacing the backplate.

---

Fault 3 — Entire Rack Loses Communication

Possible causes include:

• Power supply problem
• Backplane fault
• CPU problem
• Major connector failure

Check the system from the power supply through the backplane and CPU.

---

Fault 4 — Intermittent Module Communication

Possible causes:

• Loose module connection
• Mechanical vibration
• Contaminated connector
• Backplate damage
• Cabinet movement

Inspect the physical rack assembly carefully.

---

Fault 5 — System Resets Unexpectedly

Possible causes:

• Power instability
• Poor connection
• Backplane problem
• Excessive electrical interference
• Hardware fault

Review controller diagnostics and power-system records.

---

Fault 6 — Module Diagnostic Alarm

Possible causes:

• Poor backplane connection
• Module configuration mismatch
• Module hardware failure
• Power problem

Check whether the fault follows a particular module or remains associated with the rack position.

---

Fault 7 — Rack Configuration Does Not Match PLC Program

Possible causes:

• Incorrect hardware configuration
• Module installed in the wrong slot
• Replacement module not configured
• Engineering project mismatch

Compare the physical rack with the PLC hardware configuration.

---

Fault 8 — Physical Damage to Backplate

Inspect for:

• Cracked housing
• Bent mounting points
• Damaged connector interfaces
• Corrosion
• Burn marks

A physically damaged backplate should not remain in critical service.

---

Fault 9 — Communication Fault After Maintenance

If a communication fault appears immediately after module replacement, inspect:

• Module seating
• Backplate connector
• Slot assignment
• Wiring
• Configuration

Maintenance-related faults are often caused by incomplete mechanical engagement.

---

Fault 10 — Only One Rack Position Produces Repeated Faults

If different known-good modules exhibit problems only when installed in one specific position, investigate the backplate slot and its electrical interface.

This can help distinguish a module fault from a rack fault.

---

Diagnostic Workflow

Use the following sequence when investigating rack-level problems:

Power Supply

↓

IC695CHS007 Backplate

↓

Module Connection

↓

CPU / Communication Module

↓

I/O Modules

↓

PLC Program

↓

Field Devices

This method helps determine whether the problem originates from the rack infrastructure, a specific module, or the control application.

---

Preventive Maintenance

Mechanical Maintenance

Inspect:

• Mounting hardware
• Backplate housing
• Module retention
• Rack alignment
• Signs of vibration

Electrical Maintenance

Inspect:

• Backplane connections
• Power connections
• Grounding
• Wiring
• Connector condition

Environmental Maintenance

Monitor:

• Cabinet temperature
• Dust
• Moisture
• Corrosion
• Vibration
• Ventilation

Configuration Maintenance

Maintain:

• Current PLC hardware configuration
• Module slot records
• System drawings
• Backup project files
• Replacement-module records

---

Preventive Maintenance Checklist

Inspection Item	Recommended Action
Backplate Housing	Inspect for damage
Mounting Hardware	Check tightness
Module Connections	Verify seating
Backplane Interface	Inspect condition
Grounding	Verify continuity
Cabinet Environment	Check temperature and dust
Module Arrangement	Compare with drawings
PLC Configuration	Verify hardware configuration
Diagnostic Logs	Review periodically
Spare Hardware	Maintain suitable replacements

---

Backplate Replacement Procedure

Replacing a rack backplate requires careful planning because multiple modules may depend on its physical and electrical interfaces.

Step 1

Back up the PLC application and hardware configuration.

Step 2

Record the existing module arrangement.

Step 3

Label field and communication connections.

Step 4

Shut down the control system.

Step 5

Remove system power.

Step 6

Disconnect external wiring as required.

Step 7

Remove installed modules.

Step 8

Remove the existing backplate.

Step 9

Install the replacement IC695CHS007.

Step 10

Reinstall the modules in their original positions.

Step 11

Reconnect wiring.

Step 12

Inspect every connector.

Step 13

Restore power.

Step 14

Verify module recognition.

Step 15

Check controller diagnostics.

Step 16

Test I/O and communication.

Step 17

Return the system to service after successful testing.

---

Key Advantages

• Seven-slot rack architecture
• Compact industrial installation
• Provides structured RX3i module mounting
• Supports organized PLC system construction
• Simplifies module replacement
• Provides a common backplane interface
• Suitable for centralized control systems
• Supports expandable automation architectures
• Robust industrial construction
• Suitable for continuous industrial applications

---

Frequently Asked Questions

What is the GE IC695CHS007?

The GE IC695CHS007 is a 7-slot backplate designed for compatible GE PACSystems RX3i automation systems.

How many slots does it provide?

The backplate provides 7 slots for compatible system modules.

What are its dimensions?

The specified dimensions are:

265 × 141.5 × 148 mm

What is its weight?

Approximately 1.03 kg.

What is the purpose of the backplate?

It provides both mechanical mounting and the common electrical backplane interface required for the installed automation modules.

What happens if the backplate is faulty?

A backplate problem can potentially affect multiple modules, causing communication errors, module recognition problems, intermittent operation, or rack-level failures.

How can a backplate fault be distinguished from a module fault?

If a known-good module works correctly in another rack position but repeatedly fails in one specific position, the backplate or its interface should be investigated.

Should the PLC program be backed up before replacing the backplate?

Yes. The PLC application and hardware configuration should be backed up before performing major rack-level maintenance.

How can backplate reliability be improved?

Maintain secure mounting, clean connector interfaces, correct grounding, proper cabinet environmental conditions, and regular inspection of module connections.

---

Conclusion

The GE IC695CHS007 7-Slot Backplate is an important structural and electrical component for building compatible PACSystems RX3i control systems. With 7 available slots, dimensions of 265 × 141.5 × 148 mm, and a weight of approximately 1.03 kg, it provides a practical foundation for organizing CPU, communication, power, and I/O modules in industrial control cabinets.

Because multiple modules depend on the rack infrastructure, proper installation and maintenance of the backplate are essential. A secure mechanical installation, clean and reliable module connections, appropriate grounding, correct cabinet conditions, and accurate hardware configuration can significantly reduce rack-level communication and module-recognition problems.

When troubleshooting an RX3i system, engineers should evaluate the complete hardware path rather than immediately replacing individual modules. Checking the power supply, IC695CHS007, module connections, CPU, communication status, and PLC configuration in sequence provides a more efficient method for identifying the root cause and restoring reliable industrial automation operation.
