GE IC694MDL231 16-Point Discrete Input Module
Product Introduction
The IC694MDL231 is a sixteen-channel discrete input module in the PACSystems™ RX3i family. It accepts 24 VDC signals from field devices such as proximity switches, pushbuttons, and safety interlocks, and reports their status through the high-speed RX3i backplane. Designed for harsh industrial environments, the MDL231 features optical isolation for each channel, fast response times, and built-in diagnostics, ensuring reliable monitoring of binary field signals.
Key Applications
-
Reading status of safety interlocks, door switches, and e-stop buttons in machine safety systems.
-
Monitoring limit switches, level sensors, and float switches in bulk material handling.
-
Capturing pulse/frequency signals from flow meters and tachometers in process plants.
-
Detecting position feedback from photoeyes and proximity sensors in packaging lines.
-
Integrating status signals from motor starters and valve solenoids in water/wastewater control.
Brand and Series Overview
Brand: GE Automation & Controls
Series: PACSystems™ RX3i I/O Modules
PACSystems RX3i offers a scalable, high-performance I/O platform with rugged modules and a high-speed deterministic backplane. GE’s long lifecycle support and global service network ensure continuity for critical automation installations.
Product Advantages
-
Channel Isolation: Each input channel is optically isolated to 1500 VDC, preventing ground-loop errors and noise coupling.
-
Fast Response: Input-to-backplane update times under 5 ms support real-time control and high-speed counting.
-
Built-In Diagnostics: Per-channel status bits indicate wiring faults, voltage presence, and module health.
-
Rugged Design: Conformal-coated PCB and –25 °C to +70 °C operation accommodate harsh plant environments.
-
Space Efficiency: Sixteen channels in a single 34 mm-wide module maximize rack density and minimize footprint.
Detailed Technical Parameters
| Specification | Details |
|---|---|
| Model Number | IC694MDL231 |
| Channels | 16 discrete inputs |
| Input Voltage | 24 VDC ±20 % |
| Input Current | 8 mA @ 24 VDC per channel |
| Isolation Voltage | 1500 VDC channel-to-backplane |
| Response Time | <5 ms to backplane |
| Diagnostics | Channel-level wiring fault detection |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % RH (non-condensing) |
| Dimensions (W × H × D) | 34 × 145 × 140 mm |
| Weight | 0.37 kg |
| Mounting | RX3i backplane slot |
Related RX3i Series / Function Models
| Model | Description |
|---|---|
| IC694MDL240 | 32-channel sinking discrete input, RX3i |
| IC694MDL241 | 32-channel sourcing discrete input, RX3i |
| IC694MDL230 | 16-channel sinking discrete input, Series 90-30 |
| IC695MDL645 | 32-point sink digital input for RX3i |
| IC695MDL740 | Universal logic module: discrete & high-speed counter |
Popular GE Automation & Controls Models
| Model | Key Features |
|---|---|
| IC695CPU310 | RX3i PAC CPU, 64 MB user memory, deterministic backplane |
| IC695PWR001 | 24 VDC power supply, redundant input option |
| IC695CMM001 | Ethernet communication module for RX3i and Series 90-30 |
| IC695ALG600 | 4-channel ±10 V/0–20 mA analog output, 16-bit resolution |
| IC695MDL655 | 32-channel discrete output, sourcing, RX3i |
Frequently Asked Questions (FAQ)
Q: What voltage does the MDL231 require?
A: It accepts 24 VDC ±20 % on each of its 16 inputs.
Q: How quickly does the module report input changes?
A: All channels update in under 5 ms to the backplane.
Q: Is each channel isolated?
A: Yes, each input is optically isolated to 1500 VDC from the backplane.
Q: What diagnostic information is available?
A: Per-channel wiring fault and voltage presence status bits are reported to the PLC.
Q: Which PLC series support this module?
A: It is compatible with PACSystems RX3i backplanes only.
Q: What environment can it withstand?
A: Operating range is –25 °C to +70 °C and up to 95 % non-condensing humidity.
Q: How many channels per module?
A: Sixteen discrete input channels.
Q: Can it count high-speed pulses?
A: Yes, high-speed counting up to several kilohertz is supported.
Q: What mounting style does it use?
A: Slides into one RX3i backplane slot and latches automatically.
Q: What certifications does it have?
A: CE, UL, and cUL approvals for industrial control applications.
