GE IC694ALG442 Multi-Function Analog I/O Module
Product Introduction
The IC694ALG442 is a versatile analog I/O module in GE’s PACSystems™ RX3i family. It combines four channels of configurable current or voltage input with four channels of configurable current or voltage output in a single 34 × 145 × 140 mm package. With 16-bit resolution, galvanic isolation, and diagnostic reporting, this module reduces panel footprint and inventory while delivering precise measurements and reliable control for complex process applications.
Key Applications
-
Process Feedback & Control: Measure and drive valve positions and flow controllers in oil & gas and petrochemical plants.
-
Batch Process Automation: Execute recipe-based input/output sequencing in chemical and pharmaceutical manufacturing.
-
Water & Wastewater Management: Monitor pH, level, and turbidity sensors while controlling chemical dosing pumps.
-
Power Generation: Acquire generator excitation feedback and provide governor control signals.
-
Machine & Motion Control: Interface with servo drives and proportional valves in packaging and material handling equipment.
Brand and Series Overview
Brand: GE Automation & Controls
Series: PACSystems™ RX3i I/O Modules
PACSystems RX3i modules deliver high performance, flexibility, and long lifecycle support for process and discrete control. The ALG442 leverages this platform’s high-speed backplane and advanced diagnostics to enhance system uptime and simplify maintenance.
Product Advantages
-
Multi-Function Flexibility: Four universal input and four universal output channels eliminate separate I/O types and reduce spare parts.
-
High Resolution & Accuracy: 16-bit A/D and D/A conversion yield ±0.05 % full-scale accuracy for both inputs and outputs.
-
Channel Isolation: 1500 V AC isolation between every input, output, and backplane prevents ground loops and noise coupling.
-
Built-In Diagnostics: Real-time status bits report open-wire, over-range, under-range, and module health to the PLC.
-
Space & Cost Savings: Combines eight functions in one slot, halving rack requirements and wiring compared to discrete I/O modules.
Detailed Technical Parameters
| Specification | Details |
|---|---|
| Model Number | IC694ALG442 |
| Channels | 4 universal inputs + 4 universal outputs |
| Input Ranges | ±10 V, 0–10 V, ±5 V; 0–20 mA, 4–20 mA |
| Output Ranges | 0–10 V, 0–20 mA, 4–20 mA |
| Resolution | 16-bit A/D and D/A |
| Accuracy | ±0.05 % of full scale |
| Isolation Voltage | 1500 V AC channel-to-channel and to backplane |
| Diagnostics | Open-wire detect, over/under-range, module health status |
| Update Time | <15 ms for all channels |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % RH (non-condensing) |
| Dimensions (W × H × D) | 34 × 145 × 140 mm |
| Weight | 0.454 kg |
| Mounting | RX3i backplane slot |
Related RX3i Series / Function Models
| Model | Description |
|---|---|
| IC695ALG600 | 4-channel ±10 V/0–20 mA analog output, 16-bit resolution |
| IC695ALG620 | 8-channel high-speed analog input, 16-bit resolution |
| IC695ALG700 | 8-channel universal analog input, software-selectable ranges |
| IC695AOI622 | 4-channel isolated analog output with HART® communication |
| IC695MLC230 | Mixed analog/digital combo module: 4 inputs + 4 outputs |
Popular GE Automation & Controls Models
| Model | Key Features |
|---|---|
| IC695CPU310 | RX3i PAC CPU, 64 MB user memory, high-speed deterministic backplane |
| IC695PWR001 | 24 V DC power supply, redundant input option |
| IC695MDL645 | 32-point 24 V DC sink digital input |
| IC695CMM001 | Ethernet communication module for Series 90-30/RX3i |
| IC695ALG600 | (Also related) 4-channel analog output module |
Frequently Asked Questions (FAQ)
Q: What makes the ALG442 “multi-function”?
A: It integrates four configurable inputs and four configurable outputs—current or voltage—into a single module, reducing spare parts and wiring.
Q: How accurate are the measurements?
A: Both inputs and outputs offer ±0.05 % full-scale accuracy with 16-bit resolution for precise process control.
Q: Can the inputs and outputs be mixed?
A: Yes—any input channel can be configured for voltage or current, and any output channel likewise, via software settings.
Q: How does the module report wiring faults?
A: Built-in diagnostics detect open-wire conditions on each channel and report status back to the PLC.
Q: Is electrical isolation provided?
A: Yes, 1500 V AC galvanic isolation between every channel and the backplane prevents ground-loop errors.
Q: What is the typical update time?
A: The module scans all eight channels in under 15 ms, delivering timely data for fast control loops.
Q: Which PLC series support this module?
A: It is compatible exclusively with the PACSystems RX3i backplane.
Q: What environmental conditions can it withstand?
A: Rated for –25 °C to +70 °C and 5 %–95 % RH (non-condensing), with conformal coating for harsh environments.
Q: How much rack space does it occupy?
A: It uses one RX3i I/O slot (34 mm wide) yet replaces two separate analog input and output modules.
Q: Does it support HART communication?
A: No, the ALG442 does not include HART; for HART-enabled outputs see IC695AOI622.
