GE IC694ALG392 8-Channel Analog Output Module
Product Introduction
The IC694ALG392 is an 8-channel, 12-bit analog output module in GE’s Series 90-30 PLC family. It provides isolated current outputs (0–20 mA or 4–20 mA) with software-selectable ranges for interfacing with control valves, actuators, recorders, and other field devices. The module communicates over the high-speed Series 90-30 backplane, delivering deterministic update rates and tight loop control for demanding process applications.
Key Applications
-
Precise positioning of control valves and dampers in oil & gas and petrochemical plants.
-
Driving proportional actuators in batch reactors and continuous chemical processes.
-
Supplying analog reference signals to chart recorders and data acquisition systems in utilities.
-
Integrating with distributed I/O skids in water/wastewater treatment for pump and valve control.
-
Coordinating motion control and servo drives in packaging, material handling, and automotive assembly.
Brand and Series Overview
Brand: GE Automation & Controls
Series: 90-30 PLC I/O Modules
GE Automation & Controls, a division of General Electric, has delivered the Series 90-30 PLC platform for over two decades, supporting critical infrastructure and process industries with rugged hardware and long-lifecycle support.
Product Advantages
-
Isolated Outputs: Each of eight channels is galvanically isolated (500 V DC) to prevent ground‐loop errors and ensure signal integrity.
-
Flexible Ranges: Software-configurable current outputs of 0–20 mA or 4–20 mA without hardware changes.
-
Deterministic Performance: Typical update scan of all channels in <20 ms ensures real-time responsiveness.
-
Robust Design: Operates from –25 °C to +70 °C with conformal-coated PCB for harsh environments.
-
Seamless Integration: Plug-and-play module installs into any 90-30 backplane slot with no jumpers or switches.
Detailed Technical Parameters
| Specification | Details |
|---|---|
| Model Number | IC694ALG392 |
| Channels | 8 isolated analog outputs |
| Resolution | 12-bit DAC |
| Output Ranges | 0–20 mA, 4–20 mA (per-channel software select) |
| Isolation | 500 V DC channel-to-channel and channel-to-backplane |
| Update Time | <20 ms for all channels |
| Accuracy | ±0.1 % of full scale |
| Temperature Drift | ±50 ppm/°C |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % RH (non-condensing) |
| Dimensions (W × H × D) | 34 × 145 × 140 mm |
| Weight | 0.299 kg |
| Mounting | Series 90-30 backplane slot |
Related 90-30 Series / Function Models
| Model | Description |
|---|---|
| IC694ALG390 | 4-channel 12-bit analog output module, Series 90-30 |
| IC694ALG391 | 8-channel 14-bit high-resolution analog output module |
| IC694ALG393 | 8-channel 12-bit voltage output (0–10 V) module |
| IC694ALG395 | 16-channel 10-bit multiplexed analog output module |
| IC694ALG392 | (This module) 8-channel 12-bit current output |
Popular GE Automation & Controls Models
| Model | Key Features |
|---|---|
| IC695CPU310 | RX3i PAC CPU, 64 MB user memory, high-speed backplane |
| IC695MDL645 | 32-point 24 V DC sink digital input module |
| IC695ALG600 | 4-channel ±10 V/0–20 mA analog output, 16-bit resolution |
| IC695CMM001 | Ethernet communication module for Series 90-30 PLCs |
| IC695PWR002 | 24 V DC redundant power supply unit for RX3i and Series 90-30 systems |
Frequently Asked Questions (FAQ)
Q: What output ranges does the IC694ALG392 support?
A: Each channel supports 0–20 mA or 4–20 mA current ranges, selectable via software configuration.
Q: How isolated are the outputs?
A: Outputs are isolated to 500 V DC between channels and to the backplane to prevent noise and ground loops.
Q: What is the update time for all eight channels?
A: The module updates all channels in under 20 ms, suitable for tight control loops.
Q: Can it drive voltage outputs?
A: No; this module is current-output only. For voltage outputs, see module IC694ALG393.
Q: What environmental conditions can it endure?
A: Operates from –25 °C to +70 °C and 5 %–95 % RH (non-condensing), with conformal coating for corrosion resistance.
Q: How is the module configured?
A: No jumpers or switches—configuration is managed through the PLC’s I/O configuration tool.
Q: Is enhanced resolution available?
A: This module is fixed at 12-bit resolution; for 14-bit resolution, consider IC694ALG391.
Q: What PLC platforms are compatible?
A: Designed for GE Series 90-30 backplanes; not compatible with RX3i slots.
Q: How do I mount the module?
A: It slides into any available slot on a 90-30 baseplate rail and locks with the integral latch.
Q: What certifications does it hold?
A: CE, UL, and cUL approvals for industrial control equipment.
