Basic Information
-
Brand: GE
-
Series: Mark VI / Speedtronic (Turbine Protection / Control Modules)
-
Model: IS215VPROH2B
-
Product Type: Turbine Emergency Protection / Trip Solenoid Control Module
Specifications Table
| Parameter | Description |
|---|---|
| Model | IS215VPROH2B |
| Brand | GE |
| Series | Mark VI / Speedtronic |
| Product Type | Turbine Emergency Protection / Trip Solenoid Driver |
| Dimensions | 330 mm × 178 mm × 20 mm (approx.) |
| Weight | 2.3 kg (approx. 5 lbs) |
| Operating Voltage | 125 V DC (supplied from PDM) |
| Operating Temperature | ‑30 °C to +65 °C (typical) |
| Redundancy | Supports Triple Modular Redundancy (TMR) |
| I/O | 3 analog current inputs + 9 thermocouple inputs; drives up to 3 Trip Solenoids via TREG board |
| Mounting | VME rack slot installation (Mark VI protection module chassis) |
Product Description
The IS215VPROH2B is designed for turbine units (gas, steam, or combined cycle) as a dedicated emergency protection module. It belongs to the Mark VI series but focuses on overspeed, overtemperature, and emergency shutdown functions. It typically interfaces with TREG/TRPG terminal boards to trigger turbine shutdown or cut fuel/drive systems during abnormal conditions.
The module uses triple modular redundancy (TMR), with three independent VPRO boards (R8, S8, T8) that vote on outputs. If one board fails, the remaining two maintain protection, ensuring uninterrupted safety.
It is designed for rapid response, with Trip Solenoid activation time constants around 0.1 seconds. Its VME single-slot form factor allows modular installation and replacement. Its robust industrial-grade design makes it suitable for critical safety applications in turbines.
Applications
-
Gas turbine startup/shutdown emergency protection (overspeed trip).
-
Steam turbine overtemperature and bearing monitoring shutdown.
-
Combined cycle power plants as a backup turbine protection loop.
-
Offshore and onshore power plants to control turbine or compressor emergency shutdown.
-
Replacement or upgrade in existing Mark VI control racks to improve reliability.
Advantages
-
High reliability with triple modular redundancy.
-
Dedicated turbine protection for overspeed, overtemperature, and synchronization faults.
-
Rapid response with 0.1-second Trip Solenoid activation.
-
Modular installation allows quick replacement and reduced downtime.
-
Industrial-grade durability for temperatures from ‑30 °C to +65 °C.
-
System compatibility with Mark VI series controllers.
-
Easy maintenance via LED indicators and modular design.
-
Prolonged turbine life by preventing catastrophic events.
Related Series Models
| Model | Description | Key Specs (Dimensions / Weight) |
|---|---|---|
| IS215VPROH2B | Current product, TMR emergency protection | 330×178×20 mm / 2.3 kg |
| IS215VPROH1A | Previous revision with similar protection features | 330×178×20 mm / 2.2 kg |
| IS215REBFH1BA | Auxiliary I/O module for turbine protection | 330×100×200 mm / 2.5 kg |
| IS215UCVEM06A | Universal control module | 159×178 mm / 1.0 kg |
| IS215WEMAH1BA | Steam/water turbine protection module | 330×100×200 mm / 2.1 kg |
Popular Models of the Same Brand
| Model | Description | Key Specs (Dimensions / Weight) |
|---|---|---|
| IS215WEPAH2AB | Turbine pitch control module | 200×150×50 mm / 1.2 kg |
| IS200AEPAH1ACB | Power/interface module for control systems | 100×150×50 mm / 0.8 kg |
| IS215VCMH2B | Communication module (VME bus) | 258×160×40 mm / 1.9 kg |
| IS215PMVPH1AA | Turbine control processor board | 330×100×200 mm / 2.0 kg |
| IS215UCVHM06A | Universal control module | 279×229×38 mm / 1.0 kg |
FAQ (Q&A)
Q1: What is the primary function of IS215VPROH2B?
A1: Provides emergency protection for turbine systems, specifically overspeed trip and shutdown, via a dedicated protection board independent of the main control logic.
Q2: Which series does this module belong to?
A2: GE Mark VI / Speedtronic turbine control and protection series.
Q3: What are the dimensions and weight?
A3: 330 mm × 178 mm × 20 mm, weight approx. 2.3 kg.
Q4: Can this module work in redundant configuration?
A4: Yes, designed for triple modular redundancy (TMR).
Q5: What operating temperature range is supported?
A5: ‑30 °C to +65 °C.
Q6: What kind of protection functions does it support?
A6: Emergency overspeed, Trip Solenoid activation, backup synchronization check, exhaust overtemperature protection.
Q7: Is it suitable as a spare for existing turbine control racks?
A7: Yes, it integrates with Mark VI protection racks as a replacement.
Q8: What power supply is required?
A8: 125 V DC from cabinet Power Distribution Module (PDM).
Q9: How does it interface with turbine Trip Solenoids?
A9: Controls up to three solenoids via TREG/TRPG terminal boards using its internal redundant logic.
Q10: What should be checked before ordering?
A10: Part number, revision, rack compatibility, slot position, power supply, environment, and spare availability.
