Bently Nevada 330130-045-03-05 – Full Technical Overview
1. Brand and Series
- Brand: Bently Nevada
- Series: 3300 XL Proximity Transducer System
- Model: 330130-045-03-05
- Product Type: 3300 XL Extension Cable Assembly
This model is part of the 3300 XL proximity transducer system, widely used in rotating machinery protection and condition monitoring applications such as turbines, compressors, pumps, and generators.
2. Product Introduction
The 330130-045-03-05 is a 4.5-meter extension cable used in the 3300 XL eddy-current proximity measurement system.
It connects the proximity probe to the proximitor sensor, ensuring stable transmission of vibration and displacement signals.
The system is designed for continuous monitoring of shaft vibration, axial displacement, and phase reference signals in critical rotating machinery.
The suffix “045” indicates a 4.5 m cable length, while “03-05” refers to armored cable configuration and multi-agency approval specification, commonly used in industrial-grade installations.
3. Product Specifications
| Parameter | Details |
|---|---|
| Model | 330130-045-03-05 |
| Series | 3300 XL |
| Product Type | Extension Cable Assembly |
| System Structure | Probe + Extension Cable + Proximitor Sensor |
| Cable Length | 4.5 meters |
| Signal Type | Eddy-current proximity signal transmission |
| Measurement Function | Vibration / Shaft position / Speed |
| Cable Construction | Armored triaxial shielded cable |
| Connector Type | Gold-plated industrial connectors |
| Operating Voltage | -17.5 Vdc to -26 Vdc |
| Operating Temperature | -51°C to +177°C |
| Capacitance | ~69.9 pF/m (typical) |
| System Compatibility | 3300 XL 8 mm proximity probe system |
| Dimensions | ~16 cm × 16 cm × 12 cm (packaged) |
| Weight (kg) | ~0.5 – 0.8 kg |
4. Product Applications
This extension cable is widely used in industrial condition monitoring systems:
- Steam turbines
- Gas turbines
- Centrifugal compressors
- Industrial pumps
- Electric generators
- Heavy rotating machinery systems
Typical functions include:
- Shaft vibration monitoring
- Axial displacement measurement
- Keyphasor speed and phase reference signals
It is essential in environments requiring long-distance signal transmission with high reliability and low interference.
5. Product Advantages
Stable Signal Transmission
Shielded triaxial cable design ensures low noise and high signal integrity.
Industrial Durability
Armored structure provides resistance to vibration, oil exposure, and mechanical stress.
High Temperature Resistance
Operates reliably up to 177°C in demanding industrial environments.
Secure Connection System
Gold-plated connectors ensure corrosion resistance and stable electrical contact.
Flexible Installation
4.5 m length supports medium-range industrial installation layouts.
High System Compatibility
Fully compatible with 3300 XL proximity probe and monitoring systems.
Low Maintenance Design
Designed for long-term operation without recalibration requirements.
6. Same Series / Related Models (5 Recommended)
| Model | Type | Cable Length | Function | Weight (kg) |
|---|---|---|---|---|
| 330130-040-03-05 | Extension Cable | 4.0 m | Standard vibration signal transmission | ~0.5–0.7 |
| 330130-045-00-00 | Extension Cable | 4.5 m | Basic system configuration | ~0.5–0.8 |
| 330130-050-03-05 | Extension Cable | 5.0 m | Extended reach monitoring | ~0.7–0.9 |
| 330130-020-00-00 | Extension Cable | 2.0 m | Compact machinery systems | ~0.4–0.6 |
| 330130-080-03-05 | Extension Cable | 8.0 m | Long-distance industrial monitoring | ~0.8–1.2 |
7. Popular Models from Same Brand (5 Recommended)
| Model | Type | Function | Output | Weight (kg) |
|---|---|---|---|---|
| 330101-00-00-10-02-00 | Proximity Probe | Vibration sensing | Analog signal | ~0.5 |
| 330180-50-00 | Proximitor Sensor | Signal conditioning | 4–20 mA | ~1.0 |
| 3500/22M | Monitoring Module | Data processing | Digital system output | ~2.0 |
| 3500/25 | Keyphasor Module | Speed reference | Digital pulse | ~2.0 |
| 1900/65A | Machinery Monitor | Compact monitoring system | Digital | ~1.5 |
9. FAQ (10 Q&A)
Q1: What is the main function of this product?
A: It transmits vibration and displacement signals between the probe and monitoring system.
Q2: What does “045” mean in the model number?
A: It indicates a 4.5-meter cable length.
Q3: What system is it compatible with?
A: It is compatible with the 3300 XL proximity transducer system.
Q4: What type of signal does it carry?
A: It carries eddy-current proximity sensor signals.
Q5: Can it be used in high-temperature environments?
A: Yes, it operates up to 177°C in industrial conditions.
Q6: What industries use this cable?
A: Power generation, oil & gas, petrochemical, and heavy industry.
Q7: Does it require calibration after replacement?
A: No, it is fully interchangeable within the system.
Q8: What is the benefit of armored cable design?
A: It improves resistance to mechanical stress and harsh environments.
Q9: What is the weight of the cable assembly?
A: Typically around 0.5–0.8 kg depending on configuration.
Q10: Why is this cable important in monitoring systems?
A: It ensures stable and accurate transmission of critical machinery condition data.
