Product Overview
The Allen-Bradley MPL-A220T-EJ74AA Servo Motor is a high-performance MP-Series Low-Inertia 230V AC Rotary Servo Motor designed for precision motion control in demanding industrial automation systems. As part of the Rockwell Automation MP-Series servo motor family, this model delivers excellent positioning accuracy, fast dynamic response, and smooth torque output for high-speed machine applications. Unlike the MPL-A220T-EJ72AA, the MPL-A220T-EJ74AA is equipped with an integrated 24 V DC holding brake, making it particularly suitable for vertical-axis applications and machinery requiring secure load holding during power loss or emergency stops.
The motor features a 75 mm IEC metric frame size, 230 V AC operation, 6000 RPM rated speed, 50.8 mm magnet stack length, single-turn high-resolution encoder, keyed shaft, and a SpeedTEC right-angle rotatable DIN connector for quick installation and reliable electrical connections. Its low-inertia rotor provides rapid acceleration and deceleration, helping reduce machine cycle times while maintaining exceptional motion accuracy.
Designed for seamless integration with Allen-Bradley Kinetix servo drives, the MPL-A220T-EJ74AA is widely used in packaging machinery, robotic systems, CNC equipment, electronic assembly machines, semiconductor manufacturing, pharmaceutical production, printing machinery, and precision material handling equipment.
With a compact 75 mm frame size and an approximate weight of 2 kg, the servo motor offers high power density while minimizing installation space requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Model | MPL-A220T-EJ74AA |
| Product Series | MP-Series MPL |
| Product Type | Rotary Servo Motor |
| Motor Type | Low-Inertia Brushless AC Servo Motor |
| Rated Voltage | 230 V AC |
| Holding Brake Voltage | 24 V DC |
| Rated Speed | 6000 RPM |
| Frame Size | 75 mm |
| Magnet Stack Length | 50.8 mm |
| Feedback Device | Single-Turn High-Resolution Encoder |
| Shaft Type | Keyed Shaft |
| Brake | Integrated 24 V DC Holding Brake |
| Connector Type | SpeedTEC Right-Angle DIN Connector |
| Mounting | IEC Metric Flange |
| Frame Size | 75 mm |
| Weight | Approximately 2 kg |
Function and Working Principle
The Allen-Bradley MPL-A220T-EJ74AA converts electrical energy from a compatible servo drive into accurate rotary motion while providing secure load holding through its integrated electromagnetic brake.
Typical Motion Control Architecture
Motion Controller
↓
Allen-Bradley Kinetix Servo Drive
↓
MPL-A220T-EJ74AA Servo Motor
↓
Mechanical Transmission
↓
Industrial Machine
During operation, the servo motor continuously performs the following functions:
- Executes precise positioning commands
- Maintains accurate speed control
- Produces stable output torque
- Supports rapid acceleration and deceleration
- Provides closed-loop encoder feedback
- Activates the holding brake when required
- Improves machine positioning repeatability
- Enhances production efficiency
The integrated 24 V DC holding brake secures the motor shaft whenever power is removed, preventing unintended movement on vertical or suspended loads.
Role in Industrial Motion Control Systems
The MPL-A220T-EJ74AA serves as a precision actuator within industrial motion control systems.
Its primary responsibilities include:
- Executing motion commands
- Controlling rotational speed
- Delivering precise torque
- Supporting synchronized multi-axis motion
- Providing encoder position feedback
- Holding loads safely when power is removed
- Improving machine accuracy
- Increasing overall production efficiency
Its integrated holding brake makes it especially suitable for applications where maintaining load position is essential.
Industrial Applications
Packaging Machinery
Widely used in:
- Filling machines
- Cartoning systems
- Labeling equipment
- Wrapping machinery
- High-speed conveyors
Robotics
Suitable for:
- Six-axis robots
- Pick-and-place systems
- Assembly robots
- Collaborative robots
- Material handling robots
CNC Machinery
Applications include:
- CNC machining centers
- Milling machines
- Precision cutting equipment
- Automated machining cells
- Multi-axis motion systems
Semiconductor and Electronics Manufacturing
Commonly used in:
- PCB assembly equipment
- Semiconductor production
- Precision positioning systems
- Inspection equipment
- Component handling machines
Printing and Converting
Ideal for:
- Digital printing presses
- Web handling systems
- Label production equipment
- Paper converting machinery
- Roll-to-roll processing
Pharmaceutical and Food Processing
Suitable for:
- Packaging systems
- Filling equipment
- Conveyor automation
- Inspection machinery
- Automated production lines
Installation and System Integration
Before installation, engineers should verify:
- Servo drive compatibility
- Power supply specifications
- Brake wiring
- Encoder cable integrity
- Motor power cable condition
- Mechanical alignment
- Shaft coupling installation
- Grounding requirements
Recommended Installation Procedure
- Disconnect system power.
- Mount the servo motor securely.
- Install the shaft coupling.
- Connect the motor power cable.
- Connect the encoder cable.
- Connect the 24 V DC brake supply.
- Configure the servo drive.
- Perform motor identification.
- Tune servo parameters.
- Verify brake operation.
- Test motor rotation.
- Complete commissioning.
Compatible System Components
| Component | Function |
|---|---|
| Allen-Bradley Kinetix Servo Drive | Servo control |
| Logix PLC | Machine control |
| Motion Controller | Motion command generation |
| Servo Power Cable | Power transmission |
| Encoder Feedback Cable | Position feedback |
| 24 V DC Brake Supply | Brake control |
| Planetary Gearbox | Torque multiplication |
| Mechanical Coupling | Power transmission |
| HMI Panel | Operator interface |
| Industrial Ethernet Network | Communication |
Recommended Alternative Models
| Model | Product Type | Recommended Application |
|---|---|---|
| MPL-A220T-EJ74AA | Servo Motor with Holding Brake | Vertical-axis precision motion |
| MPL-A220T-EJ72AA | Servo Motor without Brake | Standard horizontal motion |
| MPL-B220T-EJ74AA | 460 V Servo Motor with Brake | High-voltage applications |
| MPL-A230P-EJ74AA | Larger Servo Motor | Higher torque requirements |
| Kinetix VP Servo Motors | Advanced Servo Motor | High-performance automation |
Key Advantages
- MP-Series low-inertia brushless servo motor
- 230 V AC operation
- Integrated 24 V DC holding brake
- 75 mm compact frame size
- 6000 RPM rated speed
- Single-turn high-resolution encoder
- SpeedTEC quick-connect interface
- Keyed shaft configuration
- Excellent dynamic response
- Compatible with Allen-Bradley Kinetix servo drives
- Approximate weight of 2 kg
Technical FAQs
What is the Allen-Bradley MPL-A220T-EJ74AA?
The MPL-A220T-EJ74AA is an MP-Series low-inertia brushless AC rotary servo motor featuring an integrated 24 V DC holding brake for industrial motion control applications.
What is its rated voltage?
The servo motor operates on 230 V AC, while the holding brake is powered by 24 V DC.
What is the rated speed?
The motor has a rated operating speed of 6000 RPM.
What is the frame size?
The motor features a 75 mm IEC metric frame size.
Does the motor include a holding brake?
Yes. It includes an integrated 24 V DC electromagnetic holding brake, making it suitable for vertical-axis applications.
What type of feedback device does it use?
It uses a single-turn high-resolution encoder for precise closed-loop motion control.
Which servo drives are compatible?
The motor is designed for use with Allen-Bradley Kinetix servo drive systems.
What is the approximate weight?
The motor weighs approximately 2 kg.
Which industries commonly use this servo motor?
It is widely used in packaging, robotics, CNC machining, semiconductor manufacturing, pharmaceutical production, printing, and automated manufacturing.
What are the benefits of the integrated holding brake?
The integrated brake safely holds the motor shaft when power is removed, improving operational safety, preventing load drift, and making the motor ideal for vertical-axis applications.
Conclusion
The Allen-Bradley MPL-A220T-EJ74AA Servo Motor is a compact, high-performance MP-Series low-inertia rotary servo motor engineered for demanding industrial motion control systems. Combining 230 V AC operation, a 75 mm frame size, 6000 RPM performance, a single-turn high-resolution encoder, and an integrated 24 V DC holding brake, it delivers exceptional positioning accuracy, dynamic response, and operational safety.
With its compact construction and approximate weight of 2 kg, the MPL-A220T-EJ74AA provides a dependable motion solution for machine builders and automation engineers requiring precise positioning, secure load holding, and long-term reliability in modern industrial automation systems.
