Allen Bradley 1606-XLS960F-3 Full Technical Overview
1. Product Introduction
The model 1606-XLS960F-3 is a high-capacity industrial DIN rail switching power supply designed to deliver a stable 24–28V DC output with a rated power of 960W, supporting output currents up to 40A. This unit is engineered for three-phase AC input systems, making it suitable for high-load industrial environments where power stability and efficiency are critical.
As part of the 1606-XLS series, this model belongs to the performance-level category within the 1606 family. The “F” designation typically indicates an enhanced version with advanced functionality such as improved dynamic response, extended diagnostics, and higher efficiency, while the “-3” signifies three-phase input capability.
The 1606-XLS960F-3 is widely used in demanding automation systems where large power requirements, system reliability, and continuous operation are essential.
2. Brand and Series
- Brand: Allen Bradley
- Series: 1606-XLS Series (Performance Line – High Power Three-Phase)
- Category: Industrial Switching Power Supply
- Mounting Type: DIN Rail
The XLS series is designed for high efficiency, strong overload capability, and reliable long-term performance in industrial automation systems.
3. Technical Specifications
Main Parameters Table
| Parameter | Specification |
|---|---|
| Model | 1606-XLS960F-3 |
| Output Voltage | 24–28V DC (adjustable) |
| Output Current | 40 A (up to 60A peak) |
| Rated Power | 960 W |
| Input Voltage (AC) | 3 × 380–480V AC |
| Input Voltage (DC) | 450–800V DC |
| Input Frequency | 50–60 Hz |
| Efficiency | approx. 94–96% |
| Power Factor | approx. 0.90–0.96 |
| Hold-up Time | 20–35 ms |
| Inrush Current | low (balanced across phases) |
| Output Ripple | <50–100 mVpp |
| Power Boost | up to 150% (short duration) |
| Reserve Power | up to 60A for short duration |
| Parallel Operation | Supported |
| Redundancy Capability | Supported |
| Protection Functions | Overload, overvoltage, short circuit |
| Signal Output | DC OK relay contact |
| Cooling Method | Natural convection (fanless) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
| Mounting | DIN rail |
| Connection Type | Spring clamp terminals |
| Dimensions (mm) | approx. 120 × 124 × 130 |
| Weight (kg) | approx. 2.40–2.70 kg |
4. Product Features
The 1606-XLS960F-3 incorporates advanced features designed for high-power industrial systems:
- High output capacity of 960W for demanding applications
- Three-phase input design improves efficiency and load balance
- Adjustable 24–28V DC output for flexible system requirements
- High efficiency up to approximately 96% reduces energy loss
- Power boost capability up to 150% for handling peak loads
- Parallel and redundancy operation for system scalability
- Low ripple output ensures stable performance for sensitive equipment
- DC OK relay for monitoring and diagnostics
- Fanless cooling enhances reliability and reduces maintenance
- Compact design relative to high output power
These features ensure reliable performance in high-demand industrial environments.
5. Application Areas
The 1606-XLS960F-3 is widely used in industrial systems requiring high power and reliability:
- Large-scale automation systems
- Industrial production lines and heavy machinery
- Robotics and motion control systems
- Power distribution panels
- Conveyor and material handling systems
- High-density PLC and I/O systems
It is particularly suitable for applications where high current output and three-phase input stability are required.
6. Product Advantages
1. High Power Output
Provides 960W output, suitable for heavy-duty industrial applications.
2. Three-Phase Efficiency
Balanced input reduces stress on electrical infrastructure.
3. Strong Overload Capability
Handles up to 150% load for short durations, ensuring smooth startup.
4. Scalable System Design
Supports parallel and redundancy configurations.
5. Reliable Industrial Performance
Fanless design and robust construction ensure long service life.
7. Recommended Models (Same Series / Related Series)
Comparison Table – Same or Related Series
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLS480E | 24–28V / 20A | 480W | 100–240VAC | ~94% | 84×124×127 | 1.25 |
| 1606-XLS480E-3 | 24–28V / 20A | 480W | 3×380–480VAC | ~95% | 84×124×127 | 1.35 |
| 1606-XLS960E | 24–28V / 40A | 960W | 100–240VAC | ~95% | 120×124×130 | 2.50 |
| 1606-XLS960F-3 | 24–28V / 40A | 960W | 3×380–480VAC | ~96% | 120×124×130 | 2.60 |
| 1606-XLS960E-3 | 24–28V / 40A | 960W | 3×380–480VAC | ~95% | 120×124×130 | 2.60 |
8. Recommended Popular Models (Same Brand)
Comparison Table – Popular Models
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLE240E | 24–28V / 10A | 240W | 100–240VAC | ~91% | 60×124×117 | 0.70 |
| 1606-XLE480E | 24V / 20A | 480W | 100–240VAC | ~92% | 85×124×130 | 1.30 |
| 1606-XLP100E | 24V / 4.2A | 100W | 100–240VAC | ~91% | 75×73×103 | 0.45 |
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | ~94% | 60×124×127 | 0.90 |
| 1606-XL480EP | 24–28V / 20A | 480W | 100–240VAC | ~93% | 124×60×125 | 1.80 |
