Allen Bradley 1606-XLE480EP Power Supply — Detailed Technical Overview
1. Product Overview
The Allen Bradley 1606-XLE480EP is a high-efficiency switched-mode power supply designed for industrial automation systems that require stable 24V DC output at higher load levels. It belongs to the enhanced performance category within the 1606 product family and is engineered for continuous operation in demanding environments.
With a rated output of 480W and 20A current capacity, this model is suitable for powering multiple field devices, PLC systems, and distributed control architectures. Its compact DIN rail design and high energy efficiency make it ideal for control cabinets where both space and thermal management are important.
2. Brand Information
Brand: Allen Bradley
This brand is widely used in industrial automation and control systems, offering a complete ecosystem of PLCs, drives, and power solutions. Its products are known for reliability, system compatibility, and long operational life in industrial environments.
3. Series Information
Series: 1606 Switched Mode Power Supplies — XLE Series
The XLE series is positioned as an enhanced (essential) performance line, sitting between basic and high-performance ranges.
Key characteristics include:
- Improved efficiency and thermal performance
- Higher reliability compared to entry-level models
- Built-in diagnostics such as DC-OK signal
- Power reserve capability (up to 120%)
- Compact DIN rail design for industrial panels
This series is commonly used in medium to high-demand automation applications.
4. Technical Parameters
Main Specifications Table
| Parameter | Value |
|---|---|
| Model | 1606-XLE480EP |
| Output Voltage | 24–28 V DC |
| Rated Output Voltage | 24 V DC |
| Output Current | 20 A |
| Output Power | 480 W |
| Input Voltage | 100–240 VAC (1-phase) / 110–150 V DC |
| Input Frequency | 50–60 Hz |
| Efficiency | Up to 95.6% |
| Power Factor | 0.98 typical |
| Power Reserve | ~120% |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail |
| Connection Type | Screw Terminal |
| Operating Temperature | -25°C to +70°C |
| Dimensions (W×H×D) | 60 × 124 × 117 mm |
| Weight (kg) | 1.10 |
5. Product Features
The 1606-XLE480EP is designed to deliver stable and efficient power under continuous industrial operation.
- High efficiency up to approximately 95.6%, reducing energy loss
- Adjustable output voltage (24–28V DC)
- Integrated DC-OK relay contact for monitoring system status
- Active inrush current limitation for safer startup
- Power reserve capability for handling peak loads
- Low ripple and noise for sensitive equipment
- Fanless convection cooling for silent and maintenance-free operation
- Built-in protections: overload, short circuit, overvoltage, and thermal protection
6. Product Applications
This power supply is widely used in industrial automation systems that require higher power density and stable operation.
Typical applications include:
- PLC and distributed I/O systems
- Industrial control panels
- Robotics and motion control systems
- Conveyor and packaging machinery
- Process automation equipment
- Communication and network devices
It is particularly suitable for systems with higher current demand and continuous operation requirements.
7. Product Advantages
High Power Density
Delivers 480W output in a compact housing, optimizing cabinet space usage.
Excellent Efficiency
Efficiency above 95% reduces heat generation and improves system reliability.
Power Reserve Capability
Handles temporary overload conditions without output voltage drop.
Reliable Industrial Design
Built for continuous operation with robust internal components.
Easy Integration
Standard DIN rail mounting and screw terminals simplify installation.
8. Recommended Models — Same Series / Related Series
Table: XLE / Related Models
| Model | Output Voltage | Current | Power | Input Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLE120E | 24 V DC | 5 A | 120 W | 100–240 VAC | 50 × 124 × 124 | 0.50 |
| 1606-XLE240E | 24 V DC | 10 A | 240 W | 100–240 VAC | 60 × 124 × 124 | 0.70 |
| 1606-XLE960DX-3N | 24 V DC | 40 A | 960 W | 320–575 VAC | 120 × 124 × 127 | 2.50 |
| 1606-XLB480E | 24 V DC | 20 A | 480 W | 85–264 VAC | 80 × 124 × 124 | 1.00 |
| 1606-XLS480E | 24–28 V DC | 20 A | 480 W | 100–240 VAC | 80 × 124 × 124 | 1.20 |
9. Recommended Models — Same Brand Popular Models
Table: Popular Power Supply Models
| Model | Output Voltage | Current | Power | Input Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLB120E | 24 V DC | 5 A | 120 W | 85–264 VAC | 39 × 124 × 124 | 0.37 |
| 1606-XLB240E | 24 V DC | 10 A | 240 W | 90–264 VAC | 49 × 124 × 124 | 0.56 |
| 1606-XLP100E | 24 V DC | 4.2 A | 100 W | 100–240 VAC | 40 × 110 × 100 | 0.35 |
| 1606-XLS480E | 24–28 V DC | 20 A | 480 W | 100–240 VAC | 80 × 124 × 124 | 1.20 |
| 1606-XLS960E | 24–28 V DC | 40 A | 960 W | 100–240 VAC | 120 × 124 × 124 | 2.00 |
