Allen Bradley 1606-XL240E Full Technical Overview
1. Product Introduction
The model 1606-XL240E is a DIN rail mounted industrial switching power supply designed for stable and continuous DC power delivery in automation systems. It provides a regulated 24–28V DC output with a rated power of 240W, making it suitable for medium to high load industrial applications.
This unit belongs to the 1606-XL series, which is widely recognized as a standard-class power supply family offering solid reliability, simple installation, and dependable performance. It is commonly used in control cabinets, PLC systems, and machine automation environments.
The product has been discontinued and typically replaced by newer series models, but it remains widely used in existing industrial systems due to its stable performance and compatibility.
2. Brand and Series
- Brand: Allen Bradley
- Series: 1606-XL Series
- Type: Switching Power Supply (DIN Rail)
The 1606-XL series is positioned as a general-purpose industrial power supply line, balancing cost efficiency and reliability for everyday automation needs.
3. Technical Specifications
Main Parameters Table
| Parameter | Specification |
|---|---|
| Model | 1606-XL240E |
| Output Voltage | 24–28V DC |
| Output Current | 10 A |
| Rated Power | 240 W |
| Input Voltage Range | 100–120 / 200–240V AC or 240–375V DC |
| Input Frequency | 47–63 Hz |
| Input Current | <6A @115V / <2.6A @230V |
| Efficiency | approx. 92% |
| Hold-up Time | ≥20 ms |
| Ripple & Noise | <100 mVpp |
| Protection | Overload, overvoltage, short circuit |
| Cooling Method | Natural convection |
| Mounting | DIN rail |
| Operating Temperature | 0°C to +70°C |
| Protection Class | IP20 |
| Certifications | UL, CE, EMC |
| Dimensions (mm) | approx. 60 × 125 × 124 |
| Weight (kg) | approx. 0.80 kg |
4. Product Features
The 1606-XL240E is designed with practical industrial functionality:
- Wide input voltage range supports global deployment
- Adjustable output voltage (24–28V DC) for flexible system requirements
- High efficiency reduces energy consumption and heat generation
- Compact DIN rail structure saves installation space
- Fanless cooling ensures low maintenance and long service life
- Built-in protection mechanisms enhance system safety
These features make it suitable for continuous operation in demanding environments.
5. Application Areas
The 1606-XL240E is widely used in:
- PLC and industrial control systems
- Automation production lines
- Packaging and logistics equipment
- CNC machinery
- Robotics systems
- Process control installations
It is particularly suitable for applications requiring stable 24V DC power with moderate load demands.
6. Product Advantages
1. Proven Reliability
Designed for long-term industrial operation with stable output performance.
2. Flexible Voltage Output
Adjustable output allows adaptation to different device requirements.
3. Compact and Practical Design
Slim structure optimizes panel space usage.
4. Energy Efficiency
High efficiency reduces operational costs and thermal stress.
5. Easy Installation
DIN rail mounting simplifies integration into control cabinets.
7. Recommended Models (Same Series / Related Series)
Comparison Table – Same or Related Series
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XL120D | 24V / 5A | 120W | 85–264VAC | ~92% | 40×124×117 | 0.60 |
| 1606-XL240DR | 24V / 10A | 240W | 85–264VAC | ~93% | 60×124×117 | 0.85 |
| 1606-XL480E | 24V / 20A | 480W | 100–240VAC | ~93% | 85×125×130 | 1.30 |
| 1606-XLE240E | 24V / 10A | 240W | 100–240VAC | ~91% | 60×124×117 | 0.80 |
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | ~94% | 60×124×127 | 0.90 |
8. Recommended Popular Models (Same Brand)
Comparison Table – Popular Models
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | 94% | 60×124×127 | 0.90 |
| 1606-XLS480E | 24V / 20A | 480W | 100–240VAC | 95% | 85×124×130 | 1.40 |
| 1606-XLP100E | 24V / 4.2A | 100W | 100–240VAC | 91% | 40×124×117 | 0.55 |
| 1606-XLE120E | 24V / 5A | 120W | 100–240VAC | 90% | 40×125×113 | 0.50 |
| 1606-XLE480E | 24V / 20A | 480W | 100–240VAC | 92% | 85×124×130 | 1.30 |
