Allen Bradley 1606-XL240E-3C Full Technical Overview
1. Product Introduction
The model 1606-XL240E-3C is a DIN rail mounted industrial switching power supply designed to provide a stable 24–28V DC output with a rated power of 240W. It is built for general industrial automation systems where reliability, simplicity, and cost-effectiveness are key considerations.
This unit belongs to the 1606-XL series, which represents a standard-level product line focused on stable performance without excessive complexity. The “-3C” variant indicates two important characteristics: three-phase AC input capability and conformal coating protection, allowing the device to perform reliably in environments with moisture, dust, or light chemical exposure.
Although newer series have introduced higher efficiency and advanced features, this model remains widely deployed due to its proven stability and robust construction.
2. Brand and Series
- Brand: Allen Bradley
- Series: 1606-XL Series (Standard Line – Three-Phase Coated Version)
- Category: Industrial Switching Power Supply
- Mounting Type: DIN Rail
The XL series is positioned as a reliable and practical solution for standard industrial power supply requirements.
3. Technical Specifications
Main Parameters Table
| Parameter | Specification |
|---|---|
| Model | 1606-XL240E-3C |
| Output Voltage | 24–28V DC (adjustable) |
| Output Current | 10 A |
| Rated Power | 240 W |
| Input Voltage (AC) | 3 × 380–480V AC |
| Input Frequency | 50–60 Hz |
| Efficiency | approx. 90–92% |
| Power Factor | approx. 0.85–0.92 |
| Hold-up Time | 20–30 ms |
| Inrush Current | low (distributed across phases) |
| Output Ripple | <100 mVpp |
| Parallel Operation | Not typically supported |
| Protection Functions | Overload, overvoltage, short circuit |
| Signal Output | Basic DC OK indication |
| Special Feature | Conformal coating (environmental protection) |
| Cooling Method | Natural convection (fanless) |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
| Mounting | DIN rail |
| Connection Type | Screw / clamp terminals |
| Dimensions (mm) | approx. 70 × 124 × 117 |
| Weight (kg) | approx. 1.00–1.20 kg |
4. Product Features
The 1606-XL240E-3C focuses on essential industrial functionality:
- Three-phase input design for stable power distribution
- Conformal coating improves resistance to harsh environments
- Adjustable output voltage for flexible applications
- Compact DIN rail mounting for easy installation
- Stable DC output under varying load conditions
- Fanless design reduces maintenance and increases reliability
- Basic status indication simplifies troubleshooting
- Proven design suitable for long-term operation
This model emphasizes durability and simplicity over advanced digital features.
5. Application Areas
The 1606-XL240E-3C is widely used in standard industrial scenarios:
- PLC-based control systems
- Industrial control panels
- Packaging and assembly machinery
- Conveyor systems
- General automation equipment
- Environments with moderate humidity or dust
It is particularly suitable for systems where three-phase input is available and environmental resistance is required.
6. Product Advantages
1. Environmental Durability
Conformal coating protects internal components from moisture and contamination.
2. Stable Three-Phase Operation
Balanced input improves electrical reliability and reduces stress.
3. Cost-Effective Design
Provides essential functionality without unnecessary complexity.
4. Easy Integration
Compact size and DIN rail mounting simplify installation.
5. Proven Reliability
Widely used in legacy systems with consistent long-term performance.
7. Recommended Models (Same Series / Related Series)
Comparison Table – Same or Related Series
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XL120D | 24V / 5A | 120W | 100–240VAC | ~90% | 50×120×100 | 0.70 |
| 1606-XL240E | 24–28V / 10A | 240W | 100–240VAC | ~91% | 60×125×124 | 0.80 |
| 1606-XL240E-3C | 24–28V / 10A | 240W | 3×380–480VAC | ~91% | 70×124×117 | 1.10 |
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | ~94% | 60×124×127 | 0.90 |
| 1606-XLS480E-3C | 24–28V / 20A | 480W | 3×380–480VAC | ~95% | 65×124×127 | 1.30 |
8. Recommended Popular Models (Same Brand)
Comparison Table – Popular Models
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLE240E | 24–28V / 10A | 240W | 100–240VAC | ~91% | 60×124×117 | 0.70 |
| 1606-XLE480E | 24V / 20A | 480W | 100–240VAC | ~92% | 85×124×130 | 1.30 |
| 1606-XLP100E | 24V / 4.2A | 100W | 100–240VAC | ~91% | 75×73×103 | 0.45 |
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | ~94% | 60×124×127 | 0.90 |
| 1606-XLS960E | 24–28V / 40A | 960W | 100–240VAC | ~95% | 120×124×130 | 2.50 |
