Allen Bradley 1606-XL240DR Full Technical Overview
1. Product Introduction
The model 1606-XL240DR is an industrial DIN rail switching power supply designed to deliver reliable DC power for automation and control systems. It provides a regulated 24V DC output with a rated power of 240W, making it suitable for medium-load industrial applications such as PLC systems, control panels, and distributed automation equipment.
This model belongs to the 1606-XL series, a widely used standard power supply range known for its durability, simplicity, and stable performance. The “DR” designation typically indicates enhanced functionality such as redundancy capability, allowing the unit to be used in parallel systems where uninterrupted operation is critical.
The device is engineered for continuous operation in industrial environments and is commonly installed inside control cabinets where reliability and compact structure are essential.
2. Brand and Series
- Brand: Allen Bradley
- Series: 1606-XL Series
- Category: Industrial Switching Power Supply
- Mounting: DIN Rail
The 1606-XL series is designed for general-purpose industrial use, offering a balance between performance, cost, and installation convenience.
3. Technical Specifications
Main Parameters Table
| Parameter | Specification |
|---|---|
| Model | 1606-XL240DR |
| Output Voltage | 24V DC |
| Output Current | 10 A |
| Rated Power | 240 W |
| Input Voltage Range | 85–264V AC / 90–375V DC |
| Input Frequency | 47–63 Hz |
| Efficiency | Up to 92–93% |
| Output Ripple | <100 mVpp |
| Hold-up Time | ≥20 ms |
| Inrush Current | Controlled |
| Parallel Operation | Supported (redundancy mode) |
| Protection Functions | Overload, overvoltage, short circuit |
| Cooling Method | Natural convection |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Protection Class | IP20 |
| Mounting Type | DIN rail |
| Dimensions (mm) | approx. 60 × 124 × 117 |
| Weight (kg) | approx. 0.85 kg |
4. Product Features
The 1606-XL240DR is designed with practical industrial requirements in mind:
- Wide input voltage range for global usage
- Stable 24V output suitable for control systems
- Redundancy capability for high-availability systems
- High efficiency minimizes heat and power loss
- Compact DIN rail design for easy installation
- Fanless cooling increases reliability and reduces maintenance
- LED indicators for quick operational status monitoring
These features make it suitable for both standalone and redundant power configurations.
5. Application Areas
The 1606-XL240DR is commonly used in:
- PLC-based automation systems
- Redundant power supply architectures
- Industrial control cabinets
- Packaging and conveyor systems
- Process control environments
- Robotics and automated assembly lines
- Infrastructure systems requiring uninterrupted operation
It is particularly suitable for applications where power continuity is critical.
6. Product Advantages
1. Redundancy Support
Allows parallel operation, ensuring system uptime in case of failure.
2. High Reliability
Built for continuous operation in demanding industrial environments.
3. Compact Design
Optimized for space-saving installation in control cabinets.
4. Energy Efficiency
High efficiency reduces operating costs and internal heat.
5. Easy Integration
Simple wiring and DIN rail mounting reduce installation time.
7. Recommended Models (Same Series / Related Series)
Comparison Table – Same or Related Series
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XL120D | 24V / 5A | 120W | 85–264VAC | ~92% | 40×124×117 | 0.60 |
| 1606-XL240E | 24V / 10A | 240W | 100–240VAC | ~92% | 60×125×124 | 0.80 |
| 1606-XL480E | 24V / 20A | 480W | 100–240VAC | ~93% | 85×125×130 | 1.30 |
| 1606-XLS240E | 24–28V / 10A | 240W | 100–240VAC | ~94% | 60×124×127 | 0.90 |
| 1606-XLE240E | 24V / 10A | 240W | 100–240VAC | ~91% | 60×124×117 | 0.80 |
8. Recommended Popular Models (Same Brand)
Comparison Table – Popular Models
| Model | Output | Power | Input Voltage | Efficiency | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1606-XLS240E | 24V / 10A | 240W | 100–240VAC | 94% | 60×124×127 | 0.90 |
| 1606-XLS480E | 24V / 20A | 480W | 100–240VAC | 95% | 85×124×130 | 1.40 |
| 1606-XLP100E | 24V / 4.2A | 100W | 100–240VAC | 91% | 40×124×117 | 0.55 |
| 1606-XLE120E | 24V / 5A | 120W | 100–240VAC | 90% | 40×125×113 | 0.50 |
| 1606-XLE480E | 24V / 20A | 480W | 100–240VAC | 92% | 85×124×130 | 1.30 |
