Product Overview
The SDCS-UCM-1C is a Universal Control Module for ABB DCS series converters. It functions as a central interface for control and signal processing within DC drive systems. The module manages inputs from operator panels, sensors, and upstream controllers, and distributes control signals to the relevant power electronics and interface boards.
The SDCS-UCM-1C is designed to improve system reliability, reduce wiring complexity, and provide precise signal handling in industrial environments. Its compact and modular form factor allows for quick installation and replacement, making it ideal for both new installations and retrofits.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | SDCS-UCM-1C (3ADT220090R0008) |
| Product Type | Universal Control Module |
| Primary Function | Central signal and control interface for DC drive systems |
| Input Signals | Analog, digital, and logic inputs from sensors and operator panels |
| Output Signals | Control signals to interface boards (REB, PIN, POW) |
| Operating Temperature | –20 °C to +55 °C |
| Storage Temperature | –40 °C to +70 °C |
| Relative Humidity | Up to 95% non-condensing |
| Mounting | Rack-mounted / plug-in module |
| Dimensions (L × W × H) | 250 × 90 × 200 mm |
| Weight | 1.2 kg |
| Compatibility | ABB DCS500/DCS600/DCS800 converters |
| Notes | Not hot-swappable; must power down before replacement |
Product Description
The SDCS-UCM-1C serves as the brain of the DCS drive’s control system, coordinating inputs from sensors, operator commands, and upstream logic controllers. It processes these signals and forwards the appropriate control instructions to power and interface modules such as REB, PIN, and POW boards.
It ensures timely and accurate signal distribution, helping maintain safe, stable, and efficient operation of high-power DC drives. Its modular design allows quick diagnostics and replacement, reducing downtime during maintenance.
Product Applications
-
Heavy industrial DC drives in steel, mining, and pulp & paper industries.
-
Retrofits and rebuilds of ABB DCS500/DCS600 converters.
-
Systems requiring precise control of forward and reverse motor operation.
-
Automation networks where centralized control and signal coordination is critical.
-
Industrial plants looking to reduce wiring complexity and improve reliability.
Product Advantages
-
Centralized control interface for all signal processing.
-
Modular and compact for easy installation.
-
Reduces system wiring and simplifies maintenance.
-
Enhances signal integrity and timing accuracy.
-
Compatible with multiple DCS converter series.
-
Rugged and durable in industrial environments.
-
Supports safe forward/reverse motor operation.
-
Quick replacement reduces downtime.
-
Scalable for complex drive configurations.
-
Integrates seamlessly with ABB DCS control architecture.
Brand and Series
-
Brand: ABB
-
Series: DCS Universal Control Modules (UCM series)
Recommended Related or Same-Series Models
| Model | Product Type | Main Function | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| SDCS-UCM-2C | Control Module | Enhanced logic processing for DCS | 250×90×200 | 1.3 |
| SDCS-UCM-3B | Control Module | Additional signal routing for multiple bridges | 250×90×200 | 1.4 |
| SDCS-PIN-51 | Measuring Interface Board | Provides firing pulses upstream of REB boards | 100×70×20 | 0.42 |
| SDCS-REB-1 | Routing Board | Routes firing pulses to bridge modules | 254×25×248 | 0.4 |
| SDCS-POW-1 | Power Interface Board | Supplies power to control boards | 115×65×22 | 0.38 |
Recommended Popular ABB Models
| Model | Product Type | Application | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS580‑01‑046A‑4 | AC Drive | General variable-speed motor control | 370×203×200 | 8.2 |
| DCS800‑S02‑0050‑05 | DC Drive | Heavy-duty DC motor control | 425×270×190 | 12.5 |
| ACS880‑01‑145A‑3 | Industrial Drive | Precision motion/torque | 540×270×245 | 15.0 |
| ACS355‑03E‑07A3‑4 | Compact Drive | Light industrial automation | 125×70×130 | 1.2 |
| ACS150‑03E‑02A4‑4 | Micro Drive | Small machine/fan/pump control | 98×70×120 | 1.0 |
FAQ (Frequently Asked Questions)
Q1: What is the SDCS-UCM-1C used for?
A1: Centralized signal processing and control for ABB DCS drive systems.
Q2: Which DCS converters is it compatible with?
A2: DCS500, DCS600, and DCS800 series.
Q3: What are its dimensions and weight?
A3: 250 × 90 × 200 mm, 1.2 kg.
Q4: Can it be replaced while the system is powered?
A4: No, the module must be powered down before replacement.
Q5: What type of signals does it handle?
A5: Analog, digital, and logic inputs; control outputs to PIN, REB, and POW boards.
Q6: What happens if the module fails?
A6: Drive operation may be compromised, causing potential motor trips.
Q7: Is it suitable for complex bridge or multi-motor systems?
A7: Yes, it supports scalable configurations and multiple bridge setups.
Q8: Does it require an external power supply?
A8: It draws power from the DCS converter rack through standard interfaces.
Q9: What environmental conditions is it designed for?
A9: Industrial environments with vibration, temperature variation, and electrical noise.
Q10: What maintenance is required?
A10: Check connections, inspect for damage, clean periodically, and replace as needed.
Authenticity guarantee
