Product Technical Documentation – ABB CP435T (1SBP260193R1001)
1) Brand and Series Overview
Brand: ABB
Series: CP4xx Operator Interface Terminals
The CP4xx series is a range of industrial operator interface terminals designed to facilitate interaction between human operators and programmable logic controller (PLC) systems in automated environments. These terminals provide visualization of process data, alarm display, parameter entry, and basic control functions.
The CP435T is a high-function member of this series, offering a larger and clearer graphic display, extensive keypad, and ergonomic design for enhanced usability in complex industrial applications.
2) Product Overview
The ABB CP435T (1SBP260193R1001) is a panel mount, monochrome graphical terminal designed for industrial automation applications. It integrates a high-resolution graphic LCD with a comprehensive tactile keypad, allowing operators to monitor system performance, input parameters, acknowledge alarms, and navigate through multi-level menus.
The CP435T is tailored to environments requiring clear data presentation, robust mechanical input, and efficient operation in moderately demanding industrial settings. Its larger display and richer key layout make it suitable for applications involving frequent operator interaction.
3) Technical Parameters
| Parameter | Specification |
|---|---|
| Model | CP435T (1SBP260193R1001) |
| Product Type | Operator Interface Terminal – Monochrome |
| Series | CP4xx Control Products |
| Display Type | Monochrome Graphic LCD |
| Display Size | Approx. 7.0 in diagonal |
| Resolution | 480 × 272 pixels |
| Keypad | 32 Function Keys + Navigation Keys |
| Backlight | LED Backlight |
| Communication Interfaces | Serial / Fieldbus Compatible |
| Supply Voltage | 24 V DC |
| Power Consumption | ≤ 10 W |
| Mounting | Panel Mount |
| Protection Rating | IP65 Front (panel mounted) |
| Operating Temperature | −10 °C to +55 °C |
| Storage Temperature | −20 °C to +70 °C |
| Relative Humidity | 10–90 % non-condensing |
| Dimensions (H × W × D) | 150 × 220 × 50 mm |
| Cut-out Size | 140 × 210 mm |
| Weight (kg) | 0.62 kg |
| Housing Material | Industrial-grade reinforced polymer |
4) Product Description
The CP435T is an advanced operator interface terminal intended for industrial control panels and machine interfaces where extensive operator interaction is required. The larger high-resolution display provides more room for structured data, process values, and alarm lists, enabling operators to grasp system status at a glance.
The extensive keypad with labeled function keys and directional controls enables intuitive navigation through multi-level menus, setpoint adjustments, and command entry. The LED backlight enhances display readability under varying ambient lighting conditions.
This model communicates with PLCs and other automation controllers via serial communications or fieldbus protocols, making it flexible for integration in diverse automation systems.
5) Key Advantages
• Large High-Resolution Display: Supports detailed data presentation and multi-level menus.
• Rich Keypad Layout: A large number of function keys enhance operator efficiency.
• Strong Industrial Design: Front panel is IP65 rated and built for industrial durability.
• LED Backlight: Ensures readability in dim lighting or high-contrast environments.
• Flexible Communications: Compatible with serial and fieldbus communication links.
• High Power Handling: Up to 10 W power allows advanced display usage.
• Ergonomic Operation: Designed for regular human interaction in control rooms or production floors.
• Easy Panel Integration: Standard cut-out size for control panel installation.
6) Typical Applications
• Machine operator stations for complex production equipment
• Process visualization and monitoring panels
• Alarm handling and event logging interfaces
• Parameter entry and setpoint configuration
• Control stations for packaging, assembly, or batch systems
• Diagnostic and troubleshooting terminals
• Distributed automation control panels
• Production data display for operation management
7) Five Related Models (Same Series or Closely Related)
| Model | Display Type | Communication | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| CP420B | Monochrome Graphic LCD | Serial | 110 × 170 × 42 | 0.38 |
| CP430B | Monochrome Graphic LCD | Serial | 120 × 190 × 45 | 0.41 |
| CP430BP | Monochrome Graphic LCD | Serial | 120 × 190 × 45 | 0.43 |
| CP430T | Monochrome Graphic LCD | Serial | 120 × 190 × 45 | 0.42 |
| CP450M | Monochrome Graphic LCD | Serial | 130 × 200 × 50 | 0.55 |
8) Five Popular ABB Industrial Models
| Model | Product Type | Main Rating | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS580-01-07A6-4 | Variable Frequency Drive | 7.5 kW | 358 × 152 × 203 | 5.8 |
| ACS880-01-022A-4 | High Performance Drive | 22 kW | 400 × 220 × 210 | 8.0 |
| Emax 2 E2.2 | Air Circuit Breaker | 1600 A | 371 × 210 × 268 | 8.2 |
| Tmax XT4N | Molded Case Circuit Breaker | 250 A | 140 × 105 × 160 | 2.1 |
| AF16-30-10 | Contactor | 16 A | 90 × 55 × 78 | 0.42 |
9) Frequently Asked Questions (FAQ)
Q1: What is the CP435T mainly designed for?
A1: It serves as an advanced operator interface terminal for industrial automation, offering a larger display and extended keypad for enhanced human-machine interaction.
Q2: What display type does the CP435T use?
A2: A monochrome graphic LCD with LED backlight.
Q3: What are its power requirements?
A3: It operates on a 24 V DC supply with ≤ 10 W consumption.
Q4: What are the terminal’s dimensions?
A4: 150 × 220 × 50 mm.
Q5: What is the weight of the model?
A5: Approximately 0.62 kg.
Q6: What protection rating does it have?
A6: It has IP65 front protection when panel mounted.
Q7: What communications interfaces does it support?
A7: Serial and fieldbus compatible interfaces for PLC connection.
Q8: Can it display alarms and diagnostic messages?
A8: Yes, it supports structured alarm display and system diagnostics.
Q9: Is it suitable for advanced operator interaction?
A9: Yes, its large graphical display and extensive keypad are designed for frequent operator use.
Q10: In what environments is CP435T typically installed?
A10: It is typically installed in industrial control panels, machine stations, and production floor operator points.
