Product Technical Documentation – ABB CP430BP-ETH (1SBP260194R1001)
1) Brand and Series Information
Brand: ABB
Series: CP4xx Operator Interface Terminal Series
The CP4xx series is a family of compact operator interface terminals designed for industrial automation systems. These devices provide structured communication between operators and PLC-based control systems. They are typically installed in machine control panels and production equipment where reliability, durability, and simplicity are essential.
The CP430BP-ETH represents an enhanced Ethernet-enabled version within the CP4xx family. It combines a graphical monochrome display, extended keypad, and integrated Ethernet communication, making it suitable for modern automation networks.
2) Product Overview
The ABB CP430BP-ETH (1SBP260194R1001) is a panel-mounted operator interface terminal equipped with Ethernet communication capability. It is designed to provide operators with real-time access to process information, alarms, machine status, and parameter configuration.
The integrated Ethernet port allows seamless connection to PLC systems and industrial networks, improving communication speed and flexibility compared to serial-only versions.
This model is particularly suited for installations where network connectivity and structured visualization are required without implementing a full touchscreen HMI system.
3) Technical Parameters
| Parameter | Specification |
|---|---|
| Model | CP430BP-ETH (1SBP260194R1001) |
| Product Type | Operator Interface Terminal – Monochrome with Ethernet |
| Series | CP4xx |
| Display Type | Monochrome Graphic LCD |
| Display Size | Approx. 5.7 in diagonal |
| Resolution | 320 × 240 pixels |
| Keypad | 24 Function Keys + Navigation Keys |
| Backlight | High-brightness LED |
| Communication Interfaces | Ethernet (RJ45), Serial Port |
| Network Speed | 10/100 Mbps |
| Supply Voltage | 24 V DC |
| Power Consumption | ≤ 9 W |
| Mounting Type | Panel Mount |
| Front Protection | IP65 (panel installed) |
| Operating Temperature | −10 °C to +55 °C |
| Storage Temperature | −20 °C to +70 °C |
| Relative Humidity | 10–90 % non-condensing |
| Dimensions (H × W × D) | 120 × 190 × 45 mm |
| Panel Cut-out | 112 × 182 mm |
| Weight (kg) | 0.45 kg |
| Housing Material | Industrial-grade reinforced polymer |
4) Detailed Product Description
The CP430BP-ETH is designed for industrial environments where reliable operator communication and network integration are essential. The graphical LCD provides structured menus, numeric data, status bars, and alarm lists in a clear monochrome format.
The enhanced keypad includes multiple programmable function keys, allowing operators to quickly navigate between screens and trigger predefined control actions.
The integrated Ethernet interface enables fast communication with PLC systems and industrial automation networks. This improves data transfer speed and simplifies system architecture compared to purely serial communication terminals.
Its IP65 front protection ensures resistance against dust and water splashes, making it suitable for installation in exposed production areas. The device is built for continuous operation and long-term stability in demanding industrial conditions.
5) Product Advantages
• Integrated Ethernet Connectivity – Enables modern network-based PLC communication.
• Clear Graphic Visualization – 320 × 240 pixel display ensures structured data presentation.
• Extended Keypad Layout – 24 programmable function keys enhance usability.
• Industrial Durability – IP65 front panel protection.
• Compact Footprint – Fits standard control cabinet cut-outs.
• Low Power Consumption – Energy-efficient 24 V DC operation.
• Improved Communication Speed – 10/100 Mbps Ethernet interface.
• Reliable Continuous Operation – Designed for 24/7 industrial use.
6) Typical Applications
• Machine operator panels in manufacturing plants
• PLC-based process monitoring stations
• Packaging machinery control interfaces
• Production line visualization panels
• Alarm management terminals
• Industrial network-connected operator stations
• Equipment diagnostics and parameter setting
• Distributed automation system interface
7) Five Related Models (Same Series or Closely Related)
| Model | Display Type | Communication | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| CP410M | Monochrome LCD | Serial | 84 × 138 × 35 | 0.25 |
| CP415M | Monochrome LCD | Serial | 100 × 160 × 40 | 0.35 |
| CP420B | Monochrome LCD | Serial | 110 × 170 × 42 | 0.38 |
| CP430B | Monochrome Graphic | Serial | 120 × 190 × 45 | 0.41 |
| CP430BP | Monochrome Graphic | Serial | 120 × 190 × 45 | 0.43 |
8) Five Popular ABB Industrial Models
| Model | Product Type | Main Rating | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ACS580-01-07A6-4 | Variable Frequency Drive | 7.5 kW | 358 × 152 × 203 | 5.8 |
| ACS880-01-022A-4 | High Performance Drive | 22 kW | 400 × 220 × 210 | 8.0 |
| Emax 2 E2.2 | Air Circuit Breaker | 1600 A | 371 × 210 × 268 | 8.2 |
| Tmax XT4N | Molded Case Circuit Breaker | 250 A | 140 × 105 × 160 | 2.1 |
| AF16-30-10 | Contactor | 16 A | 90 × 55 × 78 | 0.42 |
9) Frequently Asked Questions (FAQ)
Q1: What makes CP430BP-ETH different from CP430BP?
A1: It includes integrated Ethernet communication for network-based PLC connectivity.
Q2: What is the power requirement?
A2: 24 V DC supply.
Q3: What are the dimensions?
A3: 120 × 190 × 45 mm.
Q4: What is the weight of the device?
A4: Approximately 0.45 kg.
Q5: What communication interfaces are available?
A5: Ethernet (RJ45) and serial interface.
Q6: Is it suitable for harsh industrial environments?
A6: Yes, it features IP65 front protection when panel mounted.
Q7: What resolution does the display support?
A7: 320 × 240 pixels.
Q8: Does it support alarm display?
A8: Yes, it supports alarm, diagnostics, and system messages.
Q9: What temperature range can it operate in?
A9: −10 °C to +55 °C.
Q10: Is it touchscreen?
A10: No, it uses a keypad-based interface with programmable function keys.
