Product Overview
The SDCS‑MP‑1 is a modular signal/measurement board designed as part of ABB’s DCS (Drive Control System) modular architecture. It functions as a key module for signal measurement, monitoring or internal logic in industrial drive systems. This board enables precise measurement or monitoring of internal signals in the drive system, and is built to integrate seamlessly with ABB’s DCS platform modules.
This product is typically used in drive control cabinets, automation systems, or retrofit situations where a standardised measurement board is required. It supports industrial usage with compact form‑factor, compatibility with the modular DCS system ecosystem, and service‑friendly design.
Product Parameters
| Parameter | Description |
|---|---|
| Model | SDCS‑MP‑1 |
| Part Number | 3BSE005635R0001 |
| Product Type | Measurement/Signal Board Module |
| Brand | ABB |
| Series | DCS Control System Series |
| Supply Voltage | Typically 24 V DC logic supply (board electronics) |
| Function | Signal measurement, internal monitoring or pin‑test board in drive system |
| Operating Temperature | Approx. –20 °C to +70 °C |
| Dimensions (W × H × D) | Approx. 180 mm × 140 mm × 25 mm |
| Weight (kg) | Approx. 0.23 kg (various sources list ~0.31 kg or ~0.55 kg) |
| Mounting | Module frame or board‑slot mounting inside drive cabinet |
| Compliance | Industrial automation and drive‑system board standards |
Product Description
The SDCS‑MP‑1 board is designed to be installed within ABB’s DCS modular system, where it acts as a measurement, monitoring or test pin board. In many installations it is used for internal signal capture, logic verification or measurement of drive system parameters. The board connects with other modular components (control board, I/O board, excitation board) to provide measurement feedback or signal analysis.
Because the board is designed for internal drive system use, it has a compact footprint, lightweight construction and form‑factor compatible with ABB’s modular rack or cabinet architecture. It simplifies maintenance and upgrade tasks: instead of replacing larger units, this measurement board can be swapped or upgraded.
Applications may include drive retrofit projects, measurement verification during commissioning, service‑spare usage in industrial drives, or application where internal signal measurement is required. The board supports industrial environmental conditions and is service oriented.
Product Applications
-
Signal measurement or monitoring board inside DC or AC drive cabinets.
-
Industrial drive retrofit projects where internal measurement logic needs standardised module.
-
Service/spare inventory: measurement board ready for field replacement.
-
Automation systems where internal pin‑test or logic verification is required.
-
Manufacturing lines (steel, paper, chemical, marine) using modular drive systems.
-
Drives that must incorporate measurement or monitoring modules to maintain system control.
-
Maintenance setups where board swap reduces downtime by modular replacement.
-
Drive systems in harsh industrial environments requiring robust module design.
Product Advantages
-
Modular Serviceability – Enables measurement/monitor board replacement without major system disruption.
-
Compact & Lightweight – Approximately 0.23 kg, minimal footprint in control cabinets.
-
Seamless Integration – Matches ABB DCS modular architecture for ease of installation and compatibility.
-
Industrial‑Grade Design – Supports harsh environments, wide temperature range and heavy use.
-
Cost‑Effective Spare Strategy – Having this board as spare reduces need to replace full drive modules.
-
Flexible Deployment – Can be used in new installations or retrofit scenarios.
-
Reduced Downtime – Modular form allows quick swap‑out leading to faster maintenance.
-
Standardised Module – Ease of stocking and system standardisation across installations.
Brand Information
Brand: ABB
ABB is a global leader in industrial automation, motor drives, power electronics and control systems. The DCS series offers modular components for drives and automation, renowned for reliability and long service life. The SDCS‑MP‑1 board is one example of ABB’s modular‑drive ecosystem.
Product Series
Series: DCS Control System Series
Within this series, modules include control boards (CON), I/O boards (IOB/IOE), measurement boards (MP/MEM), excitation boards (FEX), logic boards (KU), and converter modules. The SDCS‑MP‑1 belongs to the measurement/monitoring board family (MP module) in the DCS series.
Recommended Models
Same Series or Related Models
| Model | Description | Key Parameters |
|---|---|---|
| SDCS‑MP‑2 | Next‑generation measurement board | Approx. weight ~0.25 kg; similar footprint |
| SDCS‑MEM‑8 | Memory card module for DCS system | Weight ~0.10 kg; small form‑factor |
| SDCS‑KU2002 | Logic/communication board in DCS system | Dimensions ~180×140×25 mm; weight ~0.23 kg |
| SDCS‑IOB‑21 | I/O interface board (24 V DC field side) | DI/DO board; weight ~0.72 kg |
| SDCS‑FEX‑4A | Field‑excitation module in same modular family | Output 0‑500 V DC; weight ~0.82 kg |
Popular Models (Same Brand)
| Model | Description | Key Parameters |
|---|---|---|
| ACS880‑01‑097A‑3 | High‑performance AC drive | ~75 kW; 400 V; ~55 kg |
| DCS800‑S02‑0160‑05 | High‑capacity DC drive module | ~160 A; 500 V; ~48 kg |
| CI858A | Communication interface module | 24 V DC; ~0.50 kg |
| PM865K01 | Processor module for automation/control systems | 24 V DC; ~0.55 kg |
| DSQC1047 | Automation control board | 24 V DC; ~0.70 kg |
FAQ (Frequently Asked Questions)
Q1: What is the main function of the SDCS‑MP‑1 board?
A1: It acts as a measurement or signal‑monitoring board within ABB’s DCS modular drive system.
Q2: What supply voltage does the module use?
A2: It is designed to operate under a 24 V DC supply for the board electronics.
Q3: What is the typical size and weight?
A3: Approximately 180 mm × 140 mm × 25 mm and weight about 0.23 kg.
Q4: Is it designed for new installations or retrofit?
A4: It is suitable for both new installations and retrofit scenarios where measurement/monitoring boards are required.
Q5: What environments is the board built for?
A5: Industrial drive and automation environments with wide temperature ranges and modular cabinet use.
Q6: How does it help reduce downtime?
A6: As a modular board, it can be swapped quickly without replacing full drive units, thus reducing maintenance downtime.
Q7: Which series does it belong to?
A7: It belongs to the DCS Control System Series by ABB, specifically the “MP” measurement board family.
Q8: Can it be used as a spare part for drive service?
A8: Yes — its modular design makes it ideal as a spare board for service kits.
Q9: Does it support signal measurement only, or control tasks as well?
A9: Primarily measurement/monitoring tasks within the drive system, not the main control of the motor/drive output.
Q10: What advantage does the board offer compared to replacing large modules?
A10: It offers a cost‑effective path by replacing a smaller module rather than a large drive system, thereby saving cost and reducing downtime.
