ABB CI520 (3BSE001800R1) — Detailed Product Specification, Introduction, and Application Guide
Product Overview
The ABB CI520 (3BSE001800R1) is a high-performance communication interface module designed for seamless integration into industrial control systems. This module is engineered to enable efficient communication between field devices, controllers, and supervisory systems within a robust industrial network. The CI520 module is versatile and supports multiple communication protocols, making it ideal for connecting devices across a wide range of applications in process control, industrial automation, and energy management.
The CI520 module plays a critical role in ensuring real-time data exchange, reliability, and scalability in control systems, especially in environments with heavy industrial equipment. It is part of ABB’s comprehensive suite of communication and control modules, designed for seamless integration in large and complex automation systems.
Brand and Product Series
-
Brand: ABB
-
Product Series: CI Communication Interface Modules
The CI series includes modules that bridge the communication gap between field devices and supervisory or control systems. These modules support various industrial communication protocols, making them essential in modern automation, energy, and process control systems. The series emphasizes high-speed data transfer, reliability, and ease of integration, meeting the needs of industries such as manufacturing, energy, and utilities.
Product Introduction
The CI520 is a communication interface module designed to enhance connectivity in industrial control systems. It supports multiple industrial protocols, enabling the integration of various field devices and supervisory systems. The module provides reliable data transmission in real-time, ensuring that critical process parameters are monitored and controlled with precision.
Key features of the CI520 module include:
-
Multi-protocol support for Modbus, Profibus, and IEC 61850
-
Fast data transmission rates of up to 10 Mbps, ensuring real-time communication
-
Robust industrial design to withstand vibration, electrical interference, and temperature fluctuations
-
Modular design for easy installation and scalability
-
Built-in diagnostics for power, communication, and fault detection via LED indicators
This product is engineered for ease of installation and operation, with a compact form factor that can be easily integrated into DIN rails or modular racks for industrial setups.
Applications
The CI520 is suitable for a variety of industrial applications, including:
-
Industrial Automation Networks: Facilitates communication between field devices (such as sensors and actuators) and control systems (PLCs, DCS).
-
Energy Management Systems: Used in substations for communication with protective relays, energy meters, and supervisory systems.
-
Process Control Systems: Integrates with process control equipment for industries such as chemicals, pharmaceuticals, and manufacturing.
-
Building Automation: Enables communication for HVAC systems, lighting, water treatment, and other building management systems.
-
Infrastructure Monitoring: Utilized in infrastructure automation for monitoring environmental conditions and utilities.
Product Advantages
-
Reliable Communication: Supports multiple industrial protocols for wide compatibility and stable data transfer.
-
Scalable and Modular: Easy to scale by adding additional CI series modules for larger automation networks.
-
Durability: Designed to operate reliably under industrial conditions, including high temperatures, vibration, and electrical noise.
-
Fast Data Transfer Rates: Capable of transmitting data at speeds up to 10 Mbps, ensuring timely control and monitoring.
-
Simple Diagnostics: Built-in LEDs for immediate feedback on system status, making troubleshooting easier.
-
Versatile Applications: Can be used in a wide range of industries, including manufacturing, utilities, and energy.
Technical Specifications
| Specification | Details |
|---|---|
| Model | CI520 (3BSE001800R1) |
| Module Type | Communication Interface Module |
| Protocols Supported | Modbus, Profibus, IEC 61850 |
| Digital Inputs | 16 inputs |
| Digital Outputs | 8 outputs |
| Analog Inputs | 8 channels (voltage/current) |
| Analog Outputs | 4 channels (voltage/current) |
| Data Transfer Rate | Up to 10 Mbps |
| Power Supply | 24 V DC |
| Power Consumption | 8 W |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Isolation | Channel-to-system isolation |
| Dimensions (H×W×D) | 120 mm × 160 mm × 60 mm |
| Weight (kg) | 1.35 kg |
| Mounting Method | DIN rail / Modular rack |
| Status Indicators | Power, communication, fault LEDs |
Related Models — Same Series or Similar Function
| Model | Digital Inputs | Digital Outputs | Analog Inputs | Analog Outputs | Protocols | Power (W) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| CI501 | 8 | 4 | 4 | 2 | Modbus, Profibus | 6.0 | 100 × 140 × 55 | 1.10 |
| CI502 | 12 | 6 | 6 | 3 | Modbus, Profibus, IEC 61850 | 7.5 | 120 × 160 × 60 | 1.25 |
| CI503 | 16 | 8 | 8 | 4 | Modbus, Profibus, DNP3 | 9.0 | 140 × 180 × 70 | 1.45 |
| CI504 | 24 | 12 | 12 | 6 | Modbus, IEC 61850, DNP3 | 10.0 | 150 × 200 × 80 | 1.80 |
| CI510 | 32 | 16 | 16 | 8 | Modbus, DNP3, IEC 61850 | 12.0 | 180 × 220 × 85 | 2.30 |
Other Popular Models — Same Brand
| Model | Function | Channels/Outputs | Protocols/Resolution | Power (W) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| DI810 | Digital Input Module | 16 digital inputs | Digital | 2.0 | 90 × 120 × 25 | 0.32 |
| DO810 | Digital Output Module | 16 digital outputs | Digital | 2.0 | 90 × 120 × 25 | 0.33 |
| AI820 | Analog Input Module | 12 analog inputs | 16-bit | 3.0 | 90 × 120 × 40 | 0.50 |
| AO820 | Analog Output Module | 12 analog outputs | 16-bit | 3.0 | 90 × 120 × 40 | 0.50 |
| BCU‑12 | Control/Interface Module | Multi I/O | Digital/Analog | 10.0 | 140 × 180 × 70 | 2.10 |
Frequently Asked Questions (FAQ)
Q1: What is the CI520 module used for?
A1: The CI520 is a communication interface module that connects field devices to control systems, enabling real-time data exchange for process monitoring and control.
Q2: What protocols does the CI520 support?
A2: It supports Modbus, Profibus, and IEC 61850.
Q3: How many digital inputs does the CI520 provide?
A3: It provides 16 digital inputs.
Q4: Can the CI520 handle analog signals?
A4: Yes, the CI520 has 8 analog inputs and 4 analog outputs.
Q5: What is the maximum data transfer rate of the CI520?
A5: The module supports a maximum data transfer rate of 10 Mbps.
Q6: What are the operating temperature ranges for the CI520?
A6: The operating temperature range is from –20°C to +60°C.
Q7: What is the weight of the CI520 module?
A7: The CI520 weighs approximately 1.35 kg.
Q8: Is the CI520 suitable for use in harsh environments?
A8: Yes, it is designed to withstand electrical interference, temperature extremes, and vibration, making it suitable for industrial environments.
Q9: How is the CI520 mounted?
A9: The CI520 can be mounted on a DIN rail or in a modular rack.
Q10: Does the CI520 provide built-in diagnostic features?
A10: Yes, the CI520 has built-in diagnostic LEDs that provide real-time feedback on power, communication, and faults.
