Product Overview
The Yokogawa GM90PS-1N1D0 is a power supply module for the SMARTDAC+ GM data acquisition platform. It serves as the power interface for the GM system, supplying the operating power required by the connected system components and supporting continuous operation of the data acquisition architecture.
In a typical SMARTDAC+ GM installation, the power supply module is installed as part of the system infrastructure rather than directly processing measurement signals. Its role is to establish the electrical power path for the main unit and associated modules, allowing signal acquisition, recording, communication, and other system functions to operate from a common platform.
The GM90PS-1N1D0 is suited to installations where the SMARTDAC+ GM system is used for centralized measurement and monitoring. Typical applications include equipment monitoring, process data collection, test systems, and industrial recording stations where dependable system power is required alongside measurement modules.
Because the power supply is part of the system hardware architecture, correct module selection and installation are important when expanding or servicing a SMARTDAC+ GM installation. The module should be considered together with the GM main unit, I/O configuration, communication hardware, and available power distribution arrangement.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Model | GM90PS-1N1D0 |
| Product Family | SMARTDAC+ GM |
| Product Type | Power Supply Module |
| System | SMARTDAC+ GM Data Acquisition System |
| Module Function | System power supply |
| Application | Powering SMARTDAC+ GM system components |
| Installation | SMARTDAC+ GM system architecture |
| System Role | Power infrastructure |
| Dimensions | 135 × 56.8 × 107.1 mm |
| Weight | 0.55 kg |
Product Features
- Part of the Yokogawa SMARTDAC+ GM modular data acquisition platform.
- Provides the system power interface required by the GM architecture.
- Supports the operation of connected SMARTDAC+ GM system hardware.
- Suited to centralized data acquisition and industrial monitoring installations.
- Separates system power management from measurement and recording functions.
- Can be considered during system expansion, replacement, and maintenance planning.
- Fits into the modular architecture used for SMARTDAC+ GM installations.
Working Principle
The GM90PS-1N1D0 operates as the power entry and distribution element within the SMARTDAC+ GM system. Incoming system power is handled by the power supply module and made available to the system components that require operating power.
In normal operation, the module does not perform the primary measurement calculation itself. Instead, it establishes the electrical foundation on which the GM main unit, measurement modules, communication functions, and other system hardware can operate.
Power Input → GM90PS-1N1D0 → SMARTDAC+ GM System Power → Main Unit / I/O / Communication Functions
During maintenance, the power supply module should therefore be checked as part of the complete system power path. A problem at this stage can affect multiple system functions simultaneously even when the individual measurement modules are operating correctly.
Role in a SMARTDAC+ GM Data Acquisition Control Architecture
The GM90PS-1N1D0 occupies the power infrastructure layer of the SMARTDAC+ GM architecture. While measurement modules handle field signals and the main system handles acquisition, recording, and communication tasks, the power supply module establishes the electrical supply required for those functions to operate.
| System Element | Function |
|---|---|
| GM90PS-1N1D0 | Supplies operating power within the SMARTDAC+ GM system |
| SMARTDAC+ GM Main Unit | Coordinates system operation and data acquisition functions |
| Input Modules | Acquire process, equipment, or test signals |
| Communication Functions | Exchange measurement and system data with external equipment |
| Recording / Monitoring Functions | Store, display, and manage acquired data |
| External Power Source | Provides the electrical input to the system power architecture |
Industrial Applications
| Application | Typical Use |
|---|---|
| Industrial Data Acquisition | Provides system power for continuous measurement and monitoring installations |
| Process Monitoring | Supports SMARTDAC+ GM systems used to collect and manage process data |
| Equipment Testing | Used as part of test and measurement systems requiring modular data acquisition |
| Production Monitoring | Supports recording systems installed around manufacturing equipment |
| Equipment Condition Monitoring | Supplies the platform used to collect operational measurements |
| Laboratory and Test Facilities | Provides system infrastructure for repeatable measurement and recording setups |
Installation and Maintenance
- Verify the GM90PS-1N1D0 model against the intended SMARTDAC+ GM system configuration before installation.
- Confirm that the installation environment meets the requirements of the complete SMARTDAC+ GM system.
- Isolate the applicable power source before removing or installing the module.
- Check the mounting position and mechanical engagement before applying power.
- Ensure that the module is correctly seated in the designated system position.
- Inspect power connections for loose terminals, damaged conductors, or signs of overheating.
- Keep wiring routed so that it does not interfere with neighboring modules or ventilation paths.
- After installation, restore power according to the approved system startup procedure.
- Check the system for normal power-up behavior and module status indications.
- If the system fails to start correctly, inspect the power path before replacing signal-processing modules.
- During preventive maintenance, check connectors and surrounding wiring for contamination, looseness, or physical damage.
- When replacing the power supply module, verify the complete system configuration before returning the SMARTDAC+ GM installation to service.
Related Components
| Component | Function |
|---|---|
| SMARTDAC+ GM Main Unit | Provides the central system platform for data acquisition and operation |
| SMARTDAC+ GM Input Modules | Interface with measurement signals from field or test equipment |
| SMARTDAC+ GM Output / Control Functions | Provide system-side signal or control interfaces where configured |
| Communication Interface | Connects the GM system with external monitoring or control equipment |
| System Power Wiring | Transfers electrical power to the SMARTDAC+ GM power architecture |
| Mounting Hardware | Secures the modular system components in the installation |
Recommended Related Models
| Model | Product Type | Typical Application |
|---|---|---|
| Yokogawa GM90PS-1N1D0 | SMARTDAC+ GM Power Supply Module | System power supply |
| Yokogawa GM10 | SMARTDAC+ GM Data Acquisition Module | Modular data acquisition |
| Yokogawa GX90XA | SMARTDAC+ Analog Input Module | Analog measurement acquisition |
| Yokogawa SMARTDAC+ GM Main Unit | Data Acquisition Main Unit | Central system operation and data handling |
Key Advantages
- Dedicated power supply module for the SMARTDAC+ GM platform.
- Supports the electrical infrastructure of modular data acquisition systems.
- Helps separate system power functions from measurement processing.
- Suitable for industrial monitoring, recording, and test applications.
- Practical for system replacement and maintenance work where the original power module must be matched.
Technical FAQs
What is the function of the Yokogawa GM90PS-1N1D0?
The GM90PS-1N1D0 functions as a power supply module within the SMARTDAC+ GM system. It supports the electrical supply required by the associated GM system hardware rather than serving as a primary measurement input module.
Can the GM90PS-1N1D0 be treated as a measurement input module?
No. Its primary role is system power supply. Measurement acquisition is handled by the appropriate SMARTDAC+ GM input or measurement modules installed in the system.
What should be checked before replacing a GM90PS-1N1D0?
Check the existing SMARTDAC+ GM configuration, module position, power wiring, connectors, and system compatibility. The replacement should match the required system architecture rather than being selected only by physical appearance.
What symptoms may indicate a problem with the power supply module?
A power-related fault can affect several system functions at the same time. Symptoms may include abnormal system startup, loss of operation of connected modules, or missing system status indications. The complete power path should be checked before concluding that an individual I/O module has failed.
