Product Introduction – ADV859-P00
The ADV859-P00 is a 16-channel digital input + 16-channel digital output mixed I/O module designed for industrial automation and modular I/O racks. It features isolated channels for both inputs and outputs, supporting standard 24 V DC field signals. The module is engineered to integrate into Yokogawa’s rack-based I/O systems (ST-compatible series), providing a compact and flexible solution where both discrete inputs and outputs are required in one card.
Its output section supports basic transistor switching (rated approx. 30 V DC, 100 mA) and also supports pulse-width or time-proportional output control for timed sequences. The input section accepts contact or voltage inputs (e.g., OFF: ≥100 kΩ, ON: ≤200Ω) and responds in the millisecond range.
With such versatility, the ADV859-P00 is well suited for control cabinets, remote racks, field interface panels, or integration into distributed control systems where space, cost, and wiring efficiency matter.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Digital Input Channels | 16 |
| Number of Digital Output Channels | 16 |
| Signal Isolation | Fully isolated channels (input & output) |
| Input Type | Contact input (OFF ≥100 kΩ, ON ≤200 Ω) & Voltage input (OFF: 4.5-25 V DC, ON: ≤1 V DC) |
| Input Response Time | Approx. 8 ms (status input) |
| Output Type | Transistor switch (current-sink) |
| Output Contact Rating | approx. 30 V DC, 100 mA (resistive/inductive) |
| Output Response Time | ≤16 ms |
| Pulse-Width / Time-Proportional Output | Range approx. 8 ms to 7200 s; resolution approx. 8 ms + up to 1 ms ON/OFF delay |
| Power Supply / Current Consumption | Logic supply (approx. 5 V DC) – consumption approx. 450 mA (typical) |
| External Connection | Dedicated cable interface (e.g., KS2) |
| Compatible I/O Backplane | ST2-compatible rack system |
| Dimensions | ~ 144 mm (W) × 100 mm (H) × 30 mm (D) |
| Weight | ~ 0.30 kg |
| Operating Environment | Standard industrial I/O cabinet, modular rack installation |
| Mounting | Plug-in rack module, front-accessible wiring terminals |
Applications
-
Modular I/O racks in process plants which require discrete input monitoring and output switching in one module (e.g., status indications + actuator control).
-
Control of field devices in water/wastewater treatment: pumps, blowers, valves and alarms – where both input status and timed output sequences are needed.
-
Discrete manufacturing or packaging lines: combining sensors (input) and actuators (output) with timing of output pulses.
-
Remote I/O stations near the field: reducing cable runs by using one mixed I/O card rather than separate input & output cards.
-
Alarm/interlock cabinets: monitoring fault inputs and driving alarm outputs with optional pulse sequences.
-
Retrofit installations in automation systems where space is constrained and reducing module count is beneficial.
Advantages
-
Mixed-function I/O in one card reduces module count, wiring complexity and panel space.
-
Timing output capability (pulse-width/time-proportional) adds flexibility beyond simple ON/OFF switching.
-
High isolation ensures safe operation in noisy industrial environments and protects sensitive control logic.
-
Compact and lightweight (~0.30 kg) makes it easy to mount and manage in dense racks.
-
Standard 24 V DC compatibility aligns with typical industrial sensors and actuators.
-
Simplified inventory: one module covers both discrete input and output, simplifying spares and maintenance.
-
Flexible architecture: well suited for modular expansion, retrofit, or remote I/O deployment.
-
Efficient wiring and installation: fewer cards, fewer terminations, faster commissioning.
Brand & Series
-
Brand: Yokogawa
-
Series: ADV (Digital I/O Modules) – Mixed I/O family
-
Model: ADV859-P00 – Mixed digital I/O module (16 IN / 16 OUT) with timing output capability
Recommended Related Models – Same Series or Functional Variants
| Model | I/O Channels | Key Features | Weight Approx. |
|---|---|---|---|
| ADV859-P00 | 16 DI + 16 DO | Mixed I/O w/ timing output | ~0.30 kg |
| ADV859-P01 | 16 DI + 16 DO | Mixed I/O, higher environmental spec | ~0.32 kg |
| ADV551-P00 | 32 DO | Output-only, 24 V DC transistor outputs | ~0.28 kg |
| ADV559-P00 | 32 DO | Output-only, 24 V DC, timing variant | ~0.28 kg |
| ADV151-P60 | 32 DI | Input-only module, high density | ~0.27 kg |
Recommended Popular Models – Same Brand
| Model | Type | Channels | Weight Approx. |
|---|---|---|---|
| ADV161-P00 | Digital Input | 64 DI | ~0.32 kg |
| ADV561-P10 | Digital Output | 64 DO | ~0.30 kg |
| ADV569-P00 | Digital Output | 64 DO | ~0.33 kg |
| ADV859-P01 | Mixed I/O | 16 DI + 16 DO (rugged) | ~0.32 kg |
| ADV551-P00 | Digital Output | 32 DO | ~0.28 kg |
FAQ – (10 Questions & Answers)
Q1: What does the ADV859-P00 module provide?
A1: It provides 16 digital input channels and 16 digital output channels in one module, combining status monitoring and actuator output in a single card.
Q2: What voltage are the I/O channels designed for?
A2: Both input and output channels are designed for 24 V DC standard industrial signals.
Q3: Are the channels isolated?
A3: Yes — input and output channels are isolated to protect the control system and reduce interference.
Q4: Can the outputs perform timed functions?
A4: Yes — the output section supports pulse-width and time-proportional modes, with a range from roughly 8 ms up to 7200 seconds.
Q5: What is the typical weight and dimension of the module?
A5: Approximately 144 mm wide × 100 mm high × 30 mm deep, and weighs about 0.30 kg.
Q6: What type of loads can the outputs drive?
A6: The outputs are transistor type, rated for approx. 30 V DC and 100 mA (resistive or inductive loads).
Q7: What is the response time for inputs and outputs?
A7: Input response time is about 8 ms for status changes; output response time is less than or equal to 16 ms for normal switching.
Q8: Is this module suited for remote I/O stations?
A8: Yes — thanks to its mixed I/O design and compact footprint, it is well suited for remote racks or field I/O panels.
Q9: Does it support redundant systems?
A9: Yes — the module is designed to plug into modular rack systems which can be configured for redundancy for higher availability.
Q10: In what industries is the ADV859-P00 typically used?
A10: It is often used in process control, utilities, manufacturing, packaging, water/wastewater, and any automation system requiring both discrete inputs and outputs with timing capability.
