Product Profile: Yokogawa AAI143‑S53/A4S00
Product Introduction
The AAI143‑S53/A4S00 is a rugged, sixteen‑channel analog input module engineered for control and instrumentation systems. Designed for industrial environments, it reads 4–20 mA signals with high accuracy, extreme reliability, and strong isolation. The S53 variant supports an extended operating temperature range and is equipped with a pressure‑clamp connection block (A4S00) for secure field wiring. Industry-tested for heavy-duty use, this module ensures long-term stability in temperature-variable, high-interference environments.
It is ideally placed in applications where precise multi-channel signal acquisition and robust physical connections are both critical.
Technical Specifications
| Specification | Details |
|---|---|
| Model | AAI143‑S53/A4S00 |
| Input Signal | 4–20 mA DC |
| Channels | 16 (individually isolated) |
| Accuracy | ±16 µA |
| Input Resistance | 270–350 Ω across the input range |
| Data Update Interval | 10 ms |
| Isolation Voltage | 1500 V AC (input to system, 1 min) |
| Transmitter Loop Power | 19–25.5 V DC (max 25 mA per channel) |
| Operating Temperature Range | –20 °C to +70 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Interface Type | A4S00 (pressure‑clamp terminal block) |
| Mounting | Rack or baseplate module installation |
| Dimensions (L × W × H) | 107.5 mm × 32.8 mm × 130 mm |
| Weight | 0.30 kg |
| Power Consumption | ~230 mA at 5 V DC; ~540 mA at 24 V DC |
| Certification | Meets industrial safety and EMC standards |
Product Applications
-
Refinery & Petrochemical
Ideal for signal acquisition from flow, pressure, or temperature transmitters in hot zone panels. -
Power Plant I&C
Interfaces accurately with turbine and boiler sensors in harsh thermal environments. -
Water & Wastewater Treatment
Monitors chemical dosing, pump statuses, and level sensor inputs with high fidelity. -
Pharmaceutical Manufacturing
Supports reliable analog signal input in controlled clean‑room environments. -
Heavy Duty Automation
Perfect for processing plants (steel, mining, pulp) where environmental extremes demand robust signal modules.
Product Advantages
-
High-Temperature Capability
Operates reliably up to +70 °C, a step above standard modules. -
Secure Wiring with Clamp Blocks
The A4S00 terminal ensures fast, tight, and vibration-resistant connections. -
Solid Channel Isolation
1500 V electrical separation between channels and system base safeguards against crosstalk and failure propagation. -
High Precision Sensing
±16 µA accuracy facilitates tighter control and detection of process variances. -
Fast Scanning for Real-Time Data
10‑millisecond update intervals deliver near‑instantaneous feedback to control systems. -
Space‑Saving & Lightweight
Compact dimensions and 0.3 kg weight make for high-density installations.
Brand & Series
-
Brand: Yokogawa
-
Series: AAI143 Series — isolated analog input modules for process control systems, featuring variants by temperature range, interface type, and communication protocol.
Related Models (Same Series or Closely Related)
| Model | Input Type | Channels | Temp Range | Interface | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| AAI143‑S50/A4S00 | 4–20 mA | 16 | –20 °C to +60 °C | A4S00 | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑H53/A4S00 | 4–20 mA + HART | 16 | –20 °C to +70 °C | A4S00 | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑S53/S1 | 4–20 mA | 16 | –20 °C to +70 °C | Loop-powered | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑S53/K4S00 | 4–20 mA | 16 | –20 °C to +70 °C | KS cable | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑S53/K4A00 | 4–20 mA | 16 | –20 °C to +70 °C | KS cable alt. | 107.5 × 32.8 × 130 | 0.30 |
Popular Models from Same Brand
| Model | Type | Channels | Input/Output | Interface | Temp Range | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| AAI543‑S53/A4S00 | Analog Output | 16 | Output | A4S00 | –20 °C to +70 °C | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑H50/A4S00 | Analog Input + HART | 16 | Input | A4S00 | –20 °C to +60 °C | 107.5 × 32.8 × 130 | 0.30 |
| AAI543‑H53/K4S00 | Analog Output + HART | 16 | Output | KS cable | –20 °C to +70 °C | 107.5 × 32.8 × 130 | 0.30 |
| AAI143‑H53/K4A00 | Analog Input + HART | 16 | Input | KS cable alt. | –20 °C to +70 °C | 107.5 × 32.8 × 130 | 0.30 |
| AAB841‑S00/A4S00 | Mixed I/O Module | 8 in / 8 out | In/Out | A4S00 | –20 °C to +60 °C | 107.5 × 32.8 × 130 | 0.30 |
Frequently Asked Questions (QA Format)
Q1: What temperature range can the AAI143‑S53/A4S00 handle?
A1: It operates reliably between –20 °C and +70 °C.
Q2: How many input channels does it include?
A2: It includes 16 independently isolated analog input channels.
Q3: Does this model support HART communication?
A3: No. The S53 variant is analog-only. Use H53 versions for HART compatibility.
Q4: What type of interface does it use?
A4: It uses a pressure-clamp terminal block (A4S00) for secure wiring.
Q5: What is the device’s input accuracy?
A5: ±16 µA accuracy ensures high-fidelity analog measurements.
Q6: How often does it update data?
A6: The module updates signals every 10 ms.
Q7: What level of electrical isolation is provided?
A7: Input channels are isolated at 1500 V AC from the system base.
Q8: What is the module’s weight and size?
A8: It weighs 0.30 kg and measures 107.5 × 32.8 × 130 mm.
Q9: Can it provide powering to field transmitters?
A9: Yes, it supplies loop power up to 25 mA per channel.
Q10: Is the module suitable for high-temperature panels?
A10: Yes. It’s designed for reliable operation in panels up to +70 °C.
